2.3 Standard Specifi cation
● VRF Central Touchscreen Controller Hardware Specifi cation
Item
Dimensions (W×H×D)
Net Weight
Installation Condition
Clock Accuracy
Ambient Temperature
Ambient Humidity
Display
Power Supply
Power Consumption
● VRF Central Touchscreen Controller Adapter Hardware Specifi cation
Item
Dimensions (W×H×D)
Net Weight
Installation Condition
Ambient Temperature
Ambient Humidity
Power Supply
Power Consumption
● Air Conditioners Communication Specifi cation
Item
Communication Peer
Communication Line
Communication Method
Synchronous Method
Communication Speed
Total Wiring Length
Maximum Controlled Unit
Number on System (*2)
(*1): Refer to page 2-2.
(*2): Maximum units that can be connected within1 H-LINK (control wiring).
TC-19001
14-5/8 × 8-15/16 × 1-1/4 + 1-1/8 (molded in wall) inch
(372 × 227.2 × 32.5 + 27.8 (molded in wall) mm)
7.7lbs. (3.5kg)
For indoor use only. Applicable for on wall mount and wall built in.
+- 70 seconds/month
32~104°F (0~40°C)
20-85% RH (No condensation)
1.2 inch TFT color liquid crystal display
AC24V ± 10%, 60Hz
50W (Max.) (55VA)
10-1/16 × 2-13/16 × 6-1/8 (protruding part not included) inch
(255.6 × 72 × 155 (protruding part not included) mm)
3.3lbs. (1.5kg)
For indoor use only. Applicable for horizontal installation and vertical on wall
mount.
32~104°F (0~40°C)
20-85% RH (No condensation)
AC24V ± 10%, 60Hz
10W or less (12VA)
Indoor units / Outdoor units (*1)
Nonpolar Two Wires
Half-Duplex Communication
Asynchronous
9,600 bps
3,281 ft. (1000m)
Outdoor Unit: Max. 64 Units Indoor Unit: Max. 160 Units
Central Controller: 8 pcs. Total Number: 200
SYSTEM SPECIFICATION
Specifi cation
Specifi cation
Specifi cation
