KNOB

DISCHARGE TUBE

LOCKING COLLAR

HEAD

ASSEMBLY

GAGING COLLAR

SEAL ASSEMBLY

PINCH VALVE

SPRING

PLASTIC CAP

CYLINDER

ASSEMBLY

SEAL

SEAL O-RING

(stainless steel ball

snaps inside cylinder,

and can always

remain installed)

01914-REVB�080414�ENGLISH

PARTS INCLUDED VARY DEPENDING ON PUMP

BOTTLE PUMPS

88521

88200

Need help?

Do you have a question about the 88521 and is the answer not in the manual?

Page 1 01914-REVB�080414�ENGLISH BOTTLE PUMPS PARTS INCLUDED VARY DEPENDING ON PUMP 88521 88200 KNOB DISCHARGE TUBE LOCKING COLLAR HEAD ASSEMBLY GAGING COLLAR SEAL SEAL ASSEMBLY SEAL O-RING PINCH VALVE SPRING PLASTIC CAP CYLINDER CYLINDER ASSEMBLY (stainless steel ball snaps inside cylinder, and can always...
Page 2 CLEAN-IN-PLACE PROCEDURE PUMP DISASSEMBLY PUMP CLEANING BEFORE FIRST USE AND AFTER USE DAILY OR FOR PUMPS BEFORE FIRST USE AND AFTER USE DAILY, DISASSEMBLE REGULARLY, DISASSEMBLE AND CLEAN PARTS. AND CLEAN PUMP. CLEAN-IN-PLACE IS A BASIC FOUR STEP PUMP FLUSHING FOR SAFE AND PROPER CARE, AND TO PREVENT PROCESS: CLEAN, RINSE, SANITIZE, AND RINSE.
Page 3 PUMP ASSEMBLY PUMP ASSEMBLY ALWAYS CLEAN PUMP THOROUGHLY BEFORE EACH USE AND AFTER USE DAILY. SEE PUMP DISASSEMBLY AND PUMP CLEANING. INSTALL SEAL O-RING INSIDE SEAL. • Apply food equipment lubricant on seal o-ring. INSTALL SEAL SECURELY ONTO HEAD ASSEMBLY PISTON.
Page 4 Warranty Period and any alleged defective unit must be returned to Server Products factory, freight prepaid. Upon receipt of any defective unit, Server Products, at its option, may either: (i) replace any equipment proved to be defective, (ii) remedy or repair such defect or (iii) refund the purchase price of the defective equipment in the form of a credit applicable to future purchases.
