B E O V I S I ON H A R M ON Y
S T A R T H E R E
I N T R O D U C T I O N
This guide contains additional information about the daily use of your Bang & Olufsen product and
connected products and describes the features and functions of your product in more detail. Among other
things you can find information about settings, how to operate your product with a Bang & Olufsen remote
control, and how to set up a network connection. We expect your retailer to deliver, install and set up your
product.
Your Bang & Olufsen retailer is your first stop for all your service queries. To find your nearest retailer,
see www.bang-olufsen.com
The Beovision Harmony is a cooperation between Bang & Olufsen and LG. This guide contains instructions
related to the Bang & Olufsen Soundcenter and the Bang & Olufsen remote control.
For instructions and settings related to the screen, please go to the LG site:
https://www.lg.com/common/index.jsp
1. Select country
2. Select Home > Support > Downloads > Manuals
3. Enter model number
4. Then you have the guide for your LG screen.
Note that some features may not be available on all markets.
In this Bang & Olufsen guide you also find information about other features, such as connections, sound
settings and software updates.
You can bring up the present user guidance via a computer or a smart device.
We recommend that you become familiar with a number of differences between your Bang & Olufsen
remote control and the remote control described in the LG guidance presented. For more information, see
the chapter ´REMOTE CONTROL´.
Important information! Bang & Olufsen is not responsible for the availability and performance of internet
services, including downloaded apps. Bang & Olufsen provides the technical foundation for receiving
internet services. Bang & Olufsen cannot give any guarantees related to the services as the providers may
change the content and conditions including removal of apps. Available internet services and apps may vary
depending on the market.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Beovision Harmony Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Bang & Olufsen Beovision Harmony Series

  • Page 1 B E O V I S I ON H A R M ON Y S T A R T H E R E I N T R O D U C T I O N This guide contains additional information about the daily use of your Bang & Olufsen product and connected products and describes the features and functions of your product in more detail.
  • Page 2 R E M O T E C O N T R O L Operation for the Beovision Harmony is described with Beoremote One. Pair your remote control Note that to operate your Beovision Harmony, it must first be paired with Beoremote One. Long press the PAIRING button placed on the back of the right speaker box or pair through the Service menu found when you select the Bang &...
  • Page 3 Beovision Harmony and you need to pair it again, or if you cannot find it and you need to pair another Beoremote One, you must set both Beovision Harmony and remote control in pairing mode to pair it to the television.
  • Page 4 (MyButtons)** Long press to save the current setup, such as sound settings and stand positions, short press to activate it. 0–9 Select channels and enter information in on-screen menus. LIST Display extra functions in the display. Use to step in the list. GUIDE Bring up the TV Programme Guide.
  • Page 5 HOME button Press Left, Right, Up and Down buttons Press , , and . (OK) button Press the centre button. P Up and P Down buttons Press LIST button Press LIST then to find Channels in the Beoremote One display and press the centre button. Quick Settings button Press LIST then to find Options in the Beoremote One display and press the centre button.
  • Page 6 Remote control operation The below shows an example of remote control operation. To activate sound modes directly… 1. Press LIST, then to bring up Sound in the BeoRemote One display and press the centre button. 2. Use to step between modes and press the centre button to select a mode. 3.
  • Page 7 How to navigate in menus Use your remote control to navigate in menus and find different features. Press to bring up the home menu which gives an overview of available apps and different features. To access Bang & Olufsen settings, go to the Bang & Olufsen LG tv-app. Find it by pressing to bring up the Home menu, where the app can be accessed.
  • Page 8 Step between menu pages Some menus take up more space than available on the TV screen. You can then scroll through these menus. • Press to scroll through menu items. Select source You can bring up a source by pressing the TV or MUSIC button and select a source in the remote control display.
  • Page 9 Refer to www.bang-olufsen.com for available stands and wall brackets or contact your Bang & Olufsen retailer Overview Note, that in order to access all buttons and connections on the back, your Beovision Harmony needs to be in TV mode (speakers in open position). Locate the connection panel and other important items: 1.
  • Page 10 B A N G & O L U F S E N T V A P P The Bang & Olufsen TV App is the App the LG content store which allows you to make specific Bang & Olufsen settings, such as sound settings and speaker groups as well as operating your Beovision Harmony with the Beoremote One.
  • Page 11 After rebooting you will be invited to pair your Beoremote One with the Beovision Harmony and to proceed to the B&O first time set up which includes speakers and sound configuration options to get the most out of your television speakers and for the HDMI set-up to be able to control any third party devices with your Beovision Harmony.
  • Page 12 Connect the mains socket ( ͠ ) on the connection panel of your television to the wall outlet. The supplied plug and mains cord are specially designed for the product. Do not change the plug, and if the mains cord is damaged, you must buy a new one from your Bang & Olufsen retailer. ( ͠...
  • Page 13 Make sure the cable connection between the product and the router does not exit the building to avoid contact with high voltage. It is strongly recommended that you set your television to update system software automatically, see the chapter 'SERVICE AND SOFTWARE UPDATE'. SERVICE This connection powers the movement of the speakers.
  • Page 14 In this mode, helpful things like radio station and artist information (metadata) will be displayed on the top part of the screen. Streaming services providing information on the screen: Spotify TuneIn Deezer iTunes Apple Music Chromecast Airplay2 Bluetooth* *Cover art will not be shown when streaming via Bluetooth. Note: Built-in TuneIn source will show metadata information.
  • Page 15 P A I R I N G , N E T W O R K S T A T U S A N D F A C T O R Y R E S E T On the back of the right speaker box of the Soundcenter, available when it is in TV mode, you find a button for pairing and for factory reset.
  • Page 16 The NETWORK STATUS indicator light beneath the FACTORY RESET button gives you a status of pairing and the network connection: White (solid) Connected to a network. White (pulsing) Booting White (flashing) Factory Default Reset. Orange (solid) Connected to a wireless network, the signal strength is low.
  • Page 17 D O M O R E W A T C H T E L E V I S I O N Watch analogue and digital terrestrial, cable and satellite channels depending on your tuner options. See programme information and open the TV guide. Make a recording if you have connected a correctly formatted USB HDD or SSD.
  • Page 18 You can bring up information on the current programme. You can also change audio and subtitle language or bring up interactive information via HbbTV.** An information display appears briefly on the screen every time you change channel or station. You can also bring up a display manually by pressing INFO to see programme information.
  • Page 19 R E M O T E C O N T R O L D E V I C E S You can operate your Beovision Harmony not only with your Bang & Olufsen remote control but also with the Bang & Olufsen App. Bang &...
  • Page 20 You can save snapshots which can be activated by the Mybuttons. Your television must be switched on and a source must be selected. 1. Press and hold one of the Mybuttons, to bring up a list of items you can include in the snapshot. 2.
  • Page 21 Select a sound mode You can select the sound mode that suits the source you are using. 1. Press LIST, then to bring up Sound in the BeoRemote One display and press the centre button. 2. Press to highlight the sound mode you want and press the centre button. 3.
  • Page 22 Connect a camera... 1. Connect the cable to the appropriate socket on the camera. 2. Run the cable to a HDMI IN socket on the television screen. 3. Follow on-screen instructions to configure the source. Computer 1. Using the appropriate type of cable, connect one end to the HDMI output socket on your computer, and the other end to a HDMI IN (HDMI A-D) socket on the Soundcenter.
  • Page 23 For information about download of Peripheral Unit Controller (PUC) tables for set-top boxes, see the chapter 'SET UP CONNECTED PRODUCTS'. Speakers You can connect up to eight wired speakers and subwoofers to the television using Power Link cables. In addition, you can connect up to eight speakers wirelessly, including subwoofers. For more information about setting up wireless speakers, see the chapter 'SOUND SETTINGS'.
  • Page 24 3. Connect a Power Link cable to the appropriate sockets on a subwoofer. 4. Run the cable to an available socket marked PL 1–4 on the television. 5. Reconnect the television and the connected speakers to the mains. *Remember to set the switch on the speaker for left and right position on the speakers depending on whether your speaker is positioned on the left or right of your listening position.
  • Page 25 Access Deezer and TuneIn, audio sources built into the Soundcenter, if you have the required subscriptions, and enjoy music for every occasion. To use music or video services, your Beovision Harmony must be connected to the Internet. For more information about network, see the chapter 'NETWORK SETTINGS'. Note, that all LG sources are automatically displayed under the TV list.
  • Page 26 M A I N T E N A N C E Regular maintenance, such as cleaning, is the responsibility of the user. Screen Gently wipe the screen using a soft/dry cloth. Make sure to use just enough water or cleaning fluid to wipe the screen without leaving streaks or traces.
  • Page 27 M A K E S E T T I N G S S E T U P C O N N E C T E D P R O D U C T S If you connect additional video products to your sound center, then you can set up the products in the Sources menu.
  • Page 28 The sources are brought up on the Beoremote One display using the TV and MUSIC buttons. In the Beoremote One Lists menu, you can select in which list on your Beoremote One you want this source to appear (TV, MUSIC, both or none). Note: If you install an app in the webOS, it is automatically displayed in the TV list.
  • Page 29 2. Use the arrow buttons to select the Bang & Olufsen TV app and press the centre button. 3. Press to select Sound & BeoLink... and press the centre button. 4. Press to select Sound and press the button. 5. Press to select a Speaker Groups and press the centre button.
  • Page 30 In scenario 1 in the illustration, the right speaker in the top may be set up as a right front speaker when you watch television from the couch, whereas in scenario 2, the same speaker may function as a right surround speaker when you sit in the armchair listening to music.
  • Page 31 Some advanced Bang & Olufsen speakers support preset selection. The preset number is found in the app for the speaker. You decide which preset should be activated when you select a speaker group. Speaker roles Assigning roles to the connected loudspeakers allows you to specify the speakers’ function in a surround sound system and the number of speakers to be used.
  • Page 32 Here you also set the highest volume level allowed in normal usage. This can be used to limit the maximum output of the Beovision Harmony. Bass and treble In the Bass and Treble menu, decrease or increase the bass level and the treble level. Activate loudness The human ear is less sensitive to low frequencies when they are played at low volume levels.
  • Page 33 You can also access the function if you press , select the Bang & Olufsen TV App, then Sound & BeoLink..., Sound and Speaker Connections. Scan for and associate wireless speakers … 1. In the Speaker Connections menu, select RESCAN and press the centre button to rescan. 2.
  • Page 34 W I R E L E S S C O N N E C T I O N 1. Press to bring up the Home menu. 2. Use the arrow buttons to select the Bang & Olufsen TV App and press the centre button. 3.
  • Page 35 Select CHECK FOR UPDATE and press the centre button, the Beovision Harmony should check for new software. If any updates are available, press the centre button to start updating and follow on-screen instructions. While the Beovision Harmony is updating with new software, the standby indicator flashes red and the Beovision Harmony should remain connected to the mains.
  • Page 36 Set up a wireless network In the Wireless Network Setup menu you can search for and connect your Beovision Harmony to a wireless network Usage data - Privacy & Terms To help us improve our range of available products and services offered to you, we may request certain information from your product about its performance and usage patterns.
  • Page 37 in a corner, it is necessary to calibrate the motorised movement again. For information about moving your television, see the chapter SET UP YOUR TELEVISION. Depending on your setup, you can bring up a Stand Adjustment menu for stand positions. Set up the television with a motorised floor stand 1.
  • Page 38 1. When Stand Transport is highlighted, press the centre button to activate transport mode. Highlight OK and press the centre button to confirm. If you do not wish to activate transport mode, select Cancel instead. When the stand has been moved, you must calibrate the stand and set up stand positions again.
