Summary of Contents for Cozy N Safe Apache EST-09
- Page 1 COZY N SAFE A P A C H E I N S T R U C T I O N M A N U A L E S T - 0 9 G r o u p 2 / 3...
- Page 2 3. This child restrain has been classified as “Universal” under more stringent condi�ons than those which applied to earlier designs which do not carry this no�ce. 4. If in doubt, consult either the child restraint manufacturer or the retailer. COZY N SAFE...
- Page 3 E S T - 0 9 C a r S e a t Only suitable if the approved vehicles are fi�ed with 3 point safety belts, approved to UN/ECE Regula�on No.16 or other equivalent standards. EXTREME HAZARD Do not use in passenger seats equipped with airbags(SRS) COZY N SAFE...
- Page 4 S A F E T Y W A R N I N G S COZY N SAFE...
- Page 5 - Do not use this child seat at home. It has not been designed for home use and should only be used in your vehicle. - The safest sea�ng posi�on for this child in on the rear seat of a vehicle. COZY N SAFE...
- Page 6 - Store this child seat in a safe place when it is not being used. Avoid placing heavy objects on top of it. Do not allow your child seat to come into contact with corrosive substances e.g. Ba�ery acid. COZY N SAFE...
- Page 7 firmly engaged. - It is dangerous to make any altera�ons or addi�ons to the device without the approval of the competent authority, and a danger of not following closely the installa�on provided by the child restraint manufacturer. COZY N SAFE...
- Page 8 - Do not to use any load bearing contact points other than those described in the instruc�ons and marked in the child restraint. COZY N SAFE...
- Page 9 THE TYPE OF APPROVED SEAT BELT YOU MUST HAVE COZY N SAFE...
- Page 10 PASSENGER SEAT OF A CAR THAT HAS AN AIRBAG FITTED.(SRS) Your child seat can only be installed forward facing using a three-point lap and DIAGONAL BELT diagonal seat belt in the front or rear passenger seats of the car. LAP BELT COZY N SAFE...
- Page 11 CHILD CAR SEAT PARTS COZY N SAFE...
- Page 12 E S T - 0 9 C a r S e a t Headrest Backrest Booster seat Bu�on (headrest height adjustment) Instruc�ons for use Joint COZY N SAFE...
- Page 13 ATTACHING THE BACKREST COZY N SAFE...
- Page 14 - Pull the backrest into an upright posi�on (B & C). Danger! When pulling up the backrest, nothing must come between the backrest and the seat cushion in the area of the joint. Cau�on! Please keep your fingers away from the joint to prevent injury. COZY N SAFE...
- Page 15 E S T - 0 9 C a r S e a t COZY N SAFE...
-
Page 16: Headrest Height
ADJUSTING THE HEADREST HEIGHT COZY N SAFE... - Page 17 finger whilst simultaneously li�ing the headrest with your le� (or right) hand. Step 3. Move the headrest up and down as needed to ensure that the posi�on is correct for your child. COZY N SAFE...
- Page 18 FITTING THE CAR SEAT COZY N SAFE...
- Page 19 FITTING THE CAR SEAT USING THE BELT GUIDE Step 1. Place the safety seat on the vehicle’s seat ensuring it is firmly pressed against the car backrest. Step 2. Place the child in the child safety seat. COZY N SAFE...
- Page 20 Make sure the seat belt has not become twisted. Also check that the cover is not impending the movement or fit of the seat belt webbing in any way. To release your child, simply unfasten the seat belt in the normal way. COZY N SAFE...
- Page 21 E S T - 0 9 C a r S e a t BOOSTER SEAT 22-36kg Group 3 IMPORTANT:Remove the seat backrest COZY N SAFE...
- Page 22 FITTING THE CAR SEAT USING THE BELT GUIDE Step 1. Place the booster on the seat of the vehicle ensuring it is firmly against the vehicles seat and back rest. Step 2. Place the child in the child safety seat. COZY N SAFE...
- Page 23 Make sure the seat belt has not become twisted. Also check that the cover is not impending the movement or fit of the seat belt webbing in any way. To release your child, simply unfasten the seat belt in the normal way. COZY N SAFE...
- Page 24 2. Cleaning Use only neutral detergent and warm water to wash, do not wash by machine. Spin-dry or tumble dry are not recommended. THE COVER SHOULD BE HAND WASHED ONLY. • • • • • COZY N SAFE...
-
Page 25: Procedure After An Accident
1. The child car seat must be replaced when it has been subjected to violent stresses in an accident. 2. Correctly install the child car seat according to the instruc�on manual. 3.Do not remodel or alter the car seat in any way as this may be dangerous. COZY N SAFE... - Page 26 NA ME : .............. COZY N SAFE D A T E O F BIR TH (DD/M M /Y YY Y ) : .
