ELTA FANS Revolution SLC Series Installation & Maintenance page 7

REVOLUTION SLC
Wiring Diagrams
Please use the table(s) below to match up the product code and the wiring diagram number.
Single Phase 220V - 277V / 50Hz or 60Hz
Page
No.
10 SLC315-1EC
10 SLC355-1EC
10
SLC400-1EC
10 SLC450-1EC
10 SLC500-1EC
10 SLC560-1EC
10
SLC630-1EC
Elta Fans Limited has a policy of continuous product development and improvement and therefore reserves the right to supply products which may differ from those illustrated and described in this publication.
Confirmation of dimensions and data will be supplied on request.
Product Wiring
Code Diagram No.
152-710
152-710
152-710
152-710
152-710
152-710
152-710
EC
