- Page 1 ASSEMBLY GUIDE Smeaton Outdoor Dining Bench...
-
Page 2: What You Need
Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Middle Rail x 1 Supporting Frame x 1 Leg x 2 Bench Top x 1... - Page 3 Attach the legs to the middle rail (2). Fit a washer Step 1 to a bolt and then insert the bolt into a hole. Fix the bolt with the Allen key but do not tighten it yet. Repeat this for the remaining holes. A x 4 B x 4 C x 1...
- Page 4 Align the structure formed in Step 1 with the sup- Step 2 porting frame and make sure the bolt holes over- lap. Fit a washer to a bolt and then insert the bolt into a hole. Fix the bolt with the Allen key but do not tighten it yet.
- Page 5 Place the bench top on a level surface with the Step 3 underside facing upward. Align the structure formed Step 2 with the table top and make sure the holes on the brackets overlap the holes on the table top. Fit a washer to a bolt and then insert the bolt...
- Page 6 Tighten all bolts with the Allen key (C). Step 4 C x 1...
- Page 7 Place the bench upright on a level surface. Enjoy Step 5 your new outdoor dining bench!
