Summary of Contents for Cozy N Safe aRTHur

  • Page 2 INSTRUCTION MANUAL Birth - 36kg (Approx. Birth - 11 years) Model: EST 528 Group: 0+/1/2/3 Please read this manual carefully before use...
  • Page 3 PA RT S 06 - S houl d er pa d 05- h e a dr es t 07 - s ea t cush ion 0 8 -shoul d er belt 04 - d ia go nal bel t guid e (G ro u p. I I, III ) 09 -w a ist bel t 1 0- buc kl e 1 1- crot ch pad...
  • Page 4 s u i ta bl e w eigh t a nd i n st a ll a ti o n met ho ds s umma ry direct io n o f child fi x fi x m e th o d Grou p wei ght s e at an gl e...
  • Page 5 NOTICE ( 1 ) 1. When this CRS is used in group 0+/2+3 for child (0-13kg/15-36kg) and only fasten by 3-point safety belt, This is a "Universal" child restraint. It is approved to Regulation No. 44, 04 series of amendments, for general use in vehicles and it will fit most, but not all car seats. 2.

  • Page 6: Table Of Contents

    CONTENT 1. Introduction........................................05 2. Suitability...........................................05 3. General safety instructions................................06 4. Adjustments........................................08 4.1 Remove and reset the seat cushion............................08 4.2 Adjusting the recline position..............................08 4.3 Adjusting the crotch belt................................09 4.4 Adjust the harness and headrest height.........................09 5. Seat selection and adjustment..............................10 5.1 Adjusting the car seat..................................10 5.2 Seat for universal installation...............................10 5.3 Seat for semi-universal installation............................11...

  • Page 7: Introduction

    Instruction manual 1. Introduction We are happy that you have decided on the Arthur as your choice for a child restraint system. To gain the most comprehensive protection for your child, the seat must be used exactly as described in this manual.

  • Page 8: General Safety Instructions

    3. General safety instructions If it is the first time using the child restraint system, Please read the entire instruction manual thoroughly before installation. In any case improper installation can endanger the life of your child. Make sure the child restraint system is properly installed with your child, prior to the trip. Do not attempt to make any adjustments during driving.
  • Page 9 The child restraint must not be used without the cover provided. The seat cover should not be replaced with any other than the one recommended by the manufacturer, because the cover constitutes an integral part of the restraint performance. Your car seat must be positioned and installed properly so that, under normal vehicle usage conditions, no part can become jammed under or between any moveable seat or in the vehicle door.

  • Page 10: Adjustments

    4. Adjustments 4.1. Remove the seat cushion The seat must be used for children from 0 to 13kg (approximately birth front to 9 months ) with the seat cushion view (Fig. 2). Once your child 's weight is between back 9kg to 36kg (approximately 15 view months to 11 years), you must...

  • Page 11: Adjusting The Crotch Belt

    4.3. Adjusting the crotch belt The crotch belt is positioned at the inner slot. When you feel that the crotch belt is too tight for your child. Please adjust as follow: (Fig. 5, 6) 4.3.1. Pull up the cover at the front of your seat, Pinch the crotch belt (part no.12 page 01) and push down.

  • Page 12: Seat Selection And Adjustment

    5. Seat selection and adjustment 5.1 Adjusting the car seat If the installation is restricted by the vehicle headrest then it must be moved to the highest position or removed. (Fig. 9) Adjust the seat to the right position, place it on the vehicle seat forward facing and make sure the backrest of seat is firmly pressed against the backrest of vehicle seat.

  • Page 13: Seat For Semi-Universal Installation

    5.3. Seat for semi-universal installation for (Group. II, III) Semi-universal installation of the child restraint system is only possible on car seats fitted with ISOFIX anchors. With the aid of the ISOFIX connectors, the seat can be securely fastened to the body of the vehicle by using these ISOFIX anchor points. 5.4.
  • Page 14 IMPORTANT - DO NOT USE FORWARD FACING BEFORE THE CHILD'S WEIGHT EXCEEDS 9KG. (We recommend to try to extend the use of age and weight to use the rear facing position until your child’s weight is more than 13kg). 6.1.1. Seat angle adjust: Refer to (fig.14) to adjust the seat to the most recline position (position 4).

  • Page 15: Semi-Universal Installation In Vehicle With Fix

    6.1.2.5. Pull the diagonal belt at the top of the vehicle buckle to make sure that the belt is tight. (fig. 18) 6.1.2.6. Then pull the diagonal belt at the top of the seat as indicated by the arrow, as tight as you can.. As tight as you can.

  • Page 16: Isofix-Universal Installation In Vehicle With Isofix And Top Tether

    6.2.3 Then place the seat on a vehicle seat and push both ISOFIX CLICK connectors onto the metal brackets (ISOFIX anchor points) and press firmly against it so that the connectors lock in place (Fig. 23). The correct locking will be confirmed when the "green colour"...

  • Page 17: Securing The Child

    6.3.2.3. Put the top tether through the vehicle headrest, Then hook it onto the vehicle top tether anchorage according to the vehicle manual. (fig. 27) 6.3.2.4. Hold the end of the belt and pull out until the belt is tight enough (the green indicator will appear).

  • Page 18: Securing The Child In Groups Ii+Iii (15 - 36 Kg)

    7.1.3. Put your child into the child seat, put the buckle (part no.10 page 01) on the front of your child’s crotch. Make your child’s arms are through the shoulder belts, ensure that the shoulder belts and pads are just on top of your child's shoulders.
  • Page 19 7.2.1 Remove the harness 7.2.1.1. Relax the harness. (fig. 34) 7.2.1.2. Turn to the back of your child seat ,push down the instruction box button and at the same time pull out the box. (fig.35) 7.2.1.3. Pull out the adjuster belt and release the two shoulder belts from the metal connector. (fig.
  • Page 20 7.2.2. Seat installation It can be used forward facing only at Group II, III. The ISOFIX connector is an optional for Group II, III. If it is connected to the ISOFIX anchor point on the vehicle seat or not. (fig. 23 on page 14). 7.2.2.1.

  • Page 21: Removing And Replacing The Cover

    8. Removing and replacing the cover The fabric cover on this seat can be removed for washing, It just needs to be pulled out at the fringe of the seat(fig. 43). After washing you can assemble it to the seat again. The seat cover is an integral part of the child seat.

  • Page 22: Steps To Take After An Accident

    10. Steps to take after an accident After an accident with an impact speed greater than 10 km/h, the child restraint system must be replaced without fail. There may be hidden damages. 11. Warranty For the seat we extend a warranty against defects in materials and workmanship for up to one years.

  • Page 23: Fit List

    12. Fit list Since product year ＊ No top With toptether With 3 point belt Quantity of vehicle doors Quantity of seat Mobile vehicle Estate car Ragtop Hatchbacks Multi-Purpose Vehicle Coupe Check if the vehicle has suitable anchor 4 ... (suitable seat) a) Starting from the model has in the market b) Starting from the model has in the assemble line c) Week of natural...
