H2flow ACUFLOW digital Operating Manual page 13

advanced setup cont.
Step 1 - Download and install the 'Advanced Panel Display' Configurator Software:
Launch an internet browser page and go to www.h2flow.net/acuflow-flow-meter and locate the 'Configurator Download'
section.
Click on the 'Configurator Download' button. When the Configurator has
finished downloading, open the file, either from your Downloads folder, or
from the bar at the bottom of your browser. Follow the prompts provided by
the Setup Wizard and when asked, click on 'Save As'. Save the file to your
preferred location. The default file name will be 'APM Configurator'.
After downloading the file, double-click on the icon labelled 'APM Configurator'.
You should then see an image on your desktop which resembles Fig 3.4 (right).
Click on the 'Updates' tab and make sure that the 'Automatic Updates' option is
checked. If 'Automatic Updates' was un-checked, please check this, and then
close the program and re-launch. If new updates are available, they will be
automatically downloaded and saved to your PC.
The Configurator program has now been successfully installed and your laptop
is ready to connect to the AcuFlow Display.
Step 2 - Programming the advanced features of the AcuFlow Digital Display
With the Configurator program still open, connect the Display to your PC using the Type A to Type B cable that was delivered
with your AcuFlow Digital (Fig 1.5).
The AcuFlow Digital screen should display the text 'US.b', and the Configurator should now look like Fig.3.5, below. Click on
the 'Configure APM' button.
www.h2flow.net • Tel: 888-635-0296 (Toll Free)
13
(+1) 419-841-7774 (International)
OR
Fig 3.4
Fig 3.5
