Read and follow all safety information carefully. The signal words used in this manual are
selected as shown below and based on an assessment of the degree of potential injury or
damage (severe or minor) and the occurrence of injury (definitely occurs or has the potential to
occur) when the warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or
severe injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in
minor injury; and/or minor property damage.
Basic safety precautions should be followed, including the following:
Ensure all Local, State, and Federal Laws and Codes including health and safety guidelines are
met when installing Waterlogic Equipment. Only qualified service technicians should attempt
installation and service of Waterlogic Equipment. Always read the entire operating instructions
before using the appliance and save these instructions for future use.
DANGER!
This product can cause death or severe injury if incorrectly operated, installed or
maintained. The installation, maintenance, sanitizing and any repair must be performed by
qualified persons trained by Waterlogic International or their approved distributors only. Do
not remove any panel or cover to protect against electrical shock and exposure to UV
radiation.
DANGER!
ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly grounded
outlet. Unit should be protected by ground-fault circuit interrupter (GFCI) or residual current
device (RCD) having a rated residual operating current not exceeding 30mA. Use only
Waterlogic supplied power cord. Never use extension cords or power strips to connect unit.
Do not use if the power supply cord is damaged. Always unplug from power supply prior to
servicing.
WARNING!
AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual. Untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can't be used by children and
persons with reduced physical, sensory or mental capabilities or lack of experience.
WARNING!
DO NOT OPERATE IF DAMAGED. Unplug and isolate water supply if abnormal
conditions exist. Contact Waterlogic or authorized dealer for repair, service, and installation
to avoid hazards.
WL900 Manual
SAFETY ALERT SYMBOLS
SAFETY PRECAUTIONS
Page 4 – Revision: 4-14-2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the WL900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WaterLogic WL900

  • Page 1 (RCD) having a rated residual operating current not exceeding 30mA. Use only Waterlogic supplied power cord. Never use extension cords or power strips to connect unit. Do not use if the power supply cord is damaged. Always unplug from power supply prior to servicing.
  • Page 2 CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or damage caused by excessive water pressure. Input or feed pressure must be 40 psi to 60 psi. Be aware of any potential pressure surges caused by building/municipal pumping stations.
  • Page 3 High Volume Storage and Water Capacity The WL900 holds 5.8 Liters of Cold Water, 4.6 Liters of Hot Water, and 17.8 Liters of Ambient Water. It also can hold up to 8lbs of Ice. Float Valve and Flood Prevention The WL900 is supplied with a float valve to provide redundant protection against water damage from leaks.
  • Page 4 Intertek Labs (ETL) Certified the Waterlogic WL900 Water and Ice Machine to ANSI/UL 399 Standard for Drinking Water Coolers. CSA C22.2 No. 120 - Refrigeration Equipment Intertek Labs (ETL) certified the Waterlogic WL900 Water and Ice Machine to CSA C22.2 No. 120 Standard for Refrigeration Equipment. UL 563 - Ice Makers Intertek Labs (ETL) certified the Waterlogic WL900 Water and Ice Machine to ANSI/UL 563 Standard for Ice Makers.
  • Page 5: Specifications

    MODEL/PART DESIGNATIONS MODEL - BRAND NAME DESCRIPTION PART NUMBER Waterlogic WL900 – Hot, Cold, Ambient and Ice WL900 21-IG900-B Serial Number Prefix: Z10493-(YYMMDD)-00392 SPECIFICATIONS ITEM WL900 Water Connection 1/4” Quick Connect Cold Water Temperature 3°C (38°F) Cold Tank Size 5.8 L Hot Water Temperature 85°C (185°F)
  • Page 6: Shipping Specifications

    59” 19.5” 17” ELECTRICAL SPECIFICATIONS ELECTRICAL SUPPLY 120V/60Hz, 1PH 15 Amp Service COMPONENT POWER (approximate) AMP DRAW (approximate) Heater 500W 4.1A Compressor 120W 1.2A Ice Making Process 120W 1.2A WL900 TOTAL 780W 6.5A WL900 Manual Page 9 – Revision: 4-14-2021...
  • Page 7 OPERATING INSTRUCTIONS The above picture shows the front user interface (UI) and control panel for the Waterlogic WL900 Water and Ice Machine. The three water selection buttons control what temperature water is dispensed (hot, cold, or ambient). Dispense Water: Press the desired selection button (LED should light up once selected) and then press cup or container into the dispensing button mounted to the dispensing area backsplash until water begins to flow.
  • Page 8 This is not used for normal operation. Only for maintenance use by a trained professional. ECO SENSOR Light detection sensor. Works with Eco-mode on older models, but is DISABLED on the WL900. ICE FULL LIGHT Illuminates white when ice bin is full. WATER FULL LIGHT Illuminates when the Ambient Tank is full.
  • Page 9 (48) months from the date of manufacture. Waterlogic Commercial Products, LLC (“Waterlogic”) based in the U.S.A. and its affiliated companies are not liable for any cost of removal, installation, transportation, or any other charges which may arise in connection with a warranty claim.
