Summary of Contents for Enterasys 2G4072-52
- Page 1 Enterasys Matrix ® N Standalone Series Installation Guide 2G4072-52 9033973-04...
- Page 3 Part Number: 9033973‐04 July 2008 ENTERASYS NETWORKS, ENTERASYS MATRIX, LANVIEW, MATRIX, ENTERASYS NETSIGHT, WEBVIEW, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. For a complete list of Enterasys trademarks, see http://www.enterasys.com/company/trademarks.aspx.
-
Page 4: Regulatory Compliance Information
Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Notice This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia ... -
Page 5: Hazardous Substances
This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 2004/108/EC, EN 55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous Substances (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ Enterasys Customer Support at 353 61 705586 (Ireland). Electromagnetic Compatibility (EMC) Compatibilidad Electromágnetica (EMC) Hazardous Substances or contact ... - Page 6 (Parts) (Metal Parts) Circuit Modules) Cables & Cable Assemblies) (Plastic and Polymeric parts) Circuit Breakers) Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is below the relevant threshold of the SJ/T 11363-2006 standard. Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials in the parts is above the relevant threshold of the SJ/T 11363-2006 standard.
- Page 7 VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 8: Declaration Of Conformity
Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. Application of Council Directive(s): 2004/108/EC European Representative Address: Enterasys Networks, Ltd. Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC Equipment Type/Environment: Networking Equipment, for use in a Commercial Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. Safety Information Class 1 Laser Transceivers Declaration of Conformity 2006/95/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 2006/95/EC EN 60950 EN 60825... - Page 9 ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program ...
- Page 10 APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions. You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the 1980 United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the product is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Section 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Cambodia, Cuba, Georgia, Iraq, Kazakhstan, Laos, Libya, Macau, Moldova, Mongolia, North Korea, the People’s Republic of China, Russia, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202‐3 and its successors, and use, duplication, or disclosure by the U.S. Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO YOU IN WRITING BY ENTERASYS, ENTERASYS DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON‐INFRINGEMENT WITH RESPECT TO THE PROGRAM. IF IMPLIED WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THIRTY (30) DAYS AFTER DELIVERY OF THE PROGRAM TO YOU.
- Page 11 AUDIT RIGHTS. You hereby acknowledge that the intellectual property rights associated with the Program are of critical value to Enterasys, and, accordingly, You hereby agree to maintain complete books, records and accounts showing (i) license fees due and paid, and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and its authorized representatives, upon reasonable notice, the right to audit and examine during Your normal business hours, Your books, records, accounts and hardware devices upon which the Program may be deployed to verify compliance with this Agreement, including the verification of the license fees due and paid Enterasys and the use, copying and deployment of the Program. Enterasys’ right of examination shall be exercised reasonably, in good faith and in a manner calculated to not unreasonably interfere with Your business. In the event such audit discovers non‐compliance with this Agreement, including copies of the Program made, used or deployed in breach of this Agreement, You shall promptly pay to Enterasys the appropriate license fees. Enterasys reserves the right, to be exercised in its sole discretion and without prior notice, to terminate this license, effective immediately, for failure to comply with this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion. 13.
-
Page 13: Table Of Contents
10BASE-T Network ...2-2 100BASE-TX Network ...2-2 1000BASE-SX/SX+/LX Network ...2-2 1000BASE-T Network ...2-2 Chapter 3: Installation Unpacking the 2G4072-52 ...3-1 Rack Mounting ...3-2 Connecting Power ...3-4 Connecting to the Network ...3-5 Connecting UTP Cables ...3-5 Connecting Fiber-Optic Cables to Mini-GBICs ...3-9 Connecting to the COM Port for Local Management ...3-13... - Page 14 Overview of Shutdown Procedure ...4-5 Recommended Shutdown Procedure Using RESET Button ...4-6 Last Resort Shutdown Procedure Using RESET Button ...4-6 Appendix A: Specifications 2G4072-52 Specifications ... A-1 Mini-GBIC Input/Output Specifications ... A-2 Gigabit Ethernet Specifications ... A-3 MGBIC-LC01 / MGBIC-MT01 Specifications (1000BASE-SX) ... A-3 MGBIC-LC03 Specifications (1000BASE-SX) ...
- Page 15 Figures 2G4072-52 Front Panel...1-2 LANVIEW LEDs ...1-3 Attaching Rack-mount Ears to Enterasys Matrix N SA 2G4072-52 ...3-3 Mounting Enterasys Matrix N SA 2G4072-52 to Rack ...3-3 Connecting Power...3-4 Connecting a Twisted Pair Segment to the 2G4072-52...3-6 Crossover Four-Wire Cable RJ45 Pinouts ...3-7 Straight-Through Four-Wire Cable RJ45 Pinouts ...3-7...
-
Page 17: Important Notice
This guide provides an overview, installation and troubleshooting instructions, and specifications for the Enterasys Matrix information about the CLI (Command Line Interface) set of commands used to configure and manage the 2G4072‐52, refer to the Enterasys Matrix N Standalone Series Configuration Guide. Depending on the firmware version used in the Enterasys Matrix N SA, some features described in this document may not be supported. Refer to the Release Notes shipped with the Enterasys Matrix N SA to determine which features are supported. Who Should Use This Guide Electrical Hazard: Only qualified personnel should perform installation procedures. -
Page 18: Structure Of This Guide
Structure of This Guide Structure of This Guide This preface provides an overview of this guide, explains the symbols used throughout this guide, and instructs how to obtain technical support from Enterasys Networks. This guide provides information about the following: For... An overview of the 2G4072‐52 Network requirements that must be met before installing the 2G4072‐52 Installation instructions for the 2G4072‐52 hardware Troubleshooting installation problems and diagnosing network/operational problems using the LANVIEW LEDs Specifications, environmental requirements, and physical properties of the 2G4072‐52 and Mini‐GBICs Instructions to set the mode switches when necessary and to remove and replace DIMM and DRAM SIMM memory Related Documents The manuals listed below can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following site: http://www.enterasys.com/support/manuals • Enterasys Matrix N Standalone Series Configuration Guide provides information on how to use the Command Line Interface to set up and manage the DFE modules. • Cabling Guide provides information on dB loss and cable specifications. Unlike the Enterasys Matrix N Standalone Series Configuration Guide, the Cabling Guide is not listed alphabetically on the web site. Instead, it is listed under the Overview Guides ... -
Page 19: Document Conventions
Document Conventions Document Conventions This guide uses the following conventions: blue type Indicates a hypertext link. When reading this document online, click the text in blue to go to the referenced figure, table, or section. Note: Calls the reader’s attention to any item of information that may be of special importance. -
Page 20: Getting Help
• Network load and frame size at the time of trouble (if known) • The device history (for example, have you returned the device before, is this a recurring problem) • Any previous Return Material Authorization (RMA) numbers xviii Preface www.enterasys.com/services/support/ 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/ support@enterasys.com To expedite your message, type [SWITCHING] in the subject line. -
Page 21: Chapter 1: Introduction
This chapter provides an overview of the Enterasys Matrix N Standalone (NSA) Series 2G4072‐52 capabilities. Overview of Enterasys Matrix N Standalone (NSA) Series Capabilities The 2G4072‐52 provides robust functionality, including the following: • Superior performance and capacity to support more high‐bandwidth and latency sensitive applications • 10/100/1000 Base‐TX and 10 Gigabit Ethernet connectivity • Integrated Services Design that reduces the number/type of modules required, simplifies network design, and lowers entry cost • Port‐ and User‐Based Policy and Multilayer Packet Classification that provides granular control and security for business‐critical applications • High‐availability services with stateful failover for services and management • Self‐learning configuration modules with increased reliability and fault tolerance that reduces configuration time and maximizes uptime • Network‐wide configuration, change, and inventory management that is easier to install, troubleshoot, and maintain • Reduced support and maintenance costs, and decreased configuration time • Support for a variety of converged applications including VoIP with Power‐over‐ Ethernet Introduction N Standalone Series Installation Guide 1-1... -
Page 22: The 2G4072-52
The 2G4072-52 The 2G4072-52 This section provides an overview of the Enterasys Matrix N SA 2G4072‐52. For information about software features of the 2G4072‐52 and how to configure them, refer to the Enterasys Matrix N Standalone Series Configuration Guide. 2G4072-52 The Enterasys Matrix N SA 2G4072‐52 has 48, 10/100/1000BASE‐T/‐TX compliant ports, through fixed front panel RJ45 connectors and 4 Mini‐GBIC ports, as shown in Figure Each of the fixed front panel ports can operate in either half‐duplex or full‐duplex mode which can be determined by either auto‐negotiation or manual configuration. Enterasys Matrix N SA 2G4072‐52 ports can be configured to control traffic by limiting its rate and prioritizing it to expedite higher priority flows through the device. Figure 1-1 Connectivity Depending on how the 2G4072‐52 is configured, it can support up to 48, 10BASE‐T/ 100BASE‐TX switched ports connected through the front panel connectors. Management Management of the device can be either in‐band or out‐of‐band. In‐band remote management is possible using Telnet, Enterasys Networks’ NetSight application, or WebView™ application. Out‐of‐band management is provided through the RJ45 COM (Communication) port on the front panel using a VT100 terminal or a VT100 terminal emulator. Switch Configuration Using WebView Enterasys Networks’ HTTP‐based Web management application (WebView) is an intuitive web tool for simple management tasks. 1-2 Introduction 2G4072-52 Front Panel 1‐1. ® management ... -
Page 23: Switch Configuration Using Cli Commands
Switch Configuration Using CLI Commands CLI commands enable you to perform more complete switch configuration management tasks. For CLI command set information and how to configure the device, refer to the Enterasys Matrix N Standalone Series Configuration Guide. Standards Compatibility The Enterasys Matrix N SA 2G4072‐52 is fully compliant with the IEEE 802.3‐2002, 802.3ae‐2002, 802.1D‐1998, and 802.1Q‐1998 standards. It provides IEEE 802.1D‐1998 Spanning Tree Algorithm (STA) support to enhance the overall reliability of the network and protect against “looping” conditions. LANVIEW Diagnostic LEDs LANVIEW diagnostic LEDs, as shown in Figure troubleshooting aid by providing an easy way to observe the status of individual ports and overall network operations. Figure 1-2 1 LANVIEW LEDs LANVIEW LEDs Standards Compatibility 1‐2, serve as an important À N Standalone Series Installation Guide 1-3... - Page 24 LANVIEW Diagnostic LEDs 1-4 Introduction...
-
Page 25: Chapter 2: Network Requirements
1000BASE-SX/SX+/LX Network 1000BASE-T Network The network installation must meet the requirements to ensure satisfactory performance of this equipment. Failure to do so will produce poor network performance. Note: The Enterasys Matrix N Standalone Series Configuration Guide and the Cabling Guide referred to in the following sections can be found on the Enterasys Networks World Wide Web site: Link Aggregation Link Aggregation is a method of grouping multiple physical ports on a network device into one logical link according to the IEEE 802.3ad‐2002 standard. Because Link ... -
Page 26: 10Base-T Network
Note: The RJ45 ports support Category 5 UTP cabling with an impedance between 85 and 111 ohms for 100 Mbps operation. The 2G4072-52 is capable of operating at either 10 or 100 Mbps. It automatically senses the speed of the connected device and adjusts its speed accordingly. -
Page 27: Chapter 3: Installation
Connecting to the Network Connecting to the COM Port for Local Management Completing the Installation Read the Release Notes shipped with the 2G4072-52 to check for any exceptions to the supported features and operation documented in this guide. Unpacking the 2G4072-52 Unpack the 2G4072‐52 as follows:... -
Page 28: Rack Mounting
Rack Mounting Table 3-1 Contents of 2G4072-52 Item Matrix N Standalone Series 2G4072-52 Accessory Kit including: power cord, rack-mount ears, eight M4 x 6 mm flathead screws, DB9 to RJ45 converter, and adhesive feet Installation Guide Release Notes Inspect the Enterasys Matrix N SA 2G4072‐52 for any signs of physical damage. Contact Enterasys Networks if it is damaged. Refer to “Getting Help” on page xviii ... -
Page 29: Attaching Rack-Mount Ears To Enterasys Matrix N Sa 2G4072-52
Figure 3-1 Attaching Rack-mount Ears to Enterasys Matrix N SA 2G4072-52 Position the Enterasys Matrix N SA 2G4072‐52 in the rack and attach to the rack as shown in Figure 3‐2. Figure 3-2 Mounting Enterasys Matrix N SA 2G4072-52 to Rack Rack Mounting N Standalone Series Installation Guide 3-3... -
Page 30: Connecting Power
To connect the module to the power sources, refer to Figure Note: The two power supplies in the module have automatic voltage sensing that allows connection to power sources ranging from 100–125 Vac, 2.5 A or 200–240 Vac, 1.25 A, 50/60 Hz. To connect the module to the power sources, refer to Figure Plug a power cord into each switch AC power receptacle. To take advantage of redundancy capabilities, plug each power cord into a separate dedicated AC outlet. Plug the cord into a dedicated grounded AC outlet as shown in Figure Figure 3-3 Á 1 AC power cords Observe the LANVIEW LEDs. The Power (PWR) LED (not shown), located on the ... -
Page 31: Connecting To The Network
GBIC ports, refer to page 3‐9. Note: If the Enterasys Matrix N SA 2G4072-52 is being installed in a network using Link Aggregation, there are rules concerning the network cable and port configurations that must be followed for Link Aggregation to operate properly. Before connecting the cables, refer to the Enterasys Matrix N Standalone Series Configuration Guide for the configuration information. -
Page 32: Connecting A Twisted Pair Segment To The 2G4072-52
Verify that cabling is Category 5 UTP with an impedance between 85 and 111 ohms. If the port is to operate at 100 Mbps, Category 5 cabling must be used. Verify that the device at the other end of the twisted pair segment is on and properly connected to the segment. d. Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts and check the cable for continuity. Typically, a crossover cable is used between hub devices. A straight‐through cable is used to connect between switches or hub devices and an end user (computer). Refer to Figure Figure 3‐6 for four‐wire RJ45 connections. Refer to Figure 3‐7 and Figure eight‐wire RJ45 connections. 3-6 Installation Connecting a Twisted Pair Segment to the 2G4072-52 À 2 RJ45 port connector Á Â 3 GROUP SELECT button 3‐4) to step to the group of interest (Groups 1 3‐5 and 3‐8 for ... -
Page 33: Crossover Four-Wire Cable Rj45 Pinouts
Figure 3-5 Crossover Four-Wire Cable RJ45 Pinouts À Ã RJ45 device port RJ45-to-RJ45 crossover cable Other device port 4 RX+/RX- and TX+/TX- connections (must share a common color pair) Figure 3-6 Straight-Through Four-Wire Cable RJ45 Pinouts À Ã RJ45 device port 3 RJ45-to-RJ45 straight-through cable Other device port 4 RX+/RX- and TX+/TX- connections (must share a common color pair) -
Page 34: Eight-Wire Crossover Cable Rj45 Pinouts
Connecting to the Network Figure 3-7 1 RJ45 device port Figure 3-8 1 RJ45 device port 3-8 Installation Eight-Wire Crossover Cable RJ45 Pinouts À 2 Other device port Eight-Wire Straight-Through Cable RJ45 Pinouts À 2 Other device port Á Â 3 RJ45-to-RJ45 crossover cable Á... -
Page 35: Connecting Fiber-Optic Cables To Mini-Gbics
Ensure that the twisted pair connection meets the dB loss and cable specifications outlined in the Cabling Guide. Refer to “Related Documents” on page xvi for information on obtaining this document. If a link is not established, contact Enterasys Networks. Refer to “Troubleshooting”on page 4‐1 for details. Repeat steps 1 through 3 above, until all connections have been made. Connecting Fiber-Optic Cables to Mini-GBICs This section describes connecting 1‐Gigabit Ethernet fiber‐optic segments from the network or other devices to Mini‐GBIC MT‐RJ or LC port connectors in the Enterasys Matrix N SA 2G4072‐52. Each fiber‐optic link consists of two fiber‐optic strands within the cable: Transmit (TX) and Receive (RX). The transmit strand from a module port connects to the receive port of a fiber‐optic Gigabit Ethernet device at the other end of the segment. The receive strand of the applicable MT‐RJ port on the module connects to the transmit port of the fiber‐optic Gigabit Ethernet device (shown in Figure 3‐9) or LC cable connector (shown in Figure and Figure 3‐11). The procedure below describes how to connect an MT‐RJ cable (Figure Mini‐GBIC port connector. This procedure also applies to an LC cable connector shown in (Figure 3‐10 and Figure 3‐11). Refer to Figure Remove the protective covers (not shown) from the MT‐RJ fiber‐optic port on the Mini‐GBIC and from the connectors on each end of the cable. Note: Leave the protective covers in place when the connectors are not in use to prevent contamination. -
Page 36: Cable Connection To Mt-Rj Fiber-Optic Connectors
Connecting to the Network Insert the MT‐RJ cable connector into the Mini‐GBIC until it clicks into place. Note: To remove the MT-RJ cable connector, press on its release tab and pull it out of the Mini-GBIC. Figure 3-9 Å 1 Mini-GBIC (MGBIC-MT01) 2 Mini-GBIC 3 7-Pin edge connector (insertion side) 3-10 Installation Cable Connection to MT-RJ Fiber-Optic Connectors Á... -
Page 37: Cable Connection To Lc01 Or Lc09 Fiber-Optic Connectors
Figure 3-10 Cable Connection to LC01 or LC09 Fiber-Optic Connectors ➁ ➄ ➀ ➅ 1 Mini-GBIC (MGBIC-LC01 or -LC09) 2 Mini-GBIC top side 3 7-Pin edge connector (insertion side) Connecting to the Network ➃ 4 Port slot 5 Mini-GBIC protective dust cover 6 Release tab N Standalone Series Installation Guide 3-11... -
Page 38: Cable Connection To Lc03 Fiber-Optic Connectors
Connecting to the Network Figure 3-11 1 Port slot 2 Mini-GBIC-LC03 cable connector Verify a link exists by checking that the port RX LED is on (flashing amber, blinking green, or solid green). If the RX LED is off, perform the following steps until it is on: Verify the device at the other end of the segment is ON and linked to the segment. b. If there are separate fiber‐optic connections on the other device, check the crossover of the cables. Swap the cable connections if necessary. Check that the fiber‐optic connection meets the dB loss and cable specifications outlined in the Cabling Guide for multimode fiber‐optic cabling. To obtain this document, refer to “Related Documents” on page xvi. If a link has not been established, refer to Chapter a problem persists, refer to “Getting Help” on page xviii for support. Repeat steps 1 through 3, above, until all connections have been made. Plug the other end of the cable into the appropriate port on the other device. Some cables may be terminated at the other end with two separate connectors, one for each fiber‐optic strand. In this case, ensure that the transmit fiber‐optic strand is connected to the receive port and the receive fiber‐optic strand to the transmit port. 3-12 Installation Cable Connection to LC03 Fiber-Optic Connectors  Ã... -
Page 39: Connecting To The Com Port For Local Management
Connecting to the COM Port for Local Management This section describes how to install a UTP cable with RJ45 connectors and optional adapters to connect a PC, VT series terminal, or modem to an Enterasys Networks device to access Local Management. This section also details adapter pinout assignments. What Is Needed The following is a list of the parts that may be needed depending on the connection: • RJ45‐to‐DB9 female adapter (supplied in accessory kit) • UTP cable with RJ45 connectors (user‐supplied) • RJ45‐to‐DB25 female adapter (user‐supplied) • RJ45‐to‐DB25 male adapter (user‐supplied) With a UTP cable with RJ45 connectors and RJ45‐to‐DB9 adapter, you can connect products equipped with an RJ45 COM port to an IBM or compatible PC running a VT series emulation software package. With a UTP cable and an optional RJ45‐to‐DB25 female adapter, you can connect products equipped with an RJ45 COM port to a VT series terminal or VT type terminals running emulation programs for the VT series. With a UTP cable and an optional RJ45‐to‐DB25 male adapter, you can connect products equipped with an RJ45 COM port to a Hayes compatible modem that supports 9600 baud. Connecting to an IBM PC or Compatible Device To connect an IBM PC or compatible device, running the VT terminal emulation, to an ... -
Page 40: Connecting To A Vt Series Terminal
Figure 3-12 1 UTP cable with RJ45 connectors 2 RJ45 COM port Connecting to a VT Series Terminal To connect a VT Series terminal to a Enterasys Matrix N SA 2G4072‐52 COM port (Figure 3‐13), use a UTP cable with RJ45 connectors and an optional RJ45‐to‐DB25 female adapter. Proceed as follows: Connect the RJ45 connector at one end of the cable to the COM port on the Enterasys Networks device. Plug the RJ45 connector at the other end of the cable into the RJ45‐to‐DB25 female adapter. Connect the RJ45‐to‐DB25 adapter to the port labeled COMM on the VT terminal. 3-14 Installation Connecting an IBM PC or Compatible à  Á À... -
Page 41: Connecting To A Modem
Turn on the terminal and access the Setup Directory. Set the following parameters: When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix N Standalone Series Configuration Guide for further information. Figure 3-13 Connecting a VT Series Terminal à 1 UTP cable with RJ45 connectors 2 RJ45 COM port Connecting to a Modem To connect a modem to the device COM port (Figure connectors and an optional RJ45‐to‐DB25 male adapter, and proceed as follows: Connect the RJ45 connector at one end of the cable to the COM port of the module. Plug the RJ45 connector at the other cable end into the RJ45‐to‐DB25 modem adapter. Connect the RJ45‐to‐DB25 adapter to the communications port on the modem. Connecting to the COM Port for Local Management Parameter Setting Mode 7 Bit Control... -
Page 42: Connecting To A Modem
Connecting to the COM Port for Local Management Turn on the modem. With a PC connected to a remote modem, you can configure the switch remotely. To do so, you must configure your PC VT emulation package with these parameters. When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix N Standalone Series Configuration Guide for further information. Figure 3-14 1 UTP cable & RJ45 connectors 2 RJ45 COM port 3-16 Installation Parameter Mode Transmit Bits Parity Stop Bit Connecting to a Modem Ä Ã 3 RJ45-to-DB25 modem adapter... -
Page 43: Adapter Wiring And Signal Assignments
Adapter Wiring and Signal Assignments COM Port Adapter Wiring and Signal Diagram RJ45 VT Series Port Adapter Wiring and Signal Diagram RJ45 Connecting to the COM Port for Local Management Conductor Blue Green Orange Yellow DB25 Conductor Red Blue Yellow Green ... -
Page 44: Completing The Installation
Completing the Installation Modem Port Adapter Wiring and Signal Diagram RJ45 Completing the Installation After installing the Enterasys Matrix N SA 2G4072‐52 and making the connections to the network, access the device management startup screen from your PC, terminal, or modem connection as described in the following section. Log-In Using a Console Port Connection Note: This procedure applies only to initial log-in and to logging in to a device not yet configured with administratively-supplied user and password settings. - Page 45 At the login prompt, enter one of the following default user names: – ro for Read‐Only access, – rw for Read‐Write access, or – admin for Super User access. (This access level allows Read‐Write access to all modifiable parameters, including user accounts.) Press Enter. The Password prompt displays. Leave this string blank and press Enter. The device information and Matrix prompt displays as shown in Figure The Enterasys Matrix N SA 2G4072‐52 is now ready to be configured. For information about setting the IP address and configuring Telnet settings for remote access to N Standalone Series management, refer to Chapter 3 in the Enterasys Matrix N Standalone Series Configuration Guide. The CLI commands enable you to initially set up and perform more involved management configurations. The Enterasys Matrix N Standalone Series Configuration Guide is available online at: http://www.enterasys.com/support/manuals Completing the Installation 3‐15. N Standalone Series Installation Guide 3-19...
-
Page 46: Matrix Startup Screen Example (N7 Chassis)
50 Minuteman Rd. Andover, MA 01810-1008 U.S.A. Phone: +1 978 684 1000 E-mail: support@enterasys.com WWW: http://www.enterasys.com (c) Copyright Enterasys Networks, Inc. 2003 Chassis Serial Number: Chassis Firmware Revision: xx.xx.xx Matrix N7(su)-> 3-20 Installation Matrix Startup Screen Example (N7 Chassis) xxxxxxxxxxxx... -
Page 47: Overview Of Shutdown Procedure
This chapter provides information concerning the following: For information about... Using LANVIEW Troubleshooting Checklist Overview of Shutdown Procedure Using LANVIEW The 2G4072‐52 uses a built‐in visual diagnostic and status monitoring system called LANVIEW. The LANVIEW LEDs (Figure status to aid in diagnosing network problems. Viewing the Receive and Transmit Activity On the 2G4072‐52, you can view the receive and transmit activity on the RX and TX LEDs. However, only one group of 20 ports may be viewed at a time on the 2G4072‐52. To view the receive and transmit activity on a group of ports, press the GROUP SELECT button (see Figure GROUP SELECT button is pressed, the GROUP LED lights up in sequence, indicating which group is selected. The receive and transmit activity for that group of segments is then indicated by the RX and TX LEDs for each port. 4‐1) allow quick observation of the network 4‐1) to step to the group of interest (Groups 1 through 3). Each time the Troubleshooting Refer to page... N Standalone Series Installation Guide 4-1... -
Page 48: Lanview Leds
Using LANVIEW Figure 4-1 1 Group Select button Table 4‐1 describes the LED indications and provides recommended actions. NOTE: The terms used in Flashing - an LED is flashing randomly. Blinking - an LED is flashing at a steady rate (approximately 50% on, 50% off). Solid - a steady LED light. No pulsing. Alternating - an LED is flashing in a steady rate other than 50% on, 50% off. - Page 49 Solid. Testing. Green Blinking. Image starts running. Solid. Functional. Solid. Processor in reset. Green Blinking. Indicates that the 2G4072-52 is in the process of shutting down. Amber Amber Alternating (67% on, 33% off). and off Indicates a shutdown is complete. The indication will hold for 60 seconds then automatically restart.
-
Page 50: Troubleshooting Checklist
No link to device. 4-4 Troubleshooting 4‐2 for a checklist of problems, Recommended Action Ensure the 2G4072-52 was installed properly according to the installation instructions in Chapter chassis has power. Refer to the Enterasys Matrix N Standalone Series Configuration Guide for proper setup procedures. -
Page 51: Overview Of Shutdown Procedure
Reenter the lost parameters as necessary. Refer to the Enterasys Matrix N Standalone Series Configuration Guide for the instructions to configure the device. If the problem persists, contact Enterasys Networks for technical support. (page 4‐6) N Standalone Series Installation Guide 4-5... -
Page 52: Recommended Shutdown Procedure Using Reset Button
Last Resort Shutdown Procedure Using RESET Button Caution: This method of shutting down a Enterasys Matrix N SA 2G4072-52 is not recommended except as a last resort, because all processes currently running on the module will be interrupted resulting in loss of frames. -
Page 53: A-1 Specifications
This appendix provides the following information: For information about... 2G4072-52 Specifications Mini-GBIC Input/Output Specifications Gigabit Ethernet Specifications COM Port Pinout Assignments Regulatory Compliance Enterasys Networks reserves the right to change specifications at any time without notice. 2G4072-52 Specifications Table A‐1 describes I/O ports, processors and memory, physical, and environmental specifications for the 2G4072‐52. Table A-1 Specifications Item 2G4072-52 Ports Ports 1 through 48 Mini-GBIC Ports Specifications Specification 48, 10BASE-T/100BASE-TX compliant ports via RJ45 connectors. -
Page 54: Mini-Gbic Input/Output Specifications
Mini-GBIC Input/Output Specifications Table A-1 Specifications (continued) Item Processors/Memory Processor Dynamic Random Access Memory FLASH Memory Physical Dimensions Approximate Weight Mean Time Between Failure (MTBF) Environmental Operating Temperature Storage Temperature Operating Relative Humidity Mini-GBIC Input/Output Specifications Mini‐Gigabit Ethernet port interfaces accept 1000BASE‐SX short wavelength or 1000BASE‐LX long wavelength fiber Mini‐GBICs (see Table Table A-2 Mini-GBIC Input/Output Port Specifications Item MGBIC-LC01 MGBIC-LC03... -
Page 55: Gigabit Ethernet Specifications
Gigabit Ethernet Specifications The following specifications for the Mini‐GBICs (shown in Table A‐1 through Table meet or exceed the IEEE 802.3z‐1998 standard. MGBIC-LC01 / MGBIC-MT01 Specifications (1000BASE-SX) Table A-1 MGBIC-LC01 / MGBIC-MT01 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Link Power Budget Table A-2 MGBIC-LC01 / MGBIC-MT01 Operating Range Item 62.5 µm MMF 62.5 µm MMF 50 µm MMF 50 µm MMF MGBIC-LC03 Specifications (1000BASE-SX) -
Page 56: Mgbic-Lc09 Specifications (1000Base-Lx
Gigabit Ethernet Specifications Table A-4 MGBIC-LC03 Operating Range Item 62.5 µm MMF 50 µm MMF MGBIC-LC09 Specifications (1000BASE-LX) Table A-5 MGBIC-LC09 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Link Power Budget Table A-6 MGBIC-LC09 Operating Range Item 62.5 µm MMF 50 µm MMF 50 µm MMF 10 µm SMF... -
Page 57: Mgbic-08 Specifications (1000Base-Elx
MGBIC-08 Specifications (1000BASE-ELX) Table A-7 MGBIC-08 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Maximum Input Power Link Power Budget (Full Duplex Only) 1. The maximum drive distance (up to 70 km) depends on the quality of the installed single-mode fiber- optic cable segment. -
Page 58: Com Port Pinout Assignments
COM Port Pinout Assignments COM Port Pinout Assignments The COM port is a serial communications port for local access to local management. Refer to the table below for the COM port pin assignments. Table A-3 COM Port Pin Assignments Signal Name Transmit Data (XMT) Data Carrier Detect (DCD) Data Set Ready (DSR) Receive Data (RCV) Signal Ground (GND) Data Terminal Ready (DTR) Request to Send (RTS) Clear to Send (CTS) Regulatory Compliance The 2G4072‐52 meets the safety and electromagnetic compatibility (EMC) requirements ... -
Page 59: Appendix B: Mode Switch Bank Settings And Optional Installations
Required Tools Setting the Mode Switches Memory Locations and Replacement Procedures Electrical Hazard: Do not remove the cover from the 2G4072-52 while power is applied to the unit. Hazardous voltages are present and could cause personal injury and/or damage the unit. Do not power up the 2G4072-52 again until the cover and screws are in place. -
Page 60: Required Tools
Precaución: Si desea modificar la configuración del interruptor, lea las secciones correspondientes para saber cuál será el resultado de hacerlo. Estas modificaciones a la configuración sólo debe realizarlas personal calificado. Figure B‐1 shows the locations of the mode switches and the switch settings for normal operation. These switches are set at the factory and rarely need to be changed. Switch definitions and positions are as follows: • Switches 1 through 6 – For Enterasys Networks use only. • Switch 7 – Clear Persistent Data. Changing the position of this switch clears Persistent Data on the next power‐up of the module. All user‐entered parameters, such as the IP address, module names, etc., are reset to the factory default settings. Once the module resets, you can either use the factory default settings or reenter your own parameters. B-2 Mode Switch Bank Settings and Optional Installations... -
Page 61: Mode Switch Location
Note: Do not change the position of Switch 8 unless it is necessary to reset the admin password to its factory default setting. Warning: Do not remove safety cover protecting the power supplies. Advertencia: No quitar tapa de seguridad que protege las fuentes de poder. -
Page 62: Memory Locations And Replacement Procedures
In the event that the Dual in Line Memory Module (DIMM) or DRAM Single In‐line Memory Module (SIMM) (FLASH memory) needs to be replaced, the following sections describe how to access, locate and replace these memory modules. If you have questions concerning the replacement of either memory module, contact Enterasys Networks. Location of DIMM and DRAM SIMM Memory Modules Figure B‐2 shows the locations of the DIMM and DRAM SIMM on the motherboard. Figure B-2 1 Motherboard B-4 Mode Switch Bank Settings and Optional Installations DIMM and DRAM SIMM Locations 2 DIMM Â Á À 3 DRAM SIMM... -
Page 63: Dimm Replacement Procedure
DIMM Replacement Procedure If the DIMM is defective and must be replaced, the following sections explain how to remove and install the DIMM. If you have questions concerning the replacement of the DIMM, contact Enterasys Networks. Removing the DIMM To remove the existing DIMM, proceed as follows: Follow steps 1 through 3 as instructed on (page B‐7). Locate the DIMM connector on the motherboard as shown in Figure Push the connector arms away from the DIMM, as shown in Figure simultaneously lift the DIMM enough to release it from the connector fingers. Figure B-3 Removing the Existing DIMM 1 Connector arms Rotate the DRAM SIMM upwards, then remove it from the connector fingers. Memory Locations and Replacement Procedures Á Â 2 DIMM N Standalone Series Installation Guide B-5 B‐2. -
Page 64: Installing The Dimm
Installing the DIMM To install a DIMM, refer to Figure Insert the DIMM down between the connector fingers. Pivot the DIMM downward so the tabs on the connector arms align with the two DIMM alignment notches. With the two connector arms spread outward, push the DIMM down between the connector arms. Then release the two connector arms to lock the DIMM into place. Figure B-4 1 DIMM 2 Connector fingers Replace the chassis cover by re‐attaching the provided screws. B-6 Mode Switch Bank Settings and Optional Installations B‐4 and proceed as follows: Installing the DIMM Ã Â Á 3 Connector arms 4 SIMM alignment notches (2) Ã Â... -
Page 65: Removing The Dram Simm
Removing the DRAM SIMM Place the 2G4072‐52 on a clean, static‐free surface. Remove the 12 screws securing the chassis cover, as shown in Figure Figure B-5 Removing Chassis Cover Memory Locations and Replacement Procedures B‐5. N Standalone Series Installation Guide B-7... -
Page 66: Dram Simm Connector Location
Figure B-6 Connector arms Installing the DRAM SIMM To install the memory module, refer to Figure Push the connector arms away from the DRAM SIMM far enough to insert the DRAM SIMM into the connector contacts. Insert the DRAM SIMM straight down between the connector contacts far enough for the tabs on the connector arms to align with the two DRAM SIMM alignment notches. Push the DRAM SIMM down into the connector contacts. Then rotate the two connector arms toward the DRAM SIMM to lock it into place. B-8 Mode Switch Bank Settings and Optional Installations DRAM SIMM Connector Location À Â 2 DRAM SIMM B‐6. Á À Connector contacts B‐7 and proceed as follows:... -
Page 67: B-7 Installing The Dram Simm
Figure B-7 Installing the DRAM SIMM 1 Connector arms 2 DRAM SIMM Replace the chassis cover by re‐attaching the provided screws. Memory Locations and Replacement Procedures à Á à  3 Connector contacts 4 DRAM SIMM alignment notches (2) N Standalone Series Installation Guide B-9... - Page 68 Memory Locations and Replacement Procedures B-10 Mode Switch Bank Settings and Optional Installations...
