Cabletron Systems STS-5SU Install Manual page 2

Menu Parameter
IP Configuration IP Address, IP Gateway, IP Subnet, IP
State
Spanning Tree STP Enabling/Disabling, STP Switch
Priority, STP Maximum Aging, STP
Hello Time, STP Forward Delay
Virtual LAN Changing VLAN names
Name
Configuration
Password System password
Console Console Time-out
Configuration
Telnet Number of Allowed Telnet Sessions,
Configuration Disallow New Telnet Sessions
TFTP Download TFTP Server Address, Download
Domain, Download Filename
Switch/Stack Stack Timeout, System Name, System
Information Contact, System Location
SNMP Send Authentication Traps, changing
Configuration the Trap table in any way, changing the
Community Name table in any way
Table 3. Inter-Box Parameters
Checking the Installation
The SmartStack Token Ring Switch performs a diagnostic
self-test during the power on cycle. From a management
console, check that the switch lists the SmartStack STS-5SU
port along with the switch ports and that there are no error
messages. The SmartStack STS-5SU port will be listed as port
29.
If, after installation, there is poor system performance or the
SmartStack STS-5SU module does not work at all, remove the
module and check for any damaged or bent connector pins.
You may need a bright light to see inside the stacker slot to
check for bent pins. Also, verify that the module is set firmly
in place.
Getting in Touch With Technical Support
For additional support related to this device or document,
contact Cabletron Systems using one of the following
:
methods
World Wide Web http://www.cabletron.com/
Phone (603) 332-9400
Internet mail support@cabletron.com
FTP ftp://ftp.cabletron.com/
anonymous
Login
Password your email address
To send comments or suggestions concerning this
document, contact the Cabletron Systems Technical
Writing Department via the following email
address: TechWriting@cabletron.com
Make sure to include the document Part Number in the
email message.
