Removing an Entire Trunk Group

To remove an entire trunk Group:
1. Using the arrow keys, highlight the Group: [ADD/DELETE] field (on the
same line as the Add/Remove Group field). Press the Spacebar to select
[DELETE].
2. If the name of the group to be deleted doesn't appear on the Add/Remove
Group field, type the name of the SmartTrunk group you wish to delete.
It is also possible to use the Display Group field to toggle through existing
groups. This will automatically update Add/Remove Group field. Once the
proper name appears in the Add/Remove Group field, highlight the SAVE
command, and then press the Return key. The group will be removed.
All ports in the group will be released. It is not necessary to remove ports from a
NOTE
group before deleting the group.

Removing a Port from a Group

To remove a port from a Group:
1. Select the group to have a port removed. If the name of the group to be
deleted doesn't appear on the Add/Remove Group field, type the name of the
SmartTrunk group you wish reconfigure. It is also possible to use the Display
Group field to toggle through existing groups. This will automatically update
the Add/Remove Group field. Once the proper name appears in the
Add/Remove Group field, proceed to step 2.
2. Highlight the [ADD/DELETE] field (to the right of the Port field). Press the
Spacebar to select [DELETE].
3. Move the cursor to the Port field. Select the port that is to be removed from the
SmartTrunk Group. Press the Spacebar to change the port number. Only ports
that are currently members of the group will be displayed.
4. Once the port is selected, highlight the [DELETE] field.
5. To delete the port, press the Return key.
6. Continue to press the Return key and all ports will be deleted.
7. Highlight the SAVE command, and then press the Return key.
