Cozy N Safe FUJI EST-508 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
C S
COZY N SAFE
R
F U J I
I N S T R U C T I O N M A N U A L
E S T - 5 0 8
G r o u p 1 / 2 / 3
9 k g t o 3 6 k g
( A p p r o x i m a t e l y 1 y e a r - 1 1 y e a r s )
E C E R 1 6 N o 4 4 . 0 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the FUJI EST-508 and is the answer not in the manual?

Questions and answers

Related Manuals for Cozy N Safe FUJI EST-508

Summary of Contents for Cozy N Safe FUJI EST-508

  • Page 1 COZY N SAFE F U J I I N S T R U C T I O N M A N U A L E S T - 5 0 8 G r o u p 1 / 2 / 3...
  • Page 2 2. A correct fit is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle is capable of accepting a “Universal” child restraint for this age group. 3. This child restraint has been classified as “Universal” COZY N SAFE...
  • Page 3 4. If in doubt, consult either the child restraint manufacturer or the retailer. Only suitable if the vehicle is fitted with 3-point safety belts, Approved to UN/ECE Regulation No.16 or other equivalent standards. EXTREME HAZARD Do not use in passenger seats equipped with airbags(SRS) COZY N SAFE...
  • Page 4 S A F E T Y W A R N I N G S COZY N SAFE...
  • Page 5 Do not secure your child restraint in the front passenger vehicle seating position equipped with an airbag. Please pay attention to all the red markings / stickers or red plastic parts on the seat, which are the belt routes for installation. COZY N SAFE...
  • Page 6 E S T - 5 0 8 C a r S e a t Any straps holding the restraint to vehicle should be adjusted to the child’s body. Straps should not be twisted. Ensure that any lap strap is worn low down so that the pelvis is firmly engaged. COZY N SAFE...
  • Page 7 Any luggage or other subjects should be properly secured or stored as they may cause injuries in the event of a collision or sudden braking. The child restraint must not be used without the cover. COZY N SAFE...
  • Page 8 The seat cover should not be replaced with any other than the one recommended by the manufacturer as restraint system performance. for its life period. Do not use any load bearing contact points other than child restraint. COZY N SAFE...
  • Page 9 The rigid items and plastic parts of a child restraint must be located after reading this instruction manual and installed so that they are not liable during everyday use of the vehicle by becoming trapped by a movable seat or in a door of the vehicle. COZY N SAFE...
  • Page 10 E S T - 5 0 8 C a r S e a t P A R T S Headrest Backrest Slot Harness Chest pad Buckle Comfort pad Seat cushion Harness adjuster lever Harness adjuster strap COZY N SAFE...
  • Page 11 E S T - 5 0 8 C a r S e a t P A R T S Red button (adjust the headrest height) Diagonal belt hook Diagonal belt hook Belt lock (only used 15-36kg) Harness straps Seats belt route slots Seats belt route slots Harness connector COZY N SAFE...
  • Page 12 E S T - 5 0 8 C a r S e a t Safety Instruction Only suitable if the approved vehicles are fitted with 3 point safety-belts, approved to UN/ECE Regulation No.16 or other equivalent standards. COZY N SAFE...
  • Page 13 E S T - 5 0 8 C a r S e a t CORRECT SHOULDER STRAPS HEIGHT Always check that the shoulder straps are at the correct height for your child. The child's shoulders should always be below the slot for the harness. COZY N SAFE...
  • Page 14 E S T - 5 0 8 C a r S e a t CHANGING THE SHOULDER STRAP HEIGHT COZY N SAFE...
  • Page 15 Then from the front of the seat, pull the harness through the slot in the backrest and fabric cover. Thread the harness strap back through the next hole up or down on the seat backrest. COZY N SAFE...
  • Page 16 Re-thread the harness strap back onto the harness connector at the back of the seat. Repeat the same process for the other harness strap. Make sure both of he straps go through slots at the same height. COZY N SAFE...
  • Page 17 E S T - 5 0 8 C a r S e a t REMOVING THE SAFETY HARNESS SHOULDER STRAPS COZY N SAFE...
  • Page 18 Release the strap at the bottom of the backrest cover to gain access to the harness. Slide both of the harness straps off the harness connector at the back of the backrest and pull the webbing through the slots in the seat backrest and fabric cover. COZY N SAFE...
  • Page 19 E S T - 5 0 8 C a r S e a t REMOVING THE SAFETY HARNESS LAP STRAPS Turn the webbing retainers on their narrowest end and feed them though the slots in the base of the seat and then through the slots in the fabric cover. COZY N SAFE...
  • Page 20 FASTENING THE SAFETY SEAT BUCKLE Step 1. Slot the two metal sections of the buckle connectors together. Step 2. Slot the two buckle connectors into the slot in the top of the buckle until they click into place. COZY N SAFE...
  • Page 21 E S T - 5 0 8 C a r S e a t FASTENING THE SAFETY SEAT BUCKLE Step 3. Always check the harness is correctly locked by pulling the shoulder straps upwards. To release the harness press the red button on the buckle downwards. COZY N SAFE...

  • Page 22: Tightening The Harness

    The harness should be adjusted as tightly as possible without causing discomfort to your child. COZY N SAFE...
  • Page 23 Ensure that the lap strap portion of the harness is located as low as possible towards the thighs and not around the stomach. A loose harness can be dangerous. Check the harness adjustment and tighten each time the child is placed in the seat. COZY N SAFE...
  • Page 24 Pull the shoulder straps towards you to loosen the harness. Take care when you adjust the shoulder straps that you do not trap the harness adjuster straps as you press the lever down. COZY N SAFE...
  • Page 25 E S T - 5 0 8 C a r S e a t FITTING THE CAR SEAT WITH 3-POINT LAP & DIAGONAL SEAT BELT Step 1. Place the child safety seat on the vehicles seat ensuring it is firmly pressed against the car seat backrest. COZY N SAFE...
  • Page 26 Thread car seat belt out through the other seat belt route slot and fasten it into the seat belt buckle. COZY N SAFE...
  • Page 27 LAP & DIAGONAL SEAT BELT Step 3. Check that the harness of the seat belt has not become twisted or tangled. Ensure that the lap belt goes under the armrest and the diagonal on the side of the backrest. COZY N SAFE...
  • Page 28 FITTING THE CAR SEAT WITH 3-POINT LAP & DIAGONAL SEAT BELT Step 4. Place your knee on the base of the safety seat and grip the top piece of the seat harness. pull the harness upwards to tighten the seat belt. COZY N SAFE...
  • Page 29 Make sure the seat belt has not become twisted. Also check that the cover is in not impeding the movement or fit of the seat harness in any way. To release your child seat follow the above instructions in reverse order. COZY N SAFE...
  • Page 30 E S T - 5 0 8 C a r S e a t FITTING THE CAR SEAT USING THE BELT LOCK Step 1. Put the red belt hook go through the upmost belt hole of backrest. Place the child seat on the vehicle against the car seat backrest. COZY N SAFE...
  • Page 31 E S T - 5 0 8 C a r S e a t FITTING THE CAR SEAT USING THE BELT LOCK Step 2. Place the child in the child safety seat, The position of red belt hook should be adjusted to the height of the child. COZY N SAFE...
  • Page 32 Check that the webbing has not become twisted and tighten the seat belt by pulling the diagonal strap upwards COZY N SAFE...
  • Page 33 THE BELT LOCK Step 4. Feed the diagonal portion of the seat belt through the seat belt lock (see fastening the seat belt lock section) and check that all of the slack has been removed from the seat belt. COZY N SAFE...
  • Page 34 Recommended for use by children from 22kg to 36kg (approximately 7 years to 11 years) IMPORTANT: Before fitting the seat remove the backrest. Step 1. Rotate the backrest to the horiaontal position. Step 2. Pull out the backrest from the base. COZY N SAFE...
  • Page 35 1. Push the booster cushion firmly into position in the desired car seating position. Then sit your child on the booster cushion. The position of red belt hook should be adjusted to the height of the child's shoulder. COZY N SAFE...
  • Page 36 3. Ensure there is no slack or twists in the seat belt. All seat belts should be secure without causing discomfort to your child. 4. To clean the booster cushion remove the cover from moulding and follow the instructions on the label. COZY N SAFE...

  • Page 37: Care And Maintenance

    Slide the cover off. The covers can now be cleaned. THE COVER SHOULD BE HAND WASHED. Use only a mild hand soap and warm water. Do not use chemical cleaners and never attempt to bleach or dye the webbing. Allow to dry naturally. COZY N SAFE...
  • Page 38 COZY N SAFE w w w . c o z y n s a f e . c o m E u r o S t o c k T r a d e r s L t d C o z y N S a f e O x f o rd S t r e e t , W o l v e r h a m p t o n , W e s t M i d l a n d s , W V 1 4 7 D P , U .
