RUPTELA FM-Eco4+ 3G E RS T Quick Start Manual

Make sure that you have:

• A computer with Windows 7/8/10
• An internet connection (or a predownloaded
• A USB A to USB mini (Type B) cable
•
Tools for installation and wire connection: a "+" type screwdriver, a panel removing tool, a wrench, a crimp
terminal, zip-ties (or double-sided tape)

Device overview

12 Pin cable

Indication LED patterns

LED Pattern
Once every second
GNSS
Once every 0.4
seconds
Once every 4 seconds
Once every 0.2
GSM
seconds
Always on
Always off
Once every 5 seconds
Periph.
Twice every 5 seconds
Three times every 5
seconds
All Once every 5 seconds
www.ruptela.com
FM-Eco4+ E RS T
Quick Start Guide
Q
Device Center)
GNSS antenna cable (if applicable)

Device pinout

Description No.
Accurate signal
1
No signal
2
Accurate signal
3
No signal
4
Link with the
5
server is open
6
No devices
connected
7
One device
connected
8
Two devices
connected
9
Three devices
10
connected
11
Sleep/deep sleep
mode
12
support@ruptela.com | +370 5 2045030
Indication LEDs
Pin Wire color
GND Black
1-Wire
Green/Yellow
DATA
DOUT2 Orange
RS232 TX Green
DIN4 Yellow
RS232 RX Blue
VIN Red
1-Wire
White/Red
POWER
DIN1 Pink
AIN1 Grey
DIN3 White
DOUT1 Purple
FM-Eco4+ 3G E RS T
Description
Ground
connection
1-Wire data
Digital output 2
RS232 TX
Digital input 4
RS232 RX
Power supply
6/12/24V
1-Wire power
Digital input 1
Analog input 1
Digital input 3
Digital output 1
1
