Monitoring Your Server - BITMAIN ANTMINER S19a Pro Installation Manual

4.

Monitoring Your Server

To check the operating status of your server:
1. Click dashboard marked below to check the server status.
Note: The S19a Pro server is with fixed frequency 600 MHz. Firmware will stop running when the Temp
(Outlet) reaches to 95℃，there will be an error message "over max temp, pcb temp (real-time temp)"
shown on the bottom of kernel log page. Meanwhile, the server temperature on the dashboard interface
turns to abnormal and shows "Temp is too high".
2. Monitor your server according to the descriptions in the following table:
Option
Number of chips
Frequency
Real Hashrate
Inlet Temp
Outlet Temp
Chip state
Number of chips detected in the chain.
ASIC frequency setting.
Real-time Hashrate of each hash board (GH/s).
Temperature of the inlet (°C).
Temperature of the outlet (°C).
One of the following statuses will appear:
●
The Green Icon - indicates normal
●
The Red Icon- indicates abnormal
- 12 -
S19a Pro Server Installation Guide
Description
4. Monitoring Your Server
