SYSTEM SUMMARY
1.2 Control Device
1.2.1 Line Up
Refer to the illustrations below showing the VRF control system components.
Central Controllers
Mini Central Controller
Outdoor Units
Indoor Units
Individual Remote Controllers
Wired Controller
A/C Meeting Room
MODE SPEED LOUV. TEMP
Avoid
COOL
Motion Sensor ON
LOUV. Adj.
On/Off
OK
1-2
Large Central Controller
Simplifi ed Wired Controller
FLTR
Menu
Back/Help ECO
H-LINK II or H-LINK Cable
Controller Cable
VRF Central Touchscreen Controller
IR Receiver
Wireless Controller
