Cozy N Safe EST-309 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
C S
COZY N SAFE
R
F I T Z R O Y
I N S T R U C T I O N M A N U A L
E S T - 3 0 9
G r o u p 0 + / 1
B i r t h t o 1 8 k g
( A p p r o x i m a t e l y B i r t h - 4 y e a r s )
E C E R 1 6 N o 4 4 . 0 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the EST-309 and is the answer not in the manual?

Questions and answers

Related Manuals for Cozy N Safe EST-309

Summary of Contents for Cozy N Safe EST-309

  • Page 1 COZY N SAFE F I T Z R O Y I N S T R U C T I O N M A N U A L E S T - 3 0 9 G r o u p 0 + / 1...
  • Page 2 2. A correct fit is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle is capable of accepting a “Universal” child restraint for this age group. 3. This child restraint has been classified as “Universal” COZY N SAFE...
  • Page 3 4. If in doubt, consult either the child restraint manufacturer or the retailer. Only suitable if the vehicle is fitted with 3-point safety belts, Approved to UN/ECE Regulation No.16 or other equivalent standards. COZY N SAFE...
  • Page 4 flame retardance fabric, wear-resistant, soft, antibacterial, and there are a variety of colors. 2. The backrest of this product can be adjusted to 4 different incline positions for the child to sit in during travel. COZY N SAFE...
  • Page 5 3. This product comes with 3 positions for adjusting the height of the shoulder straps to meet the needs of your child. 4. This child seat can only be used for children 0-4 years old(approx), installed rearward-facing or forward-facing. COZY N SAFE...
  • Page 6 S A F E T Y W A R N I N G S COZY N SAFE...
  • Page 7 18kg in weight (group 0+, less than 13kg ; group l, 9-18kg). 2. This child can be installed rearward-facing and forward-facing using a three-point lap and diagonal seat belt. Important - Do not use forward-facing before the child's weight exceeds 9kg. COZY N SAFE...
  • Page 8 5. It is recommended that children are not left in their child restraint system unattended. 6. Do not place rear-facing child seat on front seat with airbag. Death or serious injury can occur. COZY N SAFE...
  • Page 9 Any straps restraining the child should be adjusted to the child's body and check that the straps are not twisted. 10. Ensure that any lap straps is worn low down, so that the pelvis is firmly engaged. COZY N SAFE...
  • Page 10 14. To prevent from the risk of fall, your child should always be fastened. COZY N SAFE...
  • Page 11 16. This child seat is designed for children from birth up to 18kg. Never overload the child seat with more than one child or with other loads. 17. The child restraint must not be used without the cover. COZY N SAFE...
  • Page 12 20. The child seat should be kept away from sunlight if the seat is not provided with a textile, otherwise it may be too hot for the child's skin. 21. Never use a second-hand product as you can never be certain what was happened to it. COZY N SAFE...
  • Page 13 E S T - 3 0 9 C a r S e a t P A R T S Headrest Backrest Chest pad Comfortable cushion Buckle Crotch pad Belt route slot group 1 Adjuster Belt route slot (Under the cover) group 0+ Harness adjuster strap positioning handle COZY N SAFE...
  • Page 14 E S T - 3 0 9 C a r S e a t P A R T S Belt guide hook Lock off Shoulder strap slot Harness Harness Belt route slot Connector group 1 Manual Belt route slot storage tank group 0+ Base COZY N SAFE...
  • Page 15 3 point seat belts that are fitted in accordance with European standard (ECE 44 or equivalent standard) Important: The child seat must only be installed using a lap and diagonal seat belt. COZY N SAFE...
  • Page 16 Install position of the child seat in vehicle Corect fitting/suitable Incorrect fitting/not suitable Not to be used on this seat if a passenger front airbag is active Only use on this seat if a lap and diagonal seat belt is fitted. COZY N SAFE...
  • Page 17 Always check that the shoulder straps are at the correct height for your child. The child’s shoulders should always be thread through the slots in the cover and seat shell that are closest to the top of your child’s shoulders. NO-Too low NO-Too high YES-Correct COZY N SAFE...
  • Page 18 E S T - 3 0 9 C a r S e a t USAGE OF BUCKLE Firstly, adjust the shoulder straps height, please proceed as follows: Step 1. Put the two metal sections of the buckle connector together. COZY N SAFE...
  • Page 19 E S T - 3 0 9 C a r S e a t USAGE OF BUCKLE Step 2. Slot the two buckle connectors into the slot in the buckle until they “click” place. COZY N SAFE...
  • Page 20 USAGE OF BUCKLE Step 3. Check the harness is correctly locked by pulling the shoulder straps upward. To release the harness, you can press the red button of the buckle downwards, the two metal sections will be pop up. COZY N SAFE...
  • Page 21 (under the adjuster cover) on the front of the seat. Press down the adjuster as you grip the two shoulder straps with your another hand. Pull the shoulder straps towards you to loosen the harness. COZY N SAFE...
  • Page 22 The harness should be adjusted as tightly as possible without causing discomfort to your child. A loose harness can be dangerous. Check the harness adjuster and tighten each time the child is placed in the seat. COZY N SAFE...
  • Page 23 4 can be used. Pull the CLICK positioning handle under the front of the seat upward, and then pull or push the seat forwards or backwards. Release the positioning handle in the desired position and push until you hear a “click”. COZY N SAFE...
  • Page 24 E S T - 3 0 9 C a r S e a t Adjust the child seat to different incline positions 1 2 3 Before adjusting After adjusting Important: Check to make sure the child seat is securely locked in the desired position by pulling the positioning handle. COZY N SAFE...
  • Page 25 Side the chest straps and shoulder straps off the harness connectors. Step2. Pull the straps through the shoulder strap slots from the front of the child seat. Now you can remove the shoulder straps and chest pad. COZY N SAFE...
  • Page 26 Important: Make sure that both of the shoulder belts and chest belt go through slots at the same height, and not twisted. COZY N SAFE...
  • Page 27 Turn the harness locking clip on their narrowest end and thread it through the slot under the bottom of the child seat. The crotch pad and buckle as well as harness straps can now be removed. COZY N SAFE...
  • Page 28 G R O U P COZY N SAFE...

  • Page 29: Installation Of The Child Seat

    E S T - 3 0 9 C a r S e a t Installation of the child seat （Birth to 13kg) This child seat can be used with the harness for children less 13kg in weight (group 0+), installed rearward facing using a three-point lap and diagonal seat belt. COZY N SAFE...
  • Page 30 Step 1. Adjust the child seat to position 4. place the child seat on the car seat rearward -facing and make sure that the front of the child seat is firmly pressed against the car seat backrest. COZY N SAFE...
  • Page 31 E S T - 3 0 9 C a r S e a t Installation of the child seat （Birth to 13kg) Step 2. Pull out the diagonal belt together with lap belt, through the belt route slot of backrest and then insert into car seat belt buckle, hear “click”. COZY N SAFE...
  • Page 32 E S T - 3 0 9 C a r S e a t Installation of the child seat （Birth to 13kg) Step 3. Clip the diagonal belt into the blue and red lock-off in same side. Thread the lap belt through belt route slot (group 0+). COZY N SAFE...
  • Page 33 E S T - 3 0 9 C a r S e a t Installation of the child seat （Birth to 13kg) Step 4. Thread the lap belt through belt route slot (group 0+) of other side. COZY N SAFE...
  • Page 34 Step 5. Pull car seat belt in the direction of red arrows and make sure the belt is tight and secure. Then put the child into the seat and fasten the harness. Check that the harness is not twisted. COZY N SAFE...
  • Page 35 G R O U P COZY N SAFE...
  • Page 36 E S T - 3 0 9 C a r S e a t Installation of the child seat （9kg to 18kg) This child seat can be used with the harness for children 9kg to 18kg in weight(group 1), installed forward-facing using a three-point lap and diagonal seat belt. COZY N SAFE...
  • Page 37 （9kg to 18kg) Step 1. Adjust the child seat to position. Place the child seat on the car seat forward-facing and make sure the backrest of the seat is firmly pressed against the backrest of car seat. COZY N SAFE...
  • Page 38 Installation of the child seat （9kg to 18kg) Step 2. Pull out the diagonal belt together with lap belt, pass through the belt route slot of backrest and then insert into car seat belt buckle, hear “click”. COZY N SAFE...
  • Page 39 E S T - 3 0 9 C a r S e a t Installation of the child seat （9kg to 18kg) Step 3. Clip the diagonal belt into the red lock-off. Thread the lap belt through belt route slot (group1). COZY N SAFE...
  • Page 40 Installation of the child seat （9kg to 18kg) Step 4. Thread the lap belt through belt route slot(group1) of other side. Pull car seat belt in the direction of arrows and make sure the belt is tight and secure. COZY N SAFE...
  • Page 41 E S T - 3 0 9 C a r S e a t （9kg to 18kg) Step 5. Put the child into the seat and fasten the harness. Check that the harness does not twist. NOTICE: is only suitable for forward-facing COZY N SAFE...

  • Page 42: Maintenance And Cleaning

    Maintenance Cleaning COZY N SAFE...

  • Page 43: Daily Maintenance

    4. If food or drink is dropped accidently on the buckle, disassemble the seat belt from the child seat and rinse it COZY N SAFE...
  • Page 44 Leave it to dry naturally. Never use any solvant, clemical detergent or lubricant on any part of your child seat. Do not tumble Do not iron Hand wash, Do not bleach Dryclean, any water solvent except temperature trichloroethylene below 30 COZY N SAFE...
  • Page 45 COZY N SAFE w w w . c o z y n s a f e . c o m E u r o S t o c k T r a d e r s L t d C o z y N S a f e O x f o rd S t r e e t , W o l v e r h a m p t o n , W e s t M i d l a n d s , W V 1 4 7 D P , U .
