Section 6, Wiring the Electrical System
NOTICE
6-6
6.5
What NOT TO DO
Never shut off power to the heater via an inline battery or
master switch while the system is running. Never disconnect
the battery when the heater is running, and never disconnect
the battery while the inverter is charging.
Doing either will severely damage the heater because it fails to
automatically purge the combustion chamber. Such damage is
detectable upon inspection and will not be covered under
warranty. Always shut the system off using the normal system
controls, after it has completed its purge.
When running in bypass mode, never leave the heater
unattended.
6.6
Procedure
Consult the following table for required wire gauges and
lengths. Consult Figures 6-4 to view how various components
are connected.
CONDUCTOR SIZES (GAUGE) FOR 3% DROP IN VOLTAGE
Length of Conductor from Source of Current to Device and Back to
Source – Feet
10 15 20 25 30 40 50 60 70 80 90 100
AMPS
5
- 18 16 14 12 12 10 10 10
10 -
14 12 10 10 10
15 -
12 10 10
20 -
10 10
8
ã
American Boat and Yacht Council, Inc.
1
Mount the control box as close to the heater as possible.
Mount it vertically, not horizontally. Do not mount the
control box where it is exposed to excessive heat.
Installation Manual for Oasis® Zephyr™ HW Heating System
8
6
6
8
8
6
6
6
6
6
6
4
4
8
8
8
6
6
6
4
4
4
4
2
2
2
2
2
2
