- Page 1 BeoVision 10 ...
- Page 3 Dear Customer This Getting Started contains information about the daily use of your Bang & Olufsen product and connected equipment. We expect your retailer to deliver, install and set up your product. Your television offers more features and functions than described in Getting Started. Among other things; Timer functions and auto standby, editing and naming channels. These and other features are described in more detail in a Guide. The Guides are found on www.bang-olufsen.com/guides DVB functions are described in a separate Guide. The Guides are kept up to date if new software introduces new or modified features and functions in your television. On www.bang-olufsen.com you can also find further information and relevant FAQs about your product. Your Bang & Olufsen retailer is your first stop for all your service queries. To find your nearest retailer, visit our website ... www.bang-olufsen.com Technical specifications, features and the use thereof are subject to change without notice. 3510542 1005...
- Page 4 Cautions WARNING: To reduce the risk of fire or – Ensure that the television is positioned, set up electric shock, do not expose this and connected in accordance with the instructions appliance to rain or moisture. Do not in this Getting Started. – Place your television on a firm, stable surface. expose this equip m ent to dripping or To prevent injury, use Bang & Olufsen approved splashing and ensure that no objects stands and wall brackets only! filled with liquids, such as vases, are – Do not place any items on top of your television. – Do not subject the television to rain, high humidity placed on the equipment. or sources of heat. – The television is developed for indoor use in dry, To completely disconnect this equipment domestic environments only. Use within a from the AC Mains, disconnect the mains temperature range of 10–40°C (50–95°F), and at an altitude of no more than 1,500 m plug from the wall socket. The disconnect (5,000 ft). device shall remain readily operable. – Do not place the television in direct sunlight, as this may reduce the sensitivity of the remote The lightning flash with arrowhead control receiver. symbol within an equilateral triangle, – ...
-
Page 5: Table Of Contents
Contents Daily use 6 How to use your remote control 8 Introduction 10 Watch television 12 Look up teletext 14 Watch television via the DVB module 15 Change sound type and picture format Installation 20 Set up your television 22 Cleaning 23 Connection panels 24 First-time setup of your television ... -
Page 6: How To Use Your Remote Control
How to use your remote control Beo4 operation Your television can be operated with the Beo4 remote control. The Beo4 display shows you the activated source or function Switch on the TV* Switch on the DVB module and watch digital television Switch on teletext TEXT Select channels and enter information in on-screen menus 0 –... - Page 7 Beo5 operation You can also operate your television with a Beo5. When Beo5 operation is different, it is described separately. Soft button, touch screen to select* Switch on a source or select a function Back up through Beo5 displays Bring up Scene buttons, such as Zones or Speaker Press again to return Living Room Bring up digits to select channel or recording Press again to return V.MEM RADIO N.MUSIC N.RADIO Pause and stop playback or recording STOP...
-
Page 8: Introduction
Introduction Navigate in menus and select settings using your remote control. Display and menus V MEM MENU Switch on TV Switch on connected equipment Show menu Information about the selected source is shown at the top of the screen. On-screen menus allow you to adjust settings. Menu name TV SETUP SLEEP TIMER Menu options PLAY TIMER OPTIONS Information field select Example of on-screen menu Important BEO4 SETTING menu In the ‘OPTIONS’ menu, you can bring up the ‘BEO4 SETTING’ menu. This menu is only relevant if you have a Beo4 remote control with a navigation button. Remember to set your Beo4 remote control to the correct mode. See the Beo4 Guide or contact your Bang & Olufsen retailer for further information. ... - Page 9 Navigate in menus 0 – 9 BACK BACK Select option/ Enter data Bring up sub- Select option Move Press and hold to When a menu is on the screen, you can move setting menu/store backwards exit menus between menu options, reveal settings or enter setting through menus data. Remote control On the first pages in this Getting Started, you will find an overview of the buttons on Beo4 and Beo5. For general information about remote control operation, see the Guide enclosed with your remote control. ...
-
Page 10: Watch Television
Watch television Beo4 operation Choose a TV channel by its number or switch to another channel. Adjust the sound volume and turn the TV. Switch on the TV Activate the TV source to use these functions Channel name Select a TV channel Channel number TV CHANNEL LIST Bring up a channel list … DISCOVER CWNBC BBCWORLD … … …... - Page 11 Beo5 operation Press Press 0–9 0–9 Previous Select Activate numbers and Previous Select Select channel Select previous channel select channel channel Hold for Select page Select Hold for channel list and Accept Accept select channel channel list channel Adjust volume Press in the middle to mute Press to bring sound back Adjust volume. To mute, Turn either way to up or down sound turn quickly counter- bring back sound clockwise Position LIST 1–9 1…9 Stand Turn Press to find ...
-
Page 12: Look Up Teletext
Look up teletext Beo4 operation Operate teletext through the menu bar at the top of the teletext page or the arrow buttons on your remote control. Start teletext Activate teletext to use these functions Access the start page of teletext. Current page Move to page Access teletext pages you wish to see. Enlarge teletext pages PAGE MEMO HALT LARGE REVEAL SETUP P100 S100 Wed 13 Oct 12:39:34 Stop subpages from turning Enlarge teletext page Stop subpage MEMO pages... - Page 13 Beo5 operation TEXT Text Press repeatedly to change screen mode Press repeatedly to change screen mode 0–9 0–9 Step up or Move to ‘PAGE’ and select Select page Go to index pages Step up or Move to ‘PAGE’ and Select page down in (100, 200, 300 …) down in select pages pages STOP 0–9 STOP 0–9 Stop turning Move to ‘HALT’ Press Select subpage Restart Stop turning Select subpage Restart turning turning Move to ‘LARGE’ Press to switch between upper and lower half of page Move to Switch between upper and lower and normal viewing ‘LARGE’ ...
-
Page 14: Watch Television Via The Dvb Module
Watch television via the DVB module Beo4 operation When your television is equipped with the DVB module, you can receive digital terrestrial, cable and satellite programmes depending on your module options. Switch on the TV and the DVB module* Activate the DTV source to use these functions Select a DTV channel DVB function Beo4 button Bring up and use the menu overlay GUIDE MENU TEXT... - Page 15 Beo5 operation Press Press 0–9 0–9 Select Select channel Select Activate numbers and select channel MENU 0–9 Menu Press Activate the desired function Use the designated buttons in the display Groups+ Groups- Step between groups Step between groups Hold for Select page Select channel Accept Hold for channel list, Accept channel list select page or channel Press Press ...
- Page 16 Sound type and picture format While you watch TV through the television tuner, you can switch between available sound types and adjust the picture format. Change sound type or language Bring up SOUND in your Beo4 display* Press repeatedly to Switch between available sound types and switch between languages. available sound types Select picture format 1–4 Bring up FORMAT in your Beo4 display* Select format* Move picture up or down* or The TV automatically adapts the picture to fill out 3 select variation* as much of the screen as possible when you select a source, but you can select a format yourself. FORMAT 1 FORMAT 2 FORMAT 4 FORMAT 3 Standard* ...
- Page 17 Contents – Installation and setting up 20 Set up your television 22 Cleaning 23 Connection panels 3 4 First-time setup of your television ...
-
Page 18: Set Up Your Television
Set up your television Follow the guidelines for placement and connection described on this and the following pages. Placement options The TV can be placed on a motorised stand or Due to the heavy weight of the TV, any moving or mounted on a wall bracket. lifting of the TV should be performed by qualified personnel – using the proper equipment. Handling We recommend that you place the TV in the Three protection profiles have been enclosed with packaging while you fasten the hinges for the wall the TV. Use these when moving the TV to avoid bracket or the bracket for the stand. scratching the frame. Wall bracket and stand Set the maximum angle the TV will turn on the stand. The wall bracket can manually be turned 45˚ left or right depending on your setup. Remember to leave enough space around the TV to allow it to turn and tilt freely. Important Ventilation To ensure proper ventilation, allow enough space around the screen. Do not cover the fans. At over- heating (flashing standby indicator and an on-screen warning), switch the TV to standby, not off, in order for the TV to cool down. You cannot operate the TV during this time. Front glass If the front screen glass should crack or chip, or if it should be damaged in any way, it must be replaced immediately, as it could otherwise cause injury. You can order replacement front screen glass from your Bang & Olufsen retailer. ... -
Page 19: Cleaning
Overview Locate the connection panel and other important 1 Mounting bracket for wall bracket. items: 2 Mounting bracket for stand. 3 Cover for the connection panel. Here you also find the mains supply connection. Pull out at the bottom to remove the cover. 4 Depending on your setup lead the cables through one of the three holes. Remove the part of the cover using a pair of tongs. Run cables You can fasten the cables to either side or in the If you have a motorised stand, make sure that middle, depending on wall bracket or stand there is enough slack in the cables to allow the placement. TV to turn to either side before you fasten the cables with cable strips to make a neat bundle. Fasten the front cloth cover When the TV is placed on a wall bracket or stand During cleaning it is recommended to remove the you can attach the front cloth cover. front cloth cover. Avoid spraying liquid directly on Hold the front cover with both hands and attach it the screen as this may damage the speakers, use a at the bottom first. Then carefully attach it to the soft cloth instead. top and adjust its position before letting go. Carefully remove the front cover by supporting it in the side and at the bottom. Cleaning Maintenance Regular maintenance, such as cleaning, is the responsibility of the user. ... -
Page 20: Connection Panels
Connection panels Any equipment you connect to the main connection panel must be registered in the ‘CONNECTIONS’ menu. Mains supply CAMERA ~ – Mains supply AV (1–2 and 4) Connection to the mains supply. 21-pin sockets for connection of additional video equipment, such as a DVD player, set-top box, a Ethernet decoder or video recorder. For service use only. AV3 (video, L, R) USB For audio connection (right and left sound For service use only. channel respectively) and video signals from an external source. Useful hints Mains cord and plug The supplied plug and mains cord are specially designed for the product. Do not change the plug and if the mains cord is damaged, you must buy a new one from your Bang & Olufsen retailer. Connect the ~ socket on the main connection panel of your TV to the wall outlet. The IR-receiver lights up in red and the TV is in standby mode and ready to be used. ... - Page 21 Y – Pb – Pr (AV2–4, 6) RF OUT DVB-T/C* For video signals from an external source, e.g. Aerial output socket for distribution of video Aerial input socket for external aerial/cable TV HDTV source. You can use the socket in signals to other rooms. Also requires an RF Link network. conjunction with an AV socket or a digital audio Amplifier. See the Guide for further information. socket. AERIAL OUT POWER LINK (SUB) If the signal received consists of both an analogue SPDIF (1–2) Use for connection of a Bang & Olufsen subwoofer. and a digital signal, the signal can be routed from Digital audio input socket, e.g. DVD player. You this socket to the AERIAL socket (analogue tuner can use the socket in conjunction with an AV POWER LINK (FRONT – REAR) input). socket. Use for connection of external loudspeakers in a DVB-S* surround sound setup. See the Guide for further PUC (1–4) information. Aerial input socket for digital satellite signal. For IR control signals to external equipment ...
-
Page 22: First-Time Setup Of Your Television
First-time setup of your television This first-time setup procedure is activated when the TV is connected to the mains and switched on for the first time. If you want to change your setup at a later date, you can access the same menus and update your settings. Switch on the TV Switch on It takes the TV approx. - Page 23 Calibrate the speakers First-time setup of loudspeakers applies only to speakers for TV viewing. SPEAKER TYPE SPEAKER DISTANCE See the Guide for further information. Set up the speakers to optimise sound from your listening position. SPEAKER LEVEL SOUND ADJUSTMENT Adjust volume, bass, treble and loudness and preset two default speaker combinations. Select a different speaker combination at any time. Calibrate the stand STAND ADJUSTMENT At ‘SET LEFTMOST At ‘SET RIGHTMOST Accept Set the maximum angle the TV will turn – left and POSITION’ turn left to the POSITION’ turn right to the right. The motorised movement of the TV will not point you wish to restrict point you wish to restrict the work until the calibration process has been the movement to movement to completed. You can only tilt the TV manually. Set preferred preset position for the TV to turn to, when it is switched STAND POSITIONS on and off. NOTE! You need to calibrate the stand before you can use the motorised movement of the stand. ...
- Page 24 This product is in conformity with Manufactured under license from Dolby the provisions of the Directives Laboratories. Dolby, Pro Logic, and the 2004/108/EC and 2006/95/EC. double-D symbol are registered trademarks of Dolby Laboratories. This product incorporates copyright protection Confidential unpublished works. technology that is protected by U.S. patents and Copyright 1992–2003 Dolby Laboratories. other intellectual property rights. Use of this copy r ight protection technology must be All rights reserved. authorized by Rovi, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi. Reverse engineering or disassembly is prohibited. Manufactured under HDMI, the HDMI logo and High-Definition license under U.S. Patent #’s: 5,451,942; Multi m edia Interface are trademarks or registered trade m arks of HDMI Licensing LLC. 5,956,674; 5,974,380; 5,978,762; 6,487,535; ...
- Page 25 Waste Electrical and Electronic Equipment Electrical and electronic equipment, parts and contamination of nature with the hazardous (WEEE) – Environmental protection batteries marked with this symbol must not be substances which may be present in electrical and disposed of with normal household wastage; all electronic products and equipment. electrical and electronic equipment, parts and Your Bang & Olufsen retailer will advise you of the batteries must be collected and disposed of correct way of disposal in your country. separately. When disposing of electrical and electronic If a product is too small to be marked with the equipment and batteries by use of the collection symbol, it will appear in the User guide, on the systems available in your country, you protect the ...
