OSD Audio XMP500DSP Owner's Manual

XMP500DSP
Digital Stereo Power Amplifier
FEATURES:
MAIN / INTERRUPT priority input switching
MAIN auxiliary output
Speaker A/B switching
Front panel Balance and Volume controls
Signal sensing "Power On" and Trigger mode
Rear mounted treble and bass controls
SPECIFICATIONS
Stereo (8 ohm): 250W per channel, <1% THD+N
Stereo (4 ohm): 350W per channel, <1% THD+N
Bridged Mono (8 ohm): 700W, 1kHz, <1% THD+N
Frequency Response: 10Hz ~ 30kHz, -2dB/ +1dB
Signal to Noise Ratio: 100dB below 250W output into 8 ohms
w/20kHz Lowpass filter
Channel Separation: 65dB @ 1kHz, referred to 250W output
into 8 ohms
Input Sensitivity: 700mV input for rated 250W output
into 8 ohms
Bass/Treble Control: +/- 12dB @ 100Hz and 10kHz
AC Power Consumption: 700W maximum
Net Weight: 9.85lbs / 4.6kgs
Gross Weight: 12.85lbs / 6kgs
OsdAudio ®
775 Columbia St.,
Brea. CA92821
www.osdaudio.com
Congratulations on your purchase of the OsdAudio ® XMP500DSP.
Please take a few moments to read this entire manual, and be sure to
retain this document for future reference. Please read and observe all
safety instructions detailed on page 2.
NOTE: If any part of this product is damaged or missing, please call your
dealer or OsdAudio ® directly at 562 697 2600.
Please read your warranty and retain your receipt and original carton
for possible future use.
For more information about OsdAudio ® electronics, speakers and
accessories please visit www.osdaudio.com
2.15"
(55mm)
11"
(280mm)
XMP500DSP
OWNER'S MANUAL
16.9" (435mm)
XMP500 DSP man. 4/19
