Standard
A communication cable exiting from the top of the machines mast will connect to location P6 on the back of the console.
HUR-ERGOLINE
CONSOLE
•
The 1st cable exiting out of the top of the machine mast will connect to P6 on the back of the console.
•
The 2nd cable exiting out of the top of the machine mast is labeled "COMM". This cable will plug into a small black RJ45
connector and cable coming from the back of the console. It will also be labeled "COMM".
EXTERNAL CONNECTION
•
External connection for the HUR-ERGOLINE machine is located at the bottom of the left side cover.
Console Connections
Page 10 of 16
