SmartTrunk Configuration
Device Type: 2E42-27
SmartTrunk Group:
SmartTrunk Logical Port:
Port
----------------
SmartTrunk State: [ENABLED]
Add/Remove Group:
Display Group:
SAVE UPDATE
The following section briefly explains each field on the SmartTrunking
Configuration Screen.
SmartTrunk Group
The title of the group that is active in the screen.
SmartTrunk Logical Port
SmartTrunk ports are a collection of physical ports. When the logical port is not
one of the physical ports contained in the group, a MIBII interface is created to
represent the Trunk group. These interfaces are added dynamically as each new
hunt group is created (see Appendix A for more information).
If the logical port is one of the physical ports, then it identifies the bridge port
number used by all members of the SmartTrunking group.
The interface gets its MAC address from the management port of the SmartTrunk
(usually the first port added). If this port is removed from the trunk, the next
port's MAC address will be assigned to the interface.
2-4
2E42-27 LOCAL MANAGEMENT
SmartTrunking Configuration
State Port
-----------------
Figure 2-3. SmartTrunking Configuration Screen
Firmware Revision: XX.XX.XX
BOOTPROM Revision: XX.XX.XX
State Port
-----------------
Trunk Protocol: [ENABLED]
Group: [
Port:
EXIT
State
ADD ]
[REMOVE]
RETURN
