SPLIT TYPE ROOM AIR
CONDITIONER
WALL MOUNTED
Models
ASY9LSACW
ASY12LSACW AOY12LSAC
C O N T E N T S
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . .
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . .
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . .
REFRIGERANT SYSTEM DIAGRAM . . . .
ERROR CONTENTS . . . . . . . . . . . . . . . . . . . 5
PCB CIRCUIT DIAGRAM . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . .
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . .
STANDARD ACCESSORIES . . . . . . . . . . . 14
type
AOY9LSAC
1
2
3
4
7
9
12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fujitsu ASY9LSACW
Summary of Contents for Fujitsu ASY9LSACW
-
Page 1: Wall Mounted Type
Models Indoor unit Outdoor unit ASY9LSACW AOY9LSAC ASY12LSACW AOY12LSAC C O N T E N T S SPECIFICATIONS ..... . -
Page 2: Specifications
SPECIFICATIONS TYPE (COOL&HEAT INVERTER) (COOL&HEAT INVERTER) INDOOR UNIT ASY9LSACW ASY12LSACW OUTDOOR UNIT AOY9LSAC AOY12LSAC COOLING CAPACITY( ) : Range (kW) 2.6 (0.5~3.6) 3.5 (0.9~4.2) HEATING CAPACITY( ) : Range (kW) 3.6 (0.5~6.0) 4.8 (0.9~6.6) ELECTRICAL DATA POWER SOURCE FREQUENCY (Hz) - Page 3 D I M E N S I O N S Models : ASY9LSACW / AOY9LSAC ASY12LSACW / AOY12LSAC 2004.10.07...
-
Page 4: Circuit Diagram
CIRCUIT DIAGRAM Models : ASY9LSACW / AOY9LSAC ASY12LSACW / AOY12LSAC INDOOR UNIT OUTDOOR UNIT 2004.10.07... - Page 5 R E F R I G E R A N T S Y S T E M D I A G R A M Models : ASY9LSACW / AOY9LSACW ASY12LSACW / AOY12LSACW Muffler (2 pass) Compressor 3way-valve 2way-valve Indoor heat exchanger...
- Page 6 E R R O R C O N T E N T S Self-diagnosis function table (Flashing LED Display) Applicable model : ASY9LSACW, ASY12LSACW * Detailed Trouble Display (secondary level) can be indicated by pressing Test Operation button. Trouble Display (primary)
- Page 7 Trouble Display (primary) Detailed Trouble Display (by Test Button) Detailed Error Item Error Operation Timer Error Operation Timer Outdoor unit 0.5sec 0.1sec Current Trip 0.1sec 0.5sec Current trip error is 2nd time within control error 5 times blinking blinking 2 times start up >>Permanent stop CT Abnormal...
- Page 8 220 / 240V 50Hz GREEN / YELLOW I C 1 THERMAL FUSE BLACK uPD780024SGB-X09 CONTROLLER PCB ASEMBLY (MAIN PCB) ROOM TEMPERATURE THERMISTOR ASY9LSACW : EZ-00219HSE-C BLACK BLACK ASY12LSACW : EZ-0021CHSE-C PIPE TEMPERATURE THERMISTOR GRAY GRAY GREEN INDICATOR PCB EZ-00219HSE-D (F)
- Page 9 OUTDOOR PRINTED CIRCUIT BOARD CIRCUIT DIAGRAM CONTROLLER PCB ASSEMBLY ( MAIN PCB) POWER SOURCE AOY9LSAC : EZ-002LHUE-C 220 - 240V AOY12LSAC : EZ-002GHUE-C 50Hz N200500K SC-10-55JH MB90462-117 2004.10.07...
- Page 10 D I S A S S E M B LY I L L U S T R A T I O N Models : ASY9LSACW ASY12LSACW 2004.10.07...
- Page 11 Models : ASY9LSACW ASY12LSACW 2004.10.07...
- Page 12 Models : AOY9LSACW AOY12LSACW 2004.10.07...
- Page 13 P A R T S L I S T IN DOOR U N IT R ef. Part No. Ord. Description ASY9LSACW ASY12LSACW Q' ty Air Filter-L 9311027010 9311027010 Air Filter-R 9311028017 9311028017 Guide (Filter)-L 9311180012 9311180012 Guide (Filter)-R 9311254010 9311254010...
- Page 14 OUTDOOR UNIT Part No. R ef. Ord. Description AOY9LSAC AOY12LSAC Q' ty Blow Grill 9309929012 9309929012 Grip 9302061016 9302061016 Cabinet Front Panel, Painted 9309928053 9309928053 Electric Cover 9310979013 9310979013 Cabinet Rear Panel, Painted 9309870024 9309870024 Pulse Motor Valve 9900056018 9900056018 Base Assy, Painted 9310248027 9310248027...
-
Page 15: Standard Accessories
STANDARD ACCESSORIES Part No. Name and Shape ASY9LSACW ASY12LSACW Wall hook bracket 9312752010 Remote control unit 9312058013 Battery (penlight) 0600185534 Cloth tape 9310519004 Tapping screw 4 x 25 ) 0700076046 2004.10.07... - Page 16 0303G2168...
