1.1 Function Specifi cation
Item
(1) Model
(2) Product Code
(3) Management Range
(4) Control Function
(5) Monitor
(6) Display Format
(7) Schedule
(8) Displayed Item for
Usage History
(9) External In/Output
(10) History
*1. Required only when the system consists of multiple H-LINKs
*2. Required only for calculating electricity
*3. No restriction on the number of H-LINK
*4. Some indoor units may not fully support all functions.
*5. Available for applicable indoor units only
*6. This is the air intake temperature on representative outdoor unit.
TC-19001
VRF Central Touchscreen Controller: CCLX01
VRF Central Touchscreen Controller Adapter: CCXLA01 *1
Energy Calculation Software: CCSE01 *2
VRF Central Touchscreen Controller: 60292274
VRF Central Touchscreen Controller Adapter: 60292275
Energy Calculation Software: 60292276
H-LINK: 16
Groups: 2,048
Blocks: 512 *3
Areas: 512 *3
(Up to 128 Groups can be registered on 1 H-LINK)
On/Off
Mode
Set temperature
(including dual setpoint for Auto mode)
Fan speed
Louver
On/Off
Mode
Set temperature
(including dual setpoint for Auto mode)
Air intake temperature
RC sensor temperature
Outdoor temperature *6
Panel (7 sizes provided)
Layout
List
Weekly schedule (16 items/day)
Annual schedule (Exception day 1-5, summer/winter/regular)
Each of the following data of up to 2 years' can be shown:
• Accumulated operation time
• Accumulated thermo-ON time
• Ave. air intake temp.
• Ave. outdoor temp.
• Ave. temp. (including dual setpoint for Auto mode)
• Ave. RC sensor temp.
Management Point
[VRF Central Touchscreen Controller/VRF Central Touchscreen Controller Adapter]
External input: 4 (Level or pulse)
External output: 2 (Set voltage contact/ No-voltage contact on DSW)
Features
[Energy saving]
• Run/Stop
• RC prohibition
• Temperature shift
(For Cool/Dry mode: +1°F ~ +18°F (+1°C ~ +9°C))
(For Heat mode: -1°F ~ -18°F (-1°C ~ -9°C))
• Mode shift
(Mode shifted to Fan when in Cool/Dry mode,
and shifted to Stop in Heat mode)
• Capacity control on outdoor units
• Lower noise control for outdoor units
• Alarm history: 10,000 records
• External In/Output history: 1,000 records
• Pulse input history: 6 months
Description
Remote Controller (RC) prohibition
Filter sign reset
Function selection for indoor units *4
Function selection for outdoor units *5
Capacity control for outdoor units *5
Lower noise control for outdoor units *5
Fan Speed
Louver
RC prohibition
Thermo-ON information
Filter sign/Auto cleaning fault
Alarm status/Alarm codes
Setback information
[Control/Monitor]
Controlled items:
• Run/Stop
• Mode (Cool/Heat)
Monitored items:
• Run/Stop
• Mode (Cool/Heat)
• Alarm state
[Others]
• Power consumption signal input
• Emergency stop
