Summary of Contents for Cozy N Safe Arthur EST-528

  • Page 2 Child Safety Car Seat Instruction Manual Model:EST-528 Group: 0+,1,2,3 Weight: Birth-36kg (Approx: Birth-11 years） Please read this manual carefully before use...
  • Page 3 *When used as Semi-universal Group 2, 3, these connectors mean: Additional Attachment (FIX) Notice this picture is just for reference and may differ from Features Indication the actual model. 09-seat cushion 08-shoulder belt 01-headrest 10-waist belt 02-diagonal belt guide 11-crotch belt 03-shoulder pad 12-crotch pad 04-buckle...
  • Page 4 Suitable weight and installation methods summary Fit method Child fit Weight Direction of Seat angle Group for seat method installation Position 4 Rearward 5 point Vehicle 3 (most reclined) 0-13kg facing harness point belt Birth- 15 months 　 Universal Position 4 Rearward Vehicle 3 5 point...
  • Page 5 Suitable weight and installation methods summary Fit method Child fit Weight Direction of Seat angle Group for seat method installation Forward Position Vehicle 3 Vehicle 3 facing 1,2,3 point belt point belt 15-36kg (Main method) 3-11 years universal Position Forward Vehicle 3 point belt Vehicle 3 (FIX is an optional...
  • Page 6 NOTICE(1) 1. When this child car seat is used in group 0+/1,2,3 for a child (0-18kg/15- 36kg) and only fastened by the 3-point safety belt, this is a "Universal" child restraint. It is approved to Regulation No. 44, 04 series of amendments, for general use in vehicles and it will fit most, but not all, car seats.

  • Page 7: Table Of Contents

    Table of content 1. Introduction......................07 2. Suitability........................07 3. General safety instructions................08-09 4. Adjustments......................10 4.1 Removing and resetting the seat cushion.............10 4.2 Adjusting the recline position................10 4.3 Crotch belt adjustment ..................11 4.4 Adjusting the harness and headrest height..........11 5. Seat selection and adjustment ................12 5.1 Adjusting the car seat...................12 5.2 Seat for universal installation................12 5.3 Seat for semi-universal installation..............13...

  • Page 8: Introduction

    Instruction Manual 1. Introduction We are happy that you have decided on this seat as your choice for a child restraint system. To gain the most comprehensive protection for your child, the seat must be used exactly as described in this manual. Please read this instruction manual carefully before use.

  • Page 9: General Safety Instructions

    3. General safety instructions If it is the first time you have used this child restraint system, please read the entire instruction manual thoroughly before installation. In any case improper installation can endanger the life of your child. Make sure the child restraint system is properly installed with your child, prior to the trip.
  • Page 10 3. General safety instructions Never leave your child unattended in the child restraint system. Any luggage or other objects liable to cause injuries in the event of a collision must be properly secured. The child restraint must not be used without the cover. The seat cover should not be replaced with any other than the one recommended by the manufacturer, because the cover constitutes an integral part of the restraint performance.

  • Page 11: Adjustments

    4. Adjustments 4.1 Remove the seat cushion The seat must be used for children from 0 to 13kg (approximately birth front view to 9 months old) with the seat cushion (Fig. 2). Once your child's weight is between back 9kg to 36kg (approximately 15 view seat cushion months to approximately 12-year-old)

  • Page 12: Crotch Belt Adjustment

    4.3 Crotch belt adjustment The crotch belt is positioned near the inner slot. When you feel that the crotch belt is too tight for your child, please adjust as follows: (Fig. 5,6) 4.3.1. Pull up the cover at the front of your seat, pinch the crotch belt (part no.11) and push down.

  • Page 13: Seat Selection And Adjustment

    5. Seat selection and adjustment 5.1 Adjusting the car seat If installation is prevented by a vehicle headrest, it must be set at the highest position or removed (Fig. 9). Put the seat on the vehicle seat, ensure that the backrest of seat can rest securely against the backrest the vehicle seat (Fig.

  • Page 14: Seat For Semi-Universal Installation

    5.3 Seat for semi-universal installation for (Group 2 +3) Semi-universal installation of the child restraint system is only possible on car seats fitted with ISOFIX anchors. With the aid of the ISOFIX connectors, the seat can be securely fastened to the body of the vehicle by using these ISOFIX anchor points.
  • Page 15 IMPORTANT - DO NOT USE FORWARD FACING BEFORE THE CHILD'S WEIGHT EXCEEDS 9KG. (We recommend to try and extend the use of age and weight to use the rear facing position until your child’ s weight is more than 13kg). 6.1.1 Seat angle adjustment: Refer to (fig.14) to adjust the seat to the most reclined position (the 4th position).
  • Page 16 6.1.2.2. Extend the vehicle 3 point belt to the maximum (fig.19). Move the lap strap through the slot at front of child seat, then through to the other side (fig.20). Insert the buckle tongue into the vehicle buckle and you will hear a "click"...

  • Page 17: Installation For Group 1 (Option 1)

    6.2 Installation for Group 1 (option 1): Rearward installation in vehicle with 3 point belt. In this option, the seat installation is exactly the same as 6.1, it is suitable for children up to 4 years approximately. 6.3 Installation for Group 1 (option 2): Forward installation in vehicle with 3 point belt.

  • Page 18: Installation For Group 1 (Option 3)

    6.3.2.2. Insert the buckle tongue into the vehicle buckle and you should hear an audible "Click" (fig. 30). Then put the lap strap of the 3 point vehicle belt into the slot that is between the seat body and seat base (fig31).
  • Page 19 6.4.1.2 Using one hand grab the ISOFIX control POP OUT AUTOMATIC ISOFIX handle (part no.16) at the lower part of the base, and pull outward (Fig.37). The ISOFIX connectors (part no.23) will now automatically extend from the back of the seat PULL base (part no.24).

  • Page 20: Installation For Group 2,3 (Option 1)

    6.4.2.2. Put the top tether (part no.21) under the vehicle headrest, then hook it onto the vehicle top tether anchorage according to the vehicle manual (fig.43). 6.4.2.3. Finally hold the end of the belt and pull until the belt is tight enough (the green indicator will appear) (fig.44).

  • Page 21: Securing The Child

    7. Securing the child 7.1 Securing the child in the age Group 0+(0 – 13 kg), Group I (9 – 18 kg) When your child`s weight is between 0-18kg. Your child will be fitted using the 5 point harness. Following the steps below: 7.1.1.

  • Page 22: Securing The Child In The Age Groups 2+3 (15 - 36 Kg)

    7.2 Securing the child in the age group 2+3 (15 – 36 kg) Important: When your child's weight is more than 15kg, you can use the vehicle 3 point belt to fit your child directly into the seat. 7.2.1 Remove harness 7.2.1.1.
  • Page 23 7.2.2 Seat installation The seat can be used in only a forward facing position at Group 2+3. The ISOFIX connector is optional for Group 2+3, 7.2.2.1 First refer to chapter 4.2 to adjust the seat angle to the right position. 7.2.2.2 Then refer to chapter 5.1 to put the child seat onto the vehicle seat, make sure the backrest is flush against the vehicle seat backrest.

  • Page 24: Removing And Replacing The Cover

    8. Removing and replacing the cover The fabric cover on this seat can be removed for washing. It just needs to be pulled out at the fringe of the seat (fig.60). After washing you can re-cover the seat again. The seat cover is an integral part of the child seat. The child restraint must not be used without the cover.

  • Page 25: Steps To Take After An Accident

    10. Steps to take after an accident After an accident with an impact speed greater than 10 km/h, the child restraint system must be returned to the retailer without fail. 11. Warranty For the seat we extend a warranty against defects in materials and workmanship for up to one year.

  • Page 26: Fit List

    12. Fit list ＊ Since product year No top tether With top tether With 3 point belt Quantity of vehicle doors Quantity of seat Mobile Vehicle Estate car Soft top Hatchbacks Multi-Purpose Vehicles Coupe Check if the vehicle has a suitable Anchor ...
  • Page 27 12. Fit list 2000 (Facelift 2004) 2007 C(W204) 2007 C(S204) 2007 03/11 C(204) E(W212;S212) 2009 2009 E(C207) 2008 ML(W164) 07/05 1(E87/E81) 2005 12/05 R(W251/V251) 1(E82) 2007 VOLVO 2008 1(E88) 2006 2005 1.35m 3(E90) 2005 3(E92) S80(Facelift 2009) 2006 (Typ AS) 08/05 2010 5(F10)
  • Page 28 (details on the back of this guide). Cozy N Safe Oxford Street, Bilston Wolverhampton, West Midlands, WV14 7DP, U.K Tel: +44 (0) 1902 494905 Fax: +44 (0) 1902 490211 Email: enq@cozynsafe.com...
