HARDWARE GUIDE
INF6511
009-1610-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INF6511 and is the answer not in the manual?

Questions and answers

Related Manuals for InFocus INF6511

Summary of Contents for InFocus INF6511

  • Page 1 HARDWARE GUIDE INF6511 009-1610-01...

  • Page 3: Table Of Contents

    CONTENTS Declaration of Conformity ..............................3 Safety Considerations .................................4 安全資訊 ....................................5 What’s Included ..................................7 Setup ....................................8 Mounting ..................................8 Connecting to other devices ............................9 Connecting AC power ..............................12 External PC touchscreen control setup ........................12 Turning the Monitor On/Off ...............................12 Setting up the Wireless Mouse and Keyboard ........................13 Wireless mouse ................................13 Wireless keyboard ...............................13 Using the Remote ................................14...

  • Page 5: Declaration Of Conformity

    Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. SRS TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.

  • Page 6: Safety Considerations

    SAFETY CONSIDERATIONS Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and may damage or impair protection provided by the equipment.

  • Page 7: 安全資訊

    • Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty.
  • Page 8 • 如果您需要使用附帶的超細纖維清潔布進行清潔，請拔掉顯示器插頭。電源關閉時，可使用清潔布擦拭螢幕。切勿在顯 示器上使用酒精、溶劑或含氨 液體。 • 操作顯示器附帶的線纜後需要洗手。 • 顯示器遙控器利用電池工作。一些型號在發運時還附有採用電池工作的滑鼠和鍵盤。請確保電池極性 (+/-) 正確對齊。按 照當地廢棄物品處理法規處理 廢舊電池。 • 僅使用符合此產品規格的適當耐火等級牆和支架安裝硬體，並遵守製造商的安裝指示。由額定安裝硬體使用不當或安裝 不當造成的任何損壞均不在保 修範圍內。 • 請向專業維修人員諮詢所有維修資訊。請勿卸下封蓋或封底。自行維修顯示器不僅會對您造成傷害，而且也會使保修失 效。 • 僅使用 InFocus 指定的更換零件。未經授權進行更換可能會造成火災、電擊或人身傷害，並可能使保修失效。 • 將顯示器安裝到牆上時，必須使用 8 枚公制（12 毫米）螺絲。此外，安裝介面應符合北美地區的 UL1678 標準。安裝方 法應結實牢固，足以承受顯 示器的重量（參見產品技術規格）。 • 遵守這些指示有助於確保使用壽命內顯示器的圖像品質。不遵守這些指示可能會影響保修。 • 鋰電池注意事項（僅適用于發運時配有內嵌 PC 箱的型號）：如果更換的電池類型不正確，可能會有爆炸的風險。應按 照製造商的建議，使用相同或同類型的電池進行更換。按照當地廢棄物品處理法規處理廢舊電池。 Page 6...

  • Page 9: What's Included

    (batteries not included) *Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For additional accessory options, such as stands, feet, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. INF6511 Hardware Guide...

  • Page 10: Setup

    SETUP Mounting This product does not ship with mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • Only use properly rated wall and stand mounting hardware that meet this product’s specifications and follow the manufacturer installation instructions.

  • Page 11: Connecting To Other Devices

    2.0-A (4), USB 3.0-A (2), Audio Out RCA (1-R/L), and HDMI Out (1). Antennas TOUCH CONTROL HDMI USB-A USB-A RJ45 RJ45 RS232 IN 1 Audio IN 2 Audio OUT VIDEO HDMI4 HDMI3 HDMI2 HDMI1 PC IN COMPONENT INF6511 Hardware Guide Page 9...
  • Page 12 TOUCH TOUCH CONTROL Connect a Type A to Type B USB cable from the monitor to an external CONTROL computer in order to use the touchscreen gestures on the monitor. Connect a wireless mouse, USB thumb drive or other USB device to this USB 1-4 USB Type A 2.0 connector.
  • Page 13 Connect a 3.5mm audio cable to an external device (e.g., iPod player). IN 1 Audio AUDIO IN2 Connect an RCA L/R audio cable to an external device. IN 2 Audio OUT AUDIO OUT Connect an RCA L/R audio cable to external stereo speakers. INF6511 Hardware Guide Page 11...

  • Page 14: Connecting Ac Power

    Connecting AC power Connect one end of the AC power cord to the AC In jack on the back of the monitor. Connect the other end of the AC power cord to an AC outlet. Press the power switch. (The LED on the front of the monitor turns on.) NOTES: • Your monitor should only be operated from the power source indicated on the label.

  • Page 15: Setting Up The Wireless Mouse And Keyboard

    Insert two (2) AAA batteries (not included) into the keyboard, by aligning the + and – ends of the batteries and sliding them in place. Replace the cover. Press the CONNECT button and hold it for one second to allow the keyboard to bind with the dongle. INF6511 Hardware Guide Page 13...

  • Page 16: Using The Remote

    USING THE REMOTE The remote uses two (2) AAA batteries (not included). Install the batteries by removing the cover from the remote’s back, aligning the + and – ends of the batteries, sliding them in place and replacing the cover. To operate, point the remote at the monitor sensor at the bottom right-hand corner of the monitor.
  • Page 17 Onscreen Menu features. Info: Displays source information. INFO Vol up: Increases the audio volume. VOL UP Vol down: Decreases the audio volume. VOL DOWN Mute: Switches the audio on or off. MUTE INF6511 Hardware Guide Page 15...

  • Page 18: Using The Keypad

    Freeze: When enabled, freezes the image which is currently displayed. Blank: Toggles between the source and a blank black screen. Dimming: Adjusts brightness level. USING THE KEYPAD The keypad, located on the side of the monitor, has the following buttons: Power button: Switches the power on or puts the monitor into Standby.

  • Page 19: Osd (On-Screen Display) Menu System

    Adjust Enter Back Quit Adjust Enter Back Quit Adjust Enter Back Quit ADVANCED OPTION GAMMA SELECTION MODE1 OVER SCAN IR CONTROL NORMAL KEYPAD CONTROL LOCK DDC/CI ADVANCED OPTION RESET < > Adjust Enter Back Quit INF6511 Hardware Guide Page 17...

  • Page 20: Picture

    Picture PICTURE BRIGHTNESS CONTRAST SHARPNESS NATIVE COLOR TEMPERATURE COLOR CONTROL GREEN BLUE STANDARD PICTURE MODE PICTURE RESET < > Adjust Enter Back Quit Brightness: changes the intensity of the image. Range: 0-100. (Default 70.) Contrast: controls the degree of difference between the lightest and darkest parts of the picture and changes the amount of black and white in the image.

  • Page 21: Screen

    Dimming: Adjusts brightness level. Options: 10, 30, 70 or 100. (Default 70.) Aspect Ratio: adjusts the ratio of the image width to image height. Options: 4:3 and Wide. (Default Wide.) Screen Reset: resets all Screen menu items to factory default settings. Options: Yes and No. INF6511 Hardware Guide Page 19...

  • Page 22: Audio

    Audio AUDIO SPEAKER INTERNAL AUDIO SOURCE MONDOPAD AUDIO RESET < > Adjust Enter Back Quit Speaker: controls whether both the internal and external speakers (sound bar, etc.) or just external speakers are used. Options include: Internal (both internal and external speakers operate) and External (only external speakers operate). Default Internal.

  • Page 23: Pip

       HDMI1       HDMI2       HDMI3      HDMI4      Mondopad      INF6511 Hardware Guide Page 21...

  • Page 24: Configuration 1

    Configuration 1 CONFIGURATION 1 LANGUAGE ENGLISH AUTO SOURCE USB HUB SWITCH AUTO CONFIGURATION RESET FACTORY RESET < > Adjust Enter Back Quit Language: switches the OSD menu language. Auto Source: When enabled, automatically searches for an active source. If no source is detected, the device will revert to the previously active source.

  • Page 25: Configuration 2

    OSD V Position: adjusts the vertical position of the OSD menu. Range: 0-100. (Default: 50) OSD Rotation: rotates the image to either a landscape or portrait mode. Options include: Portrait and Landscape. Monitor Information: This read-only submenu displays the model name, serial number, operation hours, and software version. INF6511 Hardware Guide Page 23...

  • Page 26: Advanced Option

    Advanced option ADVANCED OPTION GAMMA SELECTION MODE1 OVER SCAN IR CONTROL NORMAL KEYPAD CONTROL LOCK DDC/CI ADVANCED OPTION RESET < > Adjust Enter Back Quit Gamma Selection: adjusts the gamma value of the image and optimizes image brightness and contrast. Options include: Mode 1, Mode 2, Mode 3.

  • Page 27: Troubleshooting

    • Verify you are pointing the remote at the table and are within 26’ (8m) and 30 degrees (horz/vert) of the sensor. • Verify that the IR Control setting in the Advanced Option OSD menu is set to Normal. INF6511 Hardware Guide Page 25...
  • Page 28 Keypad and/or mouse is not • Make sure the batteries are installed in the proper orientation and are not dead. working • Press the Connect button on the bottom of the keypad. • Verify the USB adapter is installed into the monitor's USB port. • Verify that the Keyboard Control setting in the Advanced Option OSD menu is set to Unlock.
  • Page 29 Verify that the power switch on the back of the unit is turned on; 3) Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage. For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support...

  • Page 30: Limited Warranty

    If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished...
  • Page 31 (l) if the product is not used under normal operating conditions which are defined as use not in excess of 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced.
  • Page 32 InFocus will provide it. You must assist in diagnosing issues with your product and follow InFocus’s warranty processes. InFocus may restrict service to the country where InFocus or its Authorized Distributors originally sold the hardware product. InFocus will provide warranty service either (i) at an ASP location, where service is performed at the Page 30...
  • Page 33 If during the diagnosis period, InFocus identifies that the repair can be accomplished by the use of a CSR part, InFocus will ship that part directly to you for replacement. There are two categories of CSR parts: • Parts for which customer self repair is mandatory. ...
  • Page 34 InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, OR 97223-8368 USA © 2015 InFocus Corp. All rights reserved. InFocus and the InFocus logo are trademarks of InFocus Corp., registered in the U.S. and other countries.

  • Page 35: 安全注意事項

    不應將明火火源如點燃的蠟燭等放在顯示器上。 • 使用所提供的電源線。將電源線連接到有安全保護（接地）接地端子的插座上。建議使用電湧保護電源排插。 • 建議將第 1 級顯示器接地。 • 不要將顯示器安裝在承受機械振動的地方。 • 不要將顯示器安置在不穩定的表面上，否則可能導致嚴重的人身傷害和顯示器損壞。將顯示器安裝到支架上時，一定要 遵守製造商的說明。僅使用制 造商推薦的安裝硬體。 • 在斷開電源線時，請握住插頭而非電線。 • 保護電源線使其免於踩踏或擠壓，尤其是插頭、電源插座處以及它們從顯示器退出的部位。 • 如果您不打算較長時間使用顯示器，則應拔下顯示器的電源線。 • 在需要使用附帶的超細纖維清潔布清潔顯示器時，應拔下顯示器的電源線。螢幕的擦拭工作應當在電源關閉時使用清潔 布進行。切勿在顯示器上使用 酒精、溶劑或腐蝕性的液體。 • 處理此顯示器隨附的線纜後請洗手。 • 顯示器遙控器、滑鼠和鍵盤使用電池。確保電池的極性（+/-）正確對齊。根據當地處理法規處理廢舊電池。 • 只使用符合本產品規格的適當規格的牆面和支架安裝硬體，並遵照製造商的安裝說明。保修範圍不包括因使用不當規格 安裝硬體或安裝不當而造成的 任何損壞。 • 應向合格的維修人員諮詢所有服務資訊。不要取下蓋子或背板。自行維修顯示器是危險的做法，將導致保修失效。 • 只使用富可視公司指定的更換零部件。未經認可的代用品可能會導致火災、觸電或人身傷害，並可能導致保修失效。 INF6511 Hardware Guide Page 33...
  • Page 36 • 在將顯示器安裝到牆上時，必須使用 M8 (12 毫米) 規格的螺栓。此外，安裝介面應符合北美 UL1678 標準。安裝方 式應牢固到足以承受顯示器的重量。 • 請遵照以下說明，以確保顯示器使用壽命期間的圖像品質。不遵守這些說明可能會影響保修。 • 鋰電池（PC 主機殼中的）注意事項：如果更換的電池類型不正確，則有爆炸的危險。更換的電池應為相同類型，或製 造商推薦的等效類型。根據當地 處理法規處理廢舊電池。 Page 34...

  • Page 37: Bigtouch 65"顯示器I/O Port 介紹前/後面板

    BigTouch 65”顯示器I/O port 介紹前/後面板 Antennas TOUCH CONTROL HDMI USB-A USB-A RJ45 RJ45 RS232 IN 1 Audio IN 2 Audio OUT VIDEO HDMI4 HDMI3 HDMI2 HDMI1 PC IN COMPONENT TOUCH TOUCH CONTROL CONTROL 將USB纜線從顯示器連接至外部電腦，以便使用觸控模組。 直接存取USB磁碟機上的多媒體檔案。 INF6511 Hardware Guide Page 35...
  • Page 38 VIDEO HDMI4 HDMI3 HDMI2 HDMI1 PC IN COMPONENT VIDEO 接受來自外部裝置（例如VCR或DVD播放器）的VIDEO信號。 HDMI4 接收外部裝置的HDMI信號。 HDMI3 接收外部裝置的HDMI信號。 HDMI2 接收外部裝置的HDMI信號。 HDMI1 接收外部裝置的HDMI信號。 PC IN 接收來自外部裝置（例如電腦）的類比RGB訊號。 接收來自外部裝置（例如DVD播放器,HDTV裝置或雷射光碟播放器）的色 COMPONENT 差視訊(YPbpr)訊號。 Page 36...
  • Page 39 HDMI OUT 將內部信號通過HDMI線纜輸出至另一台顯示器上。 USB-A 連接至USB 3.0/2.0硬碟機，數據傳輸。 HDMI USB-A USB-A RJ45 連接到乙太網絡 (10/100/1000 Mbps)。 RJ45 RJ45 RS232 連接外部數據機。 RS232 連接至麥克風。 AUDIO IN1 接收來自外部裝置（例如iPod播放器）所發出的音頻訊號。 IN 1 Audio AUDIO IN2 接收來自外部裝置（例如DVD播放器）所發出的音頻訊號。 IN 2 Audio OUT AUDIO OUT 連接到外接式立體聲喇叭。 INF6511 Hardware Guide Page 37...
  • Page 40 開啟或關閉顯示器。 選取/確認屏幕顯示(OSD) 功能表中的選項。 在OSD 功能表中向上捲動瀏覽各個設定和選項。 在OSD 功能表中向下捲動瀏覽各個設定和選項。 在OSD 功能表中向左捲動瀏覽各個設定和選項。 在OSD 功能表中向右捲動瀏覽各個設定和選項。 開啟或關閉OSD 功能表。 Page 38...
