The SET PORTS TO VLAN FORWARDING field toggles between NO and YES. NO is the
default setting and has no other function. YES will map all port(s) set to Classify/YES to the
VLAN FORWARDING LIST and set their port frame format to untagged.
NOTE: Once a port has been assigned to the VLAN Forwarding List, the port can only
be removed from the list using the VLAN Forwarding Configuration screen described in
the 802.1Q VLAN User's Guide
2.4.1

Assigning Ports to a Classification Rule

The following procedures describe how to
•
assign one or more ports to a classification rule,
•
set all ports simultaneously to a classification rule, or
•
add all ports to the VLAN Forwarding List as belonging to the VLAN shown in the Protocol
Information field.
Assigning One or More Ports Individually
1. Use the arrow keys to highlight the Classify field adjacent to the Port number.
2. Press the SPACE bar to toggle the Classify field to YES or NO. YES assigns the port to the
classification rule shown in the Protocol Information field. NO removes the port from the
classification rule shown in the Protocol Information field.
3. If more than one port is to be added to the classification rule, repeat the first two steps for each
port.
4. Use the arrow keys to highlight the SAVE command at the bottom of the screen.
5. Press ENTER. The message "SAVED OK" displays and the settings are saved.
Assigning All Ports Simultaneously
1. Use the arrow keys to highlight the SET ALL PORTS command field.
2. Press the SPACE bar to toggle the SET ALL PORTS field to YES or NO and press ENTER.
YES will set all the ports to the VLAN shown in the Protocol Information field. NO will remove
all ports from the classification rule.
3. Use the arrow keys to highlight the SAVE command at the bottom of the screen.
4. Press ENTER. The message "SAVED OK" displays and the setting is saved.
.
Protocol Port Configuration Screen
Local Management Screens 2-15
