ELTA FANS Revolution SLC Series Installation & Maintenance page 10

152-601
Wiring Diagrams
MK-152-601
All wiring and control equipment must comply to the latest IEE regulations, in particular part 552-01-02/03.
MK-152-601 Issue B: 15.07.2013
Check the individual product accessories table for fan controller compatibility.
10
FIXED SPEED CONNECTION
W2 U2 V2
FAN TERMINAL
BOX
U1
V1 W1
L1 L2 L3 E
380 - 440V 3PH 50Hz SUPPLY
3PH
W2 U2 V2
FAN TERMINAL
U1 V1 W1
L3 U V W
L1/L L2/N
L1 L2 L3 E
380 - 440V 3PH 50Hz SUPPLY
3PH
W2 U2 V2
FAN TERMINAL
U1 V1 W1
L3 U V W
L1/L L2/N
L1 L2 L3 E
380 - 440V 3PH 50Hz SUPPLY
ALL WIRING AND CONTROL EQUIPMENT MUST COMPLY TO THE
LATEST IEE REGULATIONS, IN PARTICULAR PART 552-01-02/03
Issue: B Saved Date:
Tel 01384 275800
VARIABLE SPEED
W2
U1
E L1 L2
E
L1 L2
380 - 440V 3PH 50Hz SUPPLY
CONNECTED FAN C/W INVERTER
BOX
1: +24V OUTPUT 10 RELAY COMMON
11 RELAY CONTACT
2: STOP/RUN DI1
3: FWD/REV DI2
4: ANALOG/PRESET DI3
5: +10V OUTPUT
6: ANALOG INPUT
7: 0V
1 2 3 4 5 6 7 8 9
ANALOG / DIGITAL
INPUT CONNECTIONS
CONNECTED FAN C/W INVERTER
BOX
1 TO 7 10 RELAY COMMON
PRE - WIRED 11 RELAY CONTACT
1 2 3 4 5 6 7 8 9
ANALOG / DIGITAL
INPUT CONNECTIONS
15/07/2013
Fax 01384 275810
CONNECTION CONTROLLER TYPE TC33, TC35, TC310
U2 V2
FAN TERMINAL
BOX
V1 W1
CONTROLLER
L3 U V W
TERMINAL BOX
L3
3PH - 3PH
IP20 INVERTER
10 11
3PH - 3PH
IP55 INVERTER
10 11
