SYSTEM SPECIFICATION

2.4 Appearance

USB flash drive slot

2-6

14-5/8 (372)

SD Card Slot

LAN Port

Power Input

H-LINK, External in/output Wiring Port

(Unit: inch(mm))

1-1/4

1-1/8

(32.5)

(27.8)

TC-19001
