WL900 INSTALLATION, FILTER FLUSHING, AND SANITIZING PROCEDURES

DANGER!
ELECTRICAL SHOCK HAZARD.
Only qualified personnel who have read and understand this entire manual should
attempt to install, or service this WL900 Water and Ice Machine, failure to do so could
result in death or serious injury. DO NOT plug into an electrical supply until specifically
instructed. Always unplug (isolate from power supply) to prevent electrical shock except
where electrical tests are specified.
WARNING!
ALWAYS SANITIZE BEFORE USE.
Sanitize before use to eliminate any potential microbiological contaminates.
CAUTION!
DRIP TRAY DRAIN.
The WL900 Water and Ice Machine has a built-in, pre-plumbed drain line running from
the drip tray to an external bulkhead. This connection must be completed to a drain for
proper operation.
WARNING!
USE PROPER PERSONAL PROTECTIVE EQUIPMENT
Always ensure proper ventilation and use proper personal protective equipment such as
gloves and eye protection when using chemicals. Refer to Material Safety Data Sheet for
specific requirements of each chemical product. Take all necessary precautions to
prevent sanitizer from contacting eyes, clothing, and any other surfaces in could damage
(carpets).
CAUTION!
HOT CIRCUIT IS NOT SANITIZED.
Water in the hot circuit is not sanitary until the temperature exceeds 77°C (171°F) for at
least 5 minutes.
CAUTION!
INDOOR USE ONLY.
The WL900 Water and Ice Machine has a built-in, pre-plumbed drain line running from
the drip tray to an external bulkhead. This connection must be completed to a drain for
proper operation.
CAUTION!
DRIP TRAY DRAIN.
Never expose to direct sunlight, heat sources, or ambient air temperature above 38°C
(100°F) or below 2°C (35°F). Install indoors and keep unit away from excessive humidity.
Never expose to freezing temperatures. Ensure there is adequate clearance around the
unit to allow refrigeration system condenser to dissipate heat. Warmer environments
require more clearance around the unit. Minimum clearance around all surfaces of the
machine is 2-inches. Installs where the ambient temperature exceeds 80°F, require a
minimum of 4-inches clearance for proper heat dissipation and efficient operation.
CAUTION!
USE UV STABILIZED SUPPLY LINES.
Feed the unit with a potable ambient or cold-water supply only. Feed water over 100° F
(37°C) can damage the treatment components. Water block devices and external leak
detectors are strongly recommended. Locate the unit as close to the water supply and
the electrical connections as possible.
WL900 Manual
Page 42 – Revision: 5-12-2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WL900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WaterLogic WL900

  • Page 1 Only qualified personnel who have read and understand this entire manual should attempt to install, or service this WL900 Water and Ice Machine, failure to do so could result in death or serious injury. DO NOT plug into an electrical supply until specifically instructed.
  • Page 2 Any attempt to circumvent this filtration will cause flooding and damage to the machine and voids the manufacturer’s warranty. 1. Unpack the Waterlogic WL900 Water and Ice Machine and check exterior for damage. 2. Identify the ports on the back of the machine.
  • Page 3 1/4” tubing, and route to drain. In this configuration, water will flush through the first filter slot only and out to drain. CAUTION! FILTER FLUSH REQUIRED. Disconnect, and plumb to drain for filter flushing. MANUAL SHUTOFF VALVE WL900 Manual Page 44 – Revision: 5-12-2021...
  • Page 4 CAUTION! FILTER FLUSH REQUIRED. 8. After the filters have been flushed, the Waterlogic WL900 Water and Ice Machines tanks can be sanitized. To do this, remove the top cover of the machine to access the Ambient Tank. Remove two screws at the back of the machine and the cover should slide back and disengage.
  • Page 5 Connect a section of poly hose to the cold drain and route to a drain and open the cold drain valve. Cold Drain Valve WL900 Manual Page 46 – Revision: 5-12-2021...
  • Page 6 12 cubes are produced every 12 minutes and then the process repeats until the optical ice full sensors are triggered. WL900 Manual Page 47 – Revision: 5-12-2021...
  • Page 7 Water above 52°C (125°F) can cause severe burns or scalding. Hot water should be dispensed carefully into insulated container to avoid injury. 1. To drain the tanks of the Waterlogic WL900 Water and Ice Machine, first shut off water supply to the unit. Remove the lower front panel to access the lower compartment.
  • Page 8 Deactivate the drain switch. This will enable the booster pump, and water will be allowed to flow again through the filters and begin filling the tanks. WL900 Manual Page 49 – Revision: 5-12-2021...
