4. what's included

AcuFlow Digital model AF-D / AF-D-PM includes:
Fig 1.0 100-240VAC to
12VDC Power Supply (with
interchangable international
adapters for export markets)
Fig 1.4 For 1.5"(DN40),
2"(DN50), 2.5"(DN65)
AcuFlow models: New fl apper
with attached indicator arm
and magnet
Optional equipment and accessories not included as standard with AF-D / AF-D-PM:
Fig 1.6 Optional, 8M Fig 1.6 Optional, 8M
(26.25ft.) extension cable
www.h2fl ow.net • Tel: 888-635-0296 (Toll Free)
Fig 1.1 NEMA 4X enclosure
with pre-mounted Display
(AF-D) or standalone LCD
for existing cabinet mount
(AF-D-PM)
Fig 1.5 Type A to Type B
cable
Fig 1.7 Optional Auxiliary Fig 1.7 Optional Auxiliary
Interface Unit
Fig 1.2 Sensor with standard
cable
Fig 1.8 Optional,
AcuFlow unit. Required
for use with all 'new'
Digital installations. Sold
separately
4
(+1) 419-841-7774 (International)
OR
Fig 1.3 x2 extended length
lid screws
