Summary of Contents for Fujitsu ASY9ASSCW
- Page 1 OPERATING MANUAL MANUAL DE FUNCIONAMIENTO COOLING MODEL ROOM AIR CONDITIONER WALL MOUNTED TYPE Indoor Unit ASY9ASSCW ASY9ASSTW ASY12ASQTW Outdoor Unit AOY9AGSC AOY9AGST AOY12ASQT KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE FUJITSU GENERAL LIMITED P/N9313483029-01...
- Page 2 Refer to the fold-out page on the cover.
- Page 3 Fig. 1 Fig. 2 OPERATION TIMER SWING Fig. 3 Fig. 5 Fig. 4 • º Ÿ ª≠ ™ & ¢ ∞ £ § ¶ ¡ – Fig. 6 Fig. 7 This figure shows the control display when all indicator lamps are on. It may differ from the actual display.
-
Page 4: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ........En-1 ADJUSTING THE DIRECTION OF FEATURES AND FUNCTIONS ......En-2 AIR CIRCULATION ..........En-9 NAME OF PARTS ..........En-3 SWING OPERATION ......... En-10 PREPARATION ............ En-4 MANUAL AUTO OPERATION ......En-10 OPERATION ............En-5 CLEANING AND CARE ........En-11 TIMER OPERATION .......... -
Page 5: Features And Functions
FEATURES AND FUNCTIONS AUTOMATIC OPERATION REMOVABLE INTAKE GRILLE Merely press the START/STOP button, and the unit will be- The indoor unit’s Intake Grille can be removed for easy clean- gin automatic operation in the Cooling or Dry mode as ap- ing and maintenance. -
Page 6: Name Of Parts
NAME OF PARTS Fig. 1 Indoor Unit Fig. 6 Remote Control Unit 1 Operating Control Panel (Fig. 2) I SLEEP button 2 MANUAL AUTO button J MASTER CONTROL button K SET TEMP. button ( 3 Remote Control Signal Receiver L Signal Transmitter 4 Indicator Lamps (Fig. -
Page 7: Preparation
PREPARATION CAUTION! Turn on the Power G Take care to prevent infants from accidentally swallowing batteries. Connect the Power Supply Plug (Fig. 1 C) to an electri- G When not using the remote control unit cal outlet; in the case of a direct line connection, turn for an extended period, remove the batteries to avoid possible leakage and on the circuit breaker. -
Page 8: Operation
OPERATION To Select Mode Operation Press the START/STOP button (Fig.6 R). The indoor unit’s OPERATION indicator lamp (red) (Fig. 3 5) will light. The air conditioner will start operating. Press the MASTER CONTROL button (Fig.6 J) to se- lect the desired mode. Each time the button is pressed, the mode will change in the following order. - Page 9 To Stop Operation Press the START/STOP button. The OPERATION indicator lamp (red) (Fig. 3 5) will go out. About Mode Operation G Depending on the room temperature at the time operation begins, the AUTO: During Cooling/Dry mode: operating mode will be switched automatically as shown in the Set the thermostat to a temperature set- accompanying table.
-
Page 10: Timer Operation
TIMER OPERATION To Use the OFF TIMER To Cancel the Timer Press the START/STOP button (Fig. 6 R) Press the CANCEL TIMER button. (if the unit is already operating, proceed to step 2). To Change the Timer Settings The Indoor Unit’s OPERATION Indicator Lamp (red) (Fig. 3 5) will light. Press the ON TIMER button/OFF TIMER button as required. -
Page 11: Sleep Timer Operation
SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Press the CANCEL TIMER button. -
Page 12: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF AIR CIRCULATION Vertical (up-down) direction of airflow is adjusted by pressing the Remote Control Unit’s AIR FLOW DIRECTION button. Hori- zontal (right-left) airflow direction is adjusted manually, by moving the Air Flow Direction Louvers. Whenever making horizontal airflow adjustments, start air conditioner operation and be sure that the vertical air direction louvers are stopped. -
Page 13: Swing Operation
SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING LOUVER button (Fig. 6 T). The SWING indicator lamp (orange) (Fig. 3 7) will light. In this mode, the Air Flow Direction Louvers will swing automatically to direct the air flow both up and down. -
Page 14: Cleaning And Care
CLEANING AND CARE G Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord. CAUTION! G Be sure the Intake Grille (Fig. 1 8) is installed securely. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as personal injury may result. -
Page 15: Troubleshooting
TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, disconnect the WARNING! Power Supply Plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. -
Page 16: Operating Tips
TROUBLESHOOTING Symptom Items to check See Page G Is the Power Supply Plug disconnected its outlet? CHECK ONCE Doesn’t operate at all: MORE G Has there been a power failure? — G Has a fuse blown out, or a circuit breaker been tripped? G Is the timer operating? 7 - 8 G Is the air filter dirty? - Page 17 OPERATING TIPS Temperature and Humidity Range Cooling Mode Dry Mode About 21-43 °C Outdoor temperature About 21-43 °C Indoor temperature About 18-32 °C About 18-32 °C G If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may operate to prevent internal circuit damage.
- Page 19 TYPE COOLING MODEL TIPO MODELO DE REFRIGERACIÓN ASY9ASSCW INDOOR UNIT UNIDAD INTERIOR ASY9ASSTW MODEL MODELO AOY9AGSC OUTDOOR UNIT UNIDAD EXTERIOR AOY9AGST SPECIFICATIONS POWER ....................... 220 V~50 Hz REFRIGERANT ....................R22 720 g COOLING DIMENSIONS & WEIGHT INDOOR UNIT MAX. CURRENT ....................5.6 A Height/Width/Depth ..............
