Quick Setup List -

Page Setup Procedure
4 Uncrating
4 Battery Activation &
Installation
5 Rider Assembly
6 Check Fluid Levels
7 Mower Assembly
7 Lubrication
8 SAFETY CHECKS
9 Burnish Electric Clutch
9/2003
Steps to Perform
❏ Remove crate & banding.
❏ Place transmissions in PUSH position & roll off skid.
❏ Charge the battery (Note: proceed with other setup steps
while battery is charging).
❏ Test battery with hydrometer or load-tester.
❏ Install & secure battery.
❏ Install the seat and connect the seat switch
❏ Install ground speed control levers.
❏ Fill & check Engine oil level.
❏ Check transmission fluid level.
❏ Reduce & check tire pressures
(Front tires 40 psi, rear tires 15 psi).
❏ Torque mower blade bolts.
❏ Lubricate all grease & oil points.
❏ Check for LOOSE HARDWARE.
❏ Check all OPERATOR CONTROLS.
❏ Test PARKING BRAKE.
❏ Perform MOWER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
❏ Perform SAFETY INTERLOCK SYSTEM CHECK.
❏ Burnish electric clutch (run for 15 seconds, repeat 10 times) .
❏ Repeat MOWER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
3
Champion Series
TP 300-3883-02-CH-SN
