C S
COZY N SAFE
R
J E F F E R S O N
I N S T R U C T I O N M A N U A L
E S T - 2 1 8
G r o u p 1 / 2 / 3
9 k g t o 3 6 k g
( A p p r o x i m a t e l y 1 y e a r - 1 1 y e a r s )
E C E R 1 6 N o 4 4 . 0 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the Jefferson and is the answer not in the manual?

Questions and answers

Summary of Contents for Cozy N Safe Jefferson

  • Page 1 COZY N SAFE J E F F E R S O N I N S T R U C T I O N M A N U A L E S T - 2 1 8 G r o u p 1 / 2 / 3...
  • Page 2 fit most, but not all car seats. 2. A correct fit is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle is capable of accepting a “Universal” child restraint for this age group. COZY N SAFE...
  • Page 3 4. If in doubt, consult either the child restraint manufacturer or the retailer. Only suitable if the vehicle is fitted with 3-point safety belts, Approved to UN/ECE Regulation No.16 or other equivalent standards. COZY N SAFE...
  • Page 4 S A F E T Y W A R N I N G S COZY N SAFE...
  • Page 5 2. This instruction manual can be kept in the allocated space on the child seat for its life period. 3. Do not use this child seat in the home. It has not been designed for home use and should only be used in your car. COZY N SAFE...
  • Page 6 7. Always make sure that any straps holding the seat restraint to the vehicle are secure. Any straps restraining the child should be adjusted to the child's body and check that the straps are not be twisted. COZY N SAFE...
  • Page 7 COZY N SAFE...
  • Page 8 14. This child seat is designed for children from 9kg to 36kg. Never overload the child seat more than one child or with other loads. 15. The child restraint must not be used without the cover. COZY N SAFE...
  • Page 9 18. The child seat should be kept away from sunlight if the seat is not provided with a textile, otherwise it may be too hot for the child's skin. 19. Never use a second-hand product as you can never be certain what was happened to it. COZY N SAFE...
  • Page 10 E S T - 2 1 8 C a r S e a t Notice: Do not use in any configuration not shown in the instructions. COZY N SAFE...
  • Page 11: Safety Instruction

    E S T - 2 1 8 C a r S e a t Safety Instruction Only suitable if the approved vehicles are fitted with 3 point safety-belts, approved to UN/ECE Regulation No.16 or other equivalent standards. COZY N SAFE...
  • Page 12 NOTICE Belt in this location. Unable to install the position. Do not install the child safety seat at the front seat with air bag. Only with the three point safety belt, can this location. COZY N SAFE...
  • Page 13 E S T - 2 1 8 C a r S e a t P A R T S COZY N SAFE...
  • Page 14 E S T - 2 1 8 C a r S e a t P A R T S Locking clip COZY N SAFE...
  • Page 15 E S T - 2 1 8 C a r S e a t Scope of application for children GROUP 1 It is suitable for the weight 9-18 kg, given to children approximately 1 year - 4 years old. COZY N SAFE...
  • Page 16 E S T - 2 1 8 C a r S e a t Scope of application for children GROUP ll, lll It is suitable for the weight 15-36 kg, given to children approximately 4 years - 11 years old. COZY N SAFE...
  • Page 17 E S T - 2 1 8 C a r S e a t How to place the safety seat Note: In order to keep safe, place the restraint system on the back seat and ensure that the backrest is pushed up against the car seat. COZY N SAFE...
  • Page 18 G R O U P COZY N SAFE...
  • Page 19 Step 1: Place the child safety seat on the vehicle seat. Pull out the diagonal belt together with lap belt, pass through the belt route slot of backrest(A1, A2). Step 2: Insert the belt into the car seat belt buckle until you hear a “CLICK”. COZY N SAFE...
  • Page 20 E S T - 2 1 8 C a r S e a t Installing the safety car seat (9kg to 18kg) COZY N SAFE...
  • Page 21 E S T - 2 1 8 C a r S e a t Installing the safety car seat (9kg to 18kg) Step 3: Clip the diagonal belt into the locking clip(A3, A4). COZY N SAFE...
  • Page 22 E S T - 2 1 8 C a r S e a t Installing the safety car seat (9kg to 18kg) Notice! Please refer to the following picture. Clip the safety belt into the locking clip in the right way(A5). COZY N SAFE...
  • Page 23 E S T - 2 1 8 C a r S e a t Installing the safety car seat (9kg to 18kg) Step 4: Pull car seat belt in the direction of red arrow and make sure the belt is tight and secure (A6, A7). COZY N SAFE...
  • Page 24 E S T - 2 1 8 C a r S e a t Securing the child in the safety car seat (9kg to 18kg) Step 1: Loosen the harness. COZY N SAFE...
  • Page 25 E S T - 2 1 8 C a r S e a t Securing the child in the safety car seat (9kg to 18kg) Step 2: Release the buckle COZY N SAFE...
  • Page 26 E S T - 2 1 8 C a r S e a t Securing the child in the safety car seat (9kg to 18kg) Step 3: Put the child into the safety car seat. COZY N SAFE...
  • Page 27 E S T - 2 1 8 C a r S e a t Securing the child in the safety car seat (9kg to 18kg) Step 4: Pull the height adjuster to adjust the height of the harness and headrest according to the child’s height(A11). COZY N SAFE...
  • Page 28 E S T - 2 1 8 C a r S e a t Securing the child in the safety car seat (9kg to 18kg) Note! The height for the harness is adjusted by lifting the headrest(A12) COZY N SAFE...
  • Page 29 E S T - 2 1 8 C a r S e a t Securing the child in the safety car seat (9kg to 18kg) Step 5: Align the left and right buckle tongues to one tongue and insert into the buckle until you hear“Click”. COZY N SAFE...
  • Page 30 Step 6: Pull the shoulder straps upwards to remove the slack from the lap sections of the harness then pull the adjuster strap until the harness is fully tightened. Ensure that your child is comfortable and secure. COZY N SAFE...
  • Page 31 G R O U P 2 & 3 COZY N SAFE...
  • Page 32 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 1: Loosen the harness. COZY N SAFE...
  • Page 33 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 2: Release the buckle. COZY N SAFE...
  • Page 34 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 3: Slide both of the harness straps off the harness connector. COZY N SAFE...
  • Page 35 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 4: Pull out the shoulder belt. COZY N SAFE...
  • Page 36 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 5: Pull out the harness from the slot which is under the safety car seat. COZY N SAFE...
  • Page 37 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 6: Keep the cushion and accessories in a safe place. COZY N SAFE...
  • Page 38 E S T - 2 1 8 C a r S e a t Remove the buckle and car seat pad cushion (18kg to 36kg) Step 7: Remove the shoulder straps from the safety car seat(B7, B8). COZY N SAFE...
  • Page 39 E S T - 2 1 8 C a r S e a t Installing the safety car seat (18kg to 36kg) Step 1: Let the lap belt go through under the armest(B9, B10) COZY N SAFE...
  • Page 40 E S T - 2 1 8 C a r S e a t Installing the safety car seat (18kg to 36kg) Step 2: The diagonal belt must go through the belt guide on the side of the headrest and under the armest closest to the buckle. COZY N SAFE...
  • Page 41 The gap between head belt guide and baby should be 2 fingers width. The harness straps should be level with or just above the child’s shoulders (B12, B13). COZY N SAFE...
  • Page 42 E S T - 2 1 8 C a r S e a t Installing the safety car seat (18kg to 36kg) COZY N SAFE...
  • Page 43 Installing the safety car seat (18kg to 36kg) Step 4: Fasten car seat belt and make sure it is secure. Important: Ensure that any lap straps is worn low down so that the pelvis is firmly engaged. COZY N SAFE...
  • Page 44: Maintenance And Cleaning

    Maintenance Cleaning COZY N SAFE...
  • Page 45: Daily Maintenance

    4. If food or drink droped accidently on the buckle, disassemble the seat belt from the child seat and rinse it COZY N SAFE...
  • Page 46: Washing Instruction

    Washing instruction Never use any solvant, clemical detergent or lubricant on any part of your child seat. Do not tumble Do not iron Hand wash, Do not bleach Dryclean, any water solvent except temperature trichloroethylene below 30℃ COZY N SAFE...
  • Page 47 1. Remove the crotch pad and buckle of the child seat. Remove the shoulder straps and insert cushion. 2. Remove the fabric cover of the child seat. To re-cover your car seat please follow the above instructions in reverse order. COZY N SAFE...
  • Page 48 COZY N SAFE w w w . c o z y n s a f e . c o m E u r o S t o c k T r a d e r s L t d C o z y N S a f e O x f o rd S t r e e t , W o l v e r h a m p t o n , W e s t M i d l a n d s , W V 1 4 7 D P , U .
