S17, S17 Pro Server

Installation Guide

Bitmaintech Pte.Ltd. (Bitmain) reserves the right to make corrections, modifications, enhancements,

improvements, and other changes to its products and services at any time and to discontinue any

product or service without notice.

Customers should obtain the latest relevant information before placing orders and should verify that

such information is current and complete. All products are sold subject to Bitmain's terms and conditions

of sale supplied at the time of order acknowledgment.

Bitmain warrants performance of its products to the specifications applicable at the time of sale in

accordance with Bitmain's standard warranty. Testing and other quality control techniques are used to

the extent Bitmain deems necessary to support this warranty. Except where mandated by government

requirements, testing of all parameters of each product is not necessarily performed.

Document Version 0.1

Apr. 2019

Need help?

Do you have a question about the ANTMINER S17 and is the answer not in the manual?

Questions and answers

Summary of Contents for BITMAIN ANTMINER S17

Page 1 Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are sold subject to Bitmain's terms and conditions of sale supplied at the time of order acknowledgment.
Page 2 Bitmain does not warrant or represent that any license, either express or implied, is granted under any Bitmain patent right, copyright or other Bitmain intellectual property right relating to any combination, machine, or process in which Bitmain products or services are used.
Page 3 S17, S17 Pro Server Installation Guide Table of Contents 1.Overview..............................4 1.1 S17, S17 Pro Server Components...................... 5 1.2 Specifications............................. 7 2. Setting Up the Server..........................15 3. Configuring the Server..........................17 4. Monitoring Your Server..........................19 5. Administering Your Server........................21 5.1 Checking Your Firmware Version.....................21 5.2 Upgrading Your System........................22 5.3 Modifying Your Password........................
Page 4 1. Overview The S17, S17 Pro servers are Bitmain’s newest versions in the S17 server series. Power supply APW9 is part of S17, S17 Pro servers. All S17, S17 Pro servers are tested and configured prior to shipping to ensure easy set up.
Page 5 S17, S17 Pro Server Installation Guide 1.Overview S17, S17 Pro Server Components The main components and controller front panel of S17, S17 Pro servers are shown in the following figure: ‐ 5 ‐...
Page 6 S17, S17 Pro Server Installation Guide 1.Overview APW9 Power Supply: Note: 1.Power supply APW9 is part of S17, S17 Pro servers. For detailed parameters, please refer to the specifications below. 2.Additional two power cords are needed. ‐ 6 ‐...
Page 7 S17, S17 Pro Server Installation Guide 1.Overview 1.2 Specifications Model No.: 240‐Aa Version: S17‐53T Value Product Glance Low Power Normal Crypto Algorithm/Coins SHA256/BTC/BCH Hashrate, TH/s 35~50.00 53.00 , Watt Reference power on wall 1470~2100 2385 Reference power efficiency on wall @25°C, J/TH 42.00 45.00 Value...
Page 8 S17, S17 Pro Server Installation Guide 1.Overview Server Size (Length*Width*Height, w/o 298.2*178.0*296.6 (2‐1) package),mm (2‐2) Net weight, kg 9.50 (2‐3) Noise, dBA @25°C Environmental Requirements Operation temperature,°C Storage temperature,°C ‐20 Operation humidity, RH(no condensation) Notes: (1‐1) In Low Power Mode, Max Hashrate is about Typ Hashrate *103% (1‐2) Min condition: 25°C, min J/TH, typical Hashrate Max condition: 40°C, max J/TH, max Hashrate...
Page 9 S17, S17 Pro Server Installation Guide 1.Overview Model No.: 240‐Aa Version: S17‐56T Value Product Glance Low Power Normal Crypto Algorithm/Coins SHA256/BTC/BCH Hashrate, TH/s 35.00~50.00 56.00 , Watt Reference power on wall 1470~2100 2520 Reference power efficiency on wall @25°C, J/TH 42.00.
Page 10 S17, S17 Pro Server Installation Guide 1.Overview (2‐3) Noise, dBA @25°C Environmental Requirements Operation temperature,°C Storage temperature,°C ‐20 Operation humidity, RH(no condensation) Notes: (1‐1) In Low Power Mode, Max Hashrate is about Typ Hashrate *103% (1‐2) Min condition: 25°C, min J/TH, typical Hashrate Max condition: 40°C, max J/TH, max Hashrate (1‐3) Caution: Wrong input voltage may probably cause server damaged...
Page 11 S17, S17 Pro Server Installation Guide 1.Overview Model No.: 240‐Aa Version: S17 Pro‐50T Value Product Glance Low Power Normal Turbo Crypto Algorithm/Coins SHA256/BTC/BCH Hashrate, TH/s 36~48.00 50~62.00 50.00 , Watt Reference power on wall 1296~1728 1975 2250~2790 Reference power efficiency on wall @25°C, J/TH 36.00.
Page 12 S17, S17 Pro Server Installation Guide 1.Overview Quantity of hash chips Quantity of hash boards Networking connection mode RJ45 Ethernet 10/100M Server Size (Length*Width*Height, w/o 298.2*178.0*296.6 (2‐1) package),mm (2‐2) Net weight, kg 9.50 (2‐3) Noise, dBA @25°C Environmental Requirements Operation temperature,°C Storage temperature,°C ‐20 Operation humidity, RH(no condensation)
Page 13 S17, S17 Pro Server Installation Guide 1.Overview Model No.: 240‐Aa Version: S17 Pro‐53T Value Product Glance Low Power Normal Turbo Crypto Algorithm/Coins SHA256/BTC/BCH Hashrate, TH/s 36~48.00 53.00 53~62.00 , Watt Reference power on wall 1296~1728 2094 2385~2790 Reference power efficiency on wall @25°C, J/TH 36.00.
Page 14 S17, S17 Pro Server Installation Guide 1.Overview Hardware Configuration Quantity of hash chips Quantity of hash boards Networking connection mode RJ45 Ethernet 10/100M Server Size (Length*Width*Height, w/o 298.2*178.0*296.6 (2‐1) package),mm (2‐2) Net weight, kg 9.50 (2‐3) Noise, dBA @25°C Environmental Requirements Operation temperature,°C Storage temperature,°C ‐20...
Page 15 Setting Up the Server To set up the server: The file IPReporter.zip is supported by Microsoft Windows only. Go to the following site: https://shop.bitmain.com/support.htm?pid=00720160906053730999PVD2K0vz0693 2. Download the following file: IPReporter.zip. 3. Extract the file. The default DHCP network protocol distributes IP addresses automatically.
Page 16 S17, S17 Pro Server Installation Guide 2.Setting Up the server 7. On the controller board, click the IP Report button. Hold it down until it beeps (about 5 seconds). The IP address will be displayed in a window on your computer screen. 8.
Page 17 S17, S17 Pro Server Installation Guide 3.Configuring the Server Configuring the Server Setting Up the Pool To configure the server: 1. click General Settings. S17 Server: S17 Pro Server: Note: There are three modes of Hashrate which u may adjust for S17 Pro server: Low Power mode, Normal mode and Turbo mode (High Performance Mode);...
Page 18 S17, S17 Pro Server Installation Guide 3. Configuring the Server 2. Set the options according to the following table: Option Description Pool URL Enter the URL of your desired pool. The S17, S17 Pro servers can be set up with three mining pools, with decreasing priority from the first pool (pool 1) to the third pool (pool 3).
Page 19 S17, S17 Pro Server Installation Guide 4. Monitoring Your Server Monitoring Your server To check the operating status of your server: 1. Click the status marked below. Here is an example of S17‐53T server running under Normal mode: Here is an example of S17 Pro‐ 53T server running under Turbo mode: Note: The S17, S17 Pro servers are with automatic frequency.
Page 20 S17, S17 Pro Server Installation Guide 4. Monitoring Your Server 2. Monitor your server according to the descriptions in the following table: Option Description ASIC# Number of chips detected in the chain. Frequency ASIC frequency setting. GH/S(RT) Hash rate of each hash board (GH/s). Temp(PCB) Temperature of each hash board (°C).
Page 21 S17, S17 Pro Server Installation Guide 5. Administering Your Server 5. Administering Your Server 5.1 Checking Your Firmware Version To check your firmware version: 1. In System, click the Overview tab. 2. File System Version displays the date of the firmware your server uses. In the example below, the server is using firmware version 20190408.
Page 22 5.2 Upgrading Your System Make sure that the S17, S17 Pro servers remain powered during the upgrade process. If power fails before the upgrade is completed, you will need to return it to Bitmain for repair. To upgrade the server’s firmware: 1.
Page 23 S17, S17 Pro Server Installation Guide 5. Administering Your Server 5.3 Modifying Your Password To change your login password: 1. In System, click the Administration tab. 2. Set your new password, then click Save & Apply. 5.4 Restoring Initial Settings To restore your initial settings 1.
Page 24 S17, S17 Pro Server Installation Guide Environmental Requirements Please run your server in accordance with the following requirements 1. Basic Environmental Requirements: 1.1. Climatic Conditions: Description Requirement Operating Temperature 0‐40℃ Operating Humidity 10‐90%RH (non‐condensing) Storage Temperature ‐20‐70℃ Storage Humidity 5‐95%RH（non‐condensing） Altitude <2000m 1.2.
Page 25 S17, S17 Pro Server Installation Guide 2.2 Requirements of Corrosive Gas Corrosive Gas Unit Concentration < 3 < 10 < 1 < 50 < 1 < 500 < 2 Note: ppb (part per billion) refers to the unit of concentration，1ppb stands for the volume ratio of part per billion.
Page 26 S17, S17 Pro Server Installation Guide Regulations: FCC Notice (FOR FCC CERTIFIED MODELS): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
