LED MATRIX MOVING HEAD LIGHT
MJ-1027A
User Manual
PROFESSIONAL STAGE LIGHTING
======
========
Thank you for choosing our LED matrix moving head light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place for future
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MJ-1027A and is the answer not in the manual?

Questions and answers

Related Manuals for MJ LED LIGHTNING MJ-1027A

Summary of Contents for MJ LED LIGHTNING MJ-1027A

  • Page 1 LED MATRIX MOVING HEAD LIGHT MJ-1027A User Manual PROFESSIONAL STAGE LIGHTING ====== ======== Thank you for choosing our LED matrix moving head light. For the sake of your safety, Please read and follow these instructions carefully and keep this manual in a safe place for future...

  • Page 2: Table Of Contents

    Catalogue Chapter Page Safe Usage Of The Product -----------------------------------------------------------------------------------------3 Install The Equipment ------------------------------------------------------------------------------------------------4 Power Code Connection ---------------------------------------------------------------------------------------------4 DMX Connection ------------------------------------------------------------------------------------------------------5 DMX Terminator -------------------------------------------------------------------------------------------------------5 Function Set --------------------------------------------------------------------------------------------------------------6 Operation Menu ---------------------------------------------------------------------------------------------------------6 Maintenance --------------------------------------------------------------------------------------------------------------7 Keeping The Product Clean ------------------------------------------------------------------------------------------7 Trouble Shooting ---------------------------------------------------------------------------------------------------------7 Equipment and Appendix ----------------------------------------------------------------------------------------------7 Channel List ---------------------------------------------------------------------------------------------------------------8...

  • Page 3: Safe Usage Of The Product

    SAFE USAGE OF THE PRODUCT When unpacking and before disposing of the carton, check there is no transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The product is for indoor use only, IP20.

  • Page 4: Install The Equipment

    Install The Equipment: Use 2pcs clamp and safety cord(need to purchase).Use clamp fix with light hook which in the packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure and fasten the screws attached to each clamp. Make sure the light is installed reliable, and confirm the light which you fixed is strong enough for hanging the light.

  • Page 5: Dmx Connection

    DMX Connection: Connection between the controller and a projector and between one projector and another must be made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to and from the projector is via cannon 3 pin (which are included with the projector) XLR plugs and sockets.

  • Page 6: Function Set

    Function Set: A．MENUs B．UP C．DOWN D．ENTER Instructions: Press the function key A will cycle out of different functional effects, digital tube in which the first two digits represent the current function (see Menu). After two figures represent the kinds of functions are located. Address code. Or speed parameters. Press B or C keys to modify its parameters.

  • Page 7: Maintenance

    Maintenance: To prolong the life of the projector, some maintenance work has to be done to ensure the LED optical system in good condition. If the projector does not function, check the fuses on the power socket of the projector, they should only be replaced by fuses of the same specification. Should these be damaged, call a qualified technician before replacement.

  • Page 8: Channel List

    Channel List: 19CH MODE Channel Function value Details Pan movement 0-255 0-540 degree 0-55 Pan non movement Unlimited Pan 56-155 Pan unlimited clockwise rotate slow to fast movement 156-255 Pan unlimited reversely rotate slow to fast Tilt movement 0-255 0-270 degree 0-55 Tilt non movement Unlimited Tilt...
  • Page 9 29CH MODE Channel Function value Details Pan movement 0-255 0-540 degree 0-55 Pan non movement Unlimited Pan 56-155 Pan unlimited clockwise rotate slow to fast movement 156-255 Pan unlimited reversely rotate slow to fast Pan fine 0-255 16 bit Pan fine adjustment Tilt 0-255 0-270 degree...
  • Page 10 0-49 No function 50-74 Numbers and punctuations show(Against CH22) 75-99 Letters show(Operate against CH 23) CH28 Macro Function 100-124 Static gobos show(Operate against CH 24) 125-149 Dynamic gobos show(Operate against CH 26) 150-199 Auto Run 200-255 Sound activated 0-250 No function CH29 Reset 251-255...

  • Page 11: Technical Parameters

    0-234 Effect show of static gobos Effect show of static CH112 gobos 234-235 Running water effect CH113 Color of letters 0-255 Color choice for the letters 0-234 Effect show of dynamic gobos CH114 Dynamic gobos show 234-235 Running water effect CH115 Speed of effects 0-255...
