Summary of Contents for Ambient Weather TESA WS710

  • Page 1: Table Of Contents

    WS710 Wireless Indoor/Outdoor 8-Channel Thermo-Hygrometer with Daily Min/Max Display INSTRUCTION MANUAL Table of Contents 1. Introduction …………………………..……….………………………..2 2.Getting Started .……….…………………………….......2 2.1 Parts List ……….…………………………..…………………...2 2.2 Recommend Tools ……….……………………………..…..…..…..2 2.3 Thermo-Hygrometer Sensor Set Up .……….…………………..2 2.4 Display Console Set Up ……….………………………...…..…….5 2.4.1 Display Console Layout .……….………………….……..6 2.4.2 Sensor Operation Verification...
  • Page 2: Introduction

    1. Introduction Thank you for your purchase of the WS710 Wireless Indoor/Outdoor 8-Channel Thermo-Hygrometer with Jumbo Display. The following user guide provides step by step instructions for installation, operation and troubleshooting. 2.Getting Started Note: The power up sequence must be performed in the order shown in this section (insert batteries in the remote transmitter(s) first, Display Console second).
  • Page 3 Figure 1 2. BEFORE inserting the batteries, locate the dip switches on the inside cover of the lid of the transmitter. Figure 2 displays all four switches in the OFF position (factory default setting). Figure 2 3. Channel Number: The WS710 supports up to eight transmitters.
  • Page 4 DIP SWITCH FUNCTION Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 °F °C Table 1 5. Insert two AAA batteries. 6. After inserting the batteries, the remote sensor LED indicator will light for 4 seconds, and then flash once per 60 seconds thereafter. Each time it flashes, the sensor is transmitting data.
  • Page 5: Display Console Set Up

    8. Close the battery door. Make sure the gasket (around the battery compartment) is properly seated in its trace prior to closing the door. Tighten the set screw. 2.4 Display Console Set Up 1. Move the remote thermo-hygrometer(s) about 1.5m to 3m away from the display console (if the sensor is too close, it may not be received by the display console).
  • Page 6: Display Console Layout

    While in the search mode, the remote search icon will be constantly displayed. If you have more than one remote sensor (up to eight remotes are supported), the display will automatically toggle between sensors until all sensors have reported in. Do not touch any buttons until the remote sensor has reported in, or the radio search icon is no longer on, otherwise the remote...
  • Page 7: Sensor Operation Verification

    3. Temperature, Rate of Change indicator 4. Temperature units (°F or °C) 5. Humidity, Rate of Change indicator 6. Relative Humidity (%) 7. Humidity Comfort Icon 8. Reception Icon (solid when searching, flashes when updating) 9. Channel 1,2,3,4,5,6,7,8, indicator 2.4.2 Sensor Operation Verification Verify the indoor and outdoor humidity match closely with the console and sensor array in the same location (about 1.5 to 3 meters apart).
  • Page 8: Display Features

    4. Display Features 4.1 Comfort Icon The comfort icon is based on humidity ranges specified in Figure 7 . The icon is displayed for indoor humidity, remote channel 1 humidity and optional remote channels 2 through 8 humidity. RH<45% RH45%~65% RH>65% Comfortable Figure 7...
  • Page 9: Indoor/Outdoor Channel Selection

    3. Display Minimum. Press the MIN/MAX button again to display the minimum. The MIN icon will be displayed. 4. Clear Minimum. To reset the minimum values to the current values, press and hold the CLEAR button for 3 seconds. To return to normal mode, press the MIN/MAX button again. 5.2 Indoor/Outdoor Channel Selection Press the CHANNEL/+ button to switch the display between the indoor temperature and humidity...
  • Page 10: Adjustment Or Calibration

    1. Electro-Magnetic Interference (EMI). Keep the console several feet away from computer monitors and TVs. 2. Radio Frequency Interference (RFI). If you have other 433 MHz devices and communication is intermittent, try turning off these other devices for troubleshooting purposes. You may need to relocate the transmitters or receivers to avoid intermittent communication.
  • Page 11: Humidity Calibration

    The purpose of your weather station is to measure conditions of your surroundings, which vary significantly from location to location. 5.6.1 Humidity Calibration Prior to entering the calibration mode, press the CHANNEL/+ button to select the humidity sensor you wish to adjust. To enter the humidity calibration mode, press and hold the ADJUST and MIN/MAX buttons at the same time for 5 seconds and the humidity value will begin flashing.
  • Page 12: Glossary Of Terms

    6. Glossary of Terms Term Definition Accuracy is defined as the ability of a measurement to match Accuracy the actual value of the quantity being measured. A hygrometer is a device that measures relative humidity. Hygrometer Relative humidity is a term used to describe the amount or percentage of water vapor that exists in air.
  • Page 13: Troubleshooting Guide

    Battery life: Minimum 12 months for base station with one sensor ● and excellent reception. Intermittent reception and multiple sensors may reduce the battery life. Minimum 12 months for thermometer-hygrometer sensor (use lithium batteries in cold weather climates less than -20°C) 8.
  • Page 14 Problem Solution Move the display console around electrical noise generating devices, such as computers, TVs and other wireless transmitters or receivers. Move the remote sensor to a higher location. Move the remote sensor to a closer location Make sure the thermo-hygrometer is Temperature sensor mounted in a shaded area on the north facing reads too high in the...
