User Instructions
This booklet contains important information concerning the proper and safe operation of your new amplifier..
AMPLIFIER
Made in Taiwan
UNiKA
P R O F E S S I O N A L
A U D I O
TD10000Q
HI-IMP
CH A
CH A
SIG
-20dB -15dB -10dB -4dB
Level
BRIDGE A+B
SIG
-20dB -15dB -10dB -4dB
CH B
HI-IMP
Level
HI-IMP
CH C
SIG
-20dB -15dB -10dB -4dB
Level
BRIDGE C+D
SIG
-20dB -15dB -10dB -4dB
CH D
HI-IMP
Level
VHF
CLIP
VPL
CPL
POWER
TEMP
MUTE
VHF
VPL
CPL
CLIP
TEMP
VHF
CLIP
VPL
CPL
PAL
TEMP
MUTE
VHF
VPL
CPL
CLIP
TEMP
05 Operation and Performance
TD10000Q
Index
01 Precautions
02 Introduction
03 Front Panel
04 Rear Panel
Advertisement
Table of Contents
Related Manuals for Unika TD10000Q
Summary of Contents for Unika TD10000Q
- Page 1 User Instructions This booklet contains important information concerning the proper and safe operation of your new amplifier.. TD10000Q AMPLIFIER Made in Taiwan HI-IMP CLIP CH A CH A -20dB -15dB -10dB -4dB POWER Level TEMP BRIDGE A+B MUTE -20dB -15dB -10dB -4dB...
-
Page 2: Important Precautions
TD10000Q AMPLIFIER Precautions Introduction Front Panel Rear Panel Operation and Performance This symbol, wherever it appears, CAUTION alerts you to the presence of RISK OF ELECTRIC SHOCK uninsulated dangerous voltage DO NOT OPEN inside the enclosure - voltage that may be sufficient to constitute a CAUTION: To reduce the risk of electrical risk of shock. -
Page 3: Installation
Introduction Congratulations and thank you for purchasing TD-10000Q amplifier. This amplifier is a representation of UNiKA’s continuing commitment to produce the best and highest quality audio products at an affordable price. This amplifier is designed to provide a big impact in sound reproduction. Please read and understand this manual completely before attempting to operate your new amplifier. -
Page 4: Front Panel
TD10000Q AMPLIFIER Front Panel Precautions Introduction Rear Panel Operation and Performance Front Panel HI-IMP CLIP CH A CH A -20dB -15dB -10dB -4dB POWER Level TEMP BRIDGE A+B MUTE -20dB -15dB -10dB -4dB CH B HI-IMP CLIP TEMP UNiKA Level... -
Page 5: Rear Panel
TD10000Q AMPLIFIER Rear Panel Precautions Introduction Front Panel Operation and Performance Rear Panel BALANCED INPUTS SPEAKER OUTPUTS GAIN VPL - VOLTA GE PEAK LIMITER 44dB WIRING NORMAL:CLASS 2 BRIDGED:CLASS 3 41dB VPL-MODE 141V CH D CH C CH B CH A... -
Page 6: Operation And Performance
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel Operation and Performance Signal flow blocks The TD Series amplifier has the same signal flow, and the same feature sets. The only internal differences are in the maximum output current per channel and VPL settings. -
Page 7: Headroom, Sensitivity And Vpl/Gain Settings
-0.3 / 0.7 +32 dB 2.7 / 1.1 +29 dB 5.7 / 1.5 +26 dB 8.7 / 2.1 +23 dB Figure 4 TD10000Q VPL and GAIN settings *) Headrom limited to +8dB at Gain set to +23dB at Max. VPL... -
Page 8: Unbalanced Input Connections
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel Audio Input and Output connections Balanced Input connections The XLR input connectors are electronically balanced, and wired according to the IEC268 standard (pin2 = hot). XLR input connector should be wired as follows:... -
Page 9: Speakon Output Connectors
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel Speakon Output connectors Refer to the instructions in this section if SPEAKER OUTPUTS WIRING NORMAL:CLASS 2 BRIDGED:CLASS 3 your amplifier is equipped with the CH D CH C+D CH B CH A+B speakon output connectors. -
Page 10: Amplifier Gain
Output Voltage Peak Limiter (VPL) Voltage Peak Limiter (VPL) is a unique feature in TD10000Q amplifier. It is used to select the maximum power available on each output channel. VPL levels are set using the rear-panel DIP-switches; eight level positions are offered. -
Page 11: Output Current Peak Limiter (Cpl)
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel The values for VPL are displayed as maximum Voltage Peak. To translate Voltage Peak into Vrms, you must divide the Voltage Peak values by 1.41(see table). The V peak... -
Page 12: Safe Operating Area Detector (Soad)
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel Safe Operating Area Detector (SOAD) The Safe Operating Area Detector (SOAD) compares output voltage against output current to enure that the output transistors are working inside their safe operating area. -
Page 13: High-Impedance Warning (Open Load)
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel The Attack time for the VHF protection is increasingly shorter at higher frequencies. For example, an ultrasonic continuous signal will cause the outputs to mute rapidly, where it will take several milliseconds for a 10KHz continuous signal to trigger the output mute. -
Page 14: Temperature Protection
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel If the CPL turns constant red, the output is muted, and the -4dB signal LED is on, then the amplifier has gone into maximum current protection. NOTE This situation is caused by an excessive input signal and is not due to a short circuit. -
Page 15: Level Adjust
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel Front-panel monitoring and adjustments Level indicators The front-panel displays an array of ten LED indicators for level and status monitoring of each amplifier channel. Indications related to signal levels are as... -
Page 16: Channel Indicators
TD10000Q AMPLIFIER Operation and Performance Precautions Introduction Front Panel Rear Panel Channel Indicators: Bridge mode (yellow) indicates if two channels are bridged using the DIP-switch on the rear panel. CPL, Current Peak Limiter (red), when flashing indicates the maximum possible ... -
Page 17: Specifications
TD10000Q AMPLIFIER SPECIFICATIONS General Number of channels Peak total output both channels driven 8800 W Peak output voltage per channel 141 V Max. output current per channel 35.5 A peak General Max. Output Power 2 ohms 4 ohms 8 ohms 16 ohms Per ch. - Page 18 P R O F E S S I O N A L A U D I O...
