Configuring VLAN

The ELS10-27MDU is pre-configured when shipped. Each of the 10Mbps
ports is a separate VLAN with only the CPU and the 100Mbps uplink port
as members of this VLAN. This provides for maximum security in a
Multiple Dwelling Unit environment. The VLAN configuration may be
changed, however, to suit different needs.

Adding a VLAN

To create a new VLAN, type:
vlan [add PORT-RANGE NAME VLAN-ID [IPADDR] [IPMASK]]
The port range is a number from 1 to 27.
The Name can be up to 32 ascii characters (optional).
The VLAN-ID is the hexidecimal id number. Pre-configured VLANs are
0x001 through 0x01c.
The IPADDR is the IP address of the unit to be added.
The IPMASK is the IP mask for the IP addresses.

Deleting a VLAN

To delete a VLAN, type:
vlan [del[ete] PORT-RANGE {NAME | VLAN-ID}]
The port range is a number from 1 to 27.
The NAME | VLAN-ID identifies the VLAN to be deleted either by ascii
character name or by hexidecimal id number.
