TIPO
MODELO DE ARREFECIMENTO
UNIDADE INTERNA
MODELO
UNIDADE EXTERNA
FICHA TECNICA
ALIMENTAÇÃO .......................................................................................... 230 V~50 Hz
PRESSÃO MÁXIMA
ASPIRAÇÃO .............................................................................................. 1.160 kPa
ARREFECIMENTO
COMPRESSÃO ......................................................................................... 4.120 kPa
POTÊNCIA ................................................................................................... 2,75 kW
POTÊNCIA CONSUMIDA ........................................................................... 1,05 kW
REFRIGERANTE ........................................................................................ R410A 590 g
CORRENTE CONSUMIDA ............................................................................... 4,7 A
DIMENSÕES E PESO (LÍQUIDO)
COEFICIENTE DE EFICIÊNCIA ENERGÉTICA .................................................. 2,62
UNIDADE INTERNA
CORRENTE MÁX.
ALTURA/COMPRIMENTO/PROFUNDIDADE ........................ 257/808/187 mm
Arrefecimento .................................................................................................. 5,8 A
PESO .............................................................................................. 8,0 kg (NET)
UNIDADE EXTERNA
ALTURA/COMPRIMENTO/PROFUNDIDADE ........................ 535/695/250 mm
PESO ............................................................................................... 30 kg (NET)
TIPO
MODELO DE ARREFECIMENTO
UNIDADE INTERNA
MODELO
UNIDADE EXTERNA
FICHA TECNICA
ALIMENTAÇÃO .......................................................................................... 230 V~50 Hz
PRESSÃO MÁXIMA
ASPIRAÇÃO .............................................................................................. 1.160 kPa
ARREFECIMENTO
COMPRESSÃO ......................................................................................... 4.120 kPa
POTÊNCIA ..................................................................................................... 3,4 kW
POTÊNCIA CONSUMIDA ........................................................................... 1,33 kW
REFRIGERANTE ........................................................................................ R410A 720 g
CORRENTE CONSUMIDA ............................................................................... 6,2 A
DIMENSÕES E PESO (LÍQUIDO)
COEFICIENTE DE EFICIÊNCIA ENERGÉTICA .................................................. 2,56
UNIDADE INTERNA
CORRENTE MÁX.
ALTURA/COMPRIMENTO/PROFUNDIDADE ........................ 257/808/187 mm
Arrefecimento ................................................................................................... 7,3 A
PESO .............................................................................................. 8,0 kg (NET)
UNIDADE EXTERNA
ALTURA/COMPRIMENTO/PROFUNDIDADE ........................ 535/695/250 mm
PESO ............................................................................................... 32 kg (NET)
ASY9FSBCW
AOY9FSBC
COOLING MODEL
ROOM AIR CONDITIONER
ASY12FSBCW
AOY12FSBC
WALL MOUNTED TYPE
Indoor Unit
ASY9FSBCW
ASY12FSBCW
Outdoor Unit
AOY9FSBC
AOY12FSBC
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE INSTRUÇÕES
P/N9312355013-02
Advertisement
Related Manuals for Fujitsu AOY9FSBC
Summary of Contents for Fujitsu AOY9FSBC
- Page 1 ALTURA/COMPRIMENTO/PROFUNDIDADE ......257/808/187 mm Arrefecimento ....................7,3 A PESO ....................8,0 kg (NET) ASY9FSBCW UNIDADE EXTERNA ALTURA/COMPRIMENTO/PROFUNDIDADE ......535/695/250 mm PESO ....................32 kg (NET) ASY12FSBCW Outdoor Unit AOY9FSBC AOY12FSBC KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE FUJITSU GENERAL LIMITED P/N9312355013-02...
-
Page 2: Table Of Contents
MODELO SAFETY PRECAUTIONS ........En-1 OUTDOOR UNIT UNIDAD EXTERIOR ADJUSTING THE DIRECTION OF MODELLO AUSSENGERÄT APPARECCHIO ESTERNO AOY9FSBC ΜΟΝΤΕΛΟ UNITÉ EXTÉRIEURE ΕΞΩΤΕΡΙΚΗ ΜΟΝΑ∆Α FEATURES AND FUNCTIONS ......En-2 AIR CIRCULATION ..........En-9 ESPECIFICACIONES NAME OF PARTS ..........En-3 SWING OPERATION ......... En-10 ALIMENTACIÓN .................. -
Page 3: Features And Functions
FEATURES AND FUNCTIONS AUTOMATIC OPERATION REMOVABLE INTAKE GRILLE Merely press the START/STOP button, and the unit will be- The indoor unit’s Intake Grille can be removed for easy clean- gin automatic operation in the Cooling or Dry mode as ap- ing and maintenance. - Page 4 NAME OF PARTS Fig. 1 Indoor Unit Fig. 6 Remote Controller 1 Operating Control Panel (Fig. 2) I SLEEP button 2 MANUAL AUTO button J MASTER CONTROL button K SET TEMP. buttons ( 3 Remote Control Signal Receiver L Signal Transmitter 4 Indicator Lamps (Fig.
-
Page 5: Preparation
PREPARATION CAUTION! Turn on the Power G Take care to prevent infants from accidentally swallowing batteries. Connect the Power Supply Plug (Fig. 1 C) to an electri- G When not using the Remote Controller cal outlet; in the case of a direct line connection, turn for an extended period, remove the batteries to avoid possible leakage and on the circuit breaker. -
Page 6: Operation
OPERATION To Select Mode Operation Press the START/STOP button (Fig.6 R). The indoor unit’s OPERATION indicator lamp (red) (Fig. 3 5) will light. The air conditioner will start operating. Press the MASTER CONTROL button (Fig.6 J) to se- lect the desired mode. Each time the button is pressed, the mode will change in the following order. - Page 7 To Stop Operation Press the START/STOP button. The OPERATION indicator lamp (red) (Fig. 3 5) will go out. About Mode Operation G Depending on the room temperature at the time operation begins, the AUTO: During Cooling/Dry mode: operating mode will be switched automatically as shown in the Set the thermostat to a temperature set- accompanying table.
- Page 8 TIMER OPERATION To Use the OFF TIMER To Cancel the Timer Press the START/STOP button (Fig. 6 R) Press the CANCEL TIMER button. (if the unit is already operating, proceed to step 2). To Change the Timer Settings The Indoor Unit’s OPERATION Indicator Lamp (red) (Fig. 3 5) will light. Press the ON TIMER button/OFF TIMER button as required.
- Page 9 SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Press the CANCEL TIMER button.
- Page 10 ADJUSTING THE DIRECTION OF AIR CIRCULATION Vertical (up-down) direction of airflow is adjusted by pressing the Remote Controller’s AIR FLOW DIRECTION button. Horizon- tal (right-left) airflow direction is adjusted manually, by moving the Air Flow Direction Louvers. Whenever making horizontal airflow adjustments, start air conditioner operation and be sure that the vertical air direction louvers are stopped.
- Page 11 SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING LOUVER button (Fig. 6 T). The SWING indicator lamp (orange) (Fig. 3 7) will light. In this mode, the Air Flow Direction Louvers will swing automatically to direct the air flow both up and down.
-
Page 12: Cleaning And Care
CLEANING AND CARE G Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord. CAUTION! G Be sure the Intake Grille (Fig. 1 8) is installed securely. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as personal injury may result. -
Page 13: Troubleshooting
TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, disconnect the WARNING! Power Supply Plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. -
Page 14: Operating Tips
TROUBLESHOOTING Symptom Items to check See Page G Is the Power Supply Plug disconnected its outlet? CHECK ONCE Doesn’t operate at all: MORE G Has there been a power failure? — G Has a fuse blown out, or a circuit breaker been tripped? G Is the timer operating? 7 - 8 G Is the air filter dirty? - Page 15 OPERATING TIPS Temperature and Humidity Range Dry Mode Cooling Mode About 21-43 °C Outdoor temperature About 21-43 °C About 18-32 °C Indoor temperature About 18-32 °C G If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may operate to prevent internal circuit damage.
- Page 18 TYPE COOLING MODEL FÜR KÜHLEN TYPE MODÈLE REFROIDISSANT TIPO MODELO DE REFRIGERACIÓN TIPO MODELO PER RAFFREDDAMENTO ΤΥΠΟΣ ΜΟΝΤΕΛΟ ΨΥΞΕΩΣ SPECIFICATIONS POWER SUPPLY ..................230 V~50 Hz MAX. PRESSURE SUCTION ....................1,160 kPa COOLING DISCHARGE ....................4,120 kPa CAPACITY ....................2.75 kW INPUT POWER ....................
