Porsche macan turbo with radio control
Hide thumbs
Table of Contents

Advertisement

Quick Links

®
Owner's Manual and Assembly Instructions
Model #: W416AC-RC, W16AC-WRC, W416AC-BRC, W416AC-RRC
Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colors may vary. Do not return to store. Call 1-888-982-9309 for assistance and
replacement parts.
IMPORTANT:
Save this manual with your sales receipt.
PORSCHE MACAN TURBO
WITH RADIO CONTROL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W416AC-RC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rollplay W416AC-RC

Summary of Contents for Rollplay W416AC-RC

  • Page 1 ® WITH RADIO CONTROL Owner’s Manual and Assembly Instructions Model #: W416AC-RC, W16AC-WRC, W416AC-BRC, W416AC-RRC Read and understand the entire manual before assembly and operation. The vehicle must be assembled by an adult who has read and understands the instructions.
  • Page 3 Introduction Thank you for purchasing this Rollplay vehicle. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please keep your sales receipt or register your product at www.rollplay.com.
  • Page 4 Call Customer Service if you need assistance or replacement parts. Please have your model number and serial number ready before calling. Please have proof of purchase. Keep your sales receipt or register your product at www.rollplay.com as we may require proof of purchase. Email customerservice@rollplay.com or call customer service 1-888-982-9309...

  • Page 5: Table Of Contents

    Table of Contents Safety ............5 Parts ............7 Charging Instructions ......8 Assemble the Front Wheels ....9 Assemble the Left Rear Wheel ....10 Assemble the Right Rear Wheel ..... 11 Attach the Seat ........12 Attach the Steering Wheel ...... 13 Attach the Mirrors ........

  • Page 6: Safety

    Safety WARNING: SAFETY RIDING RULES The user must follow all safety rules and guidelines, or serious injury or death may occur to the user. • Always use common sense and safe practices when using the vehicle. The user must be at least 3 •...
  • Page 7 Safety (Continued) WARNING: BATTERY SAFETY • Battery posts, terminals and related accessories contain lead and lead components. DO NOT open the battery. • Contact exposure to battery leakage (lead acid) may cause serious injury. Immediately contact your doctor if exposure occurs. If the chemical is on the skin, immediately give the person water or milk.

  • Page 8: Parts

    Parts 1. Steering wheel 8. Small washers (x5) 15. Steering wheel nut 2. Seat 9. Snap pins (x6) 16. Steering wheel screw 3. MP3 cable 10. Wheel covers (x4) 17. Mirrors (x2) 4. Car body 11. Front wheels (x2) 18. Blister pack 5.

  • Page 9: Charging Instructions

    Charging Instructions YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE THE FIRST USE! ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER. To Charge the Battery: 1. Ensure the car is stopped and the Seat power switch is turned off. 2.

  • Page 10: Assemble The Front Wheels

    Assemble the Front Wheels Correct Snap Pin Installation Small washer Small washer Front wheel Snap pin Wheel cover 1. Slide the small washer onto the front axle. 2. Slide the front wheel onto the front axle. 3. Slide another small washer onto the front axle. 4.

  • Page 11: Assemble The Left Rear Wheel

    Assemble the Left Rear Wheel Rear wheel Gear teeth Snap pin Large washer Inner wheel spacer Large washer Wheel cover Left Rear Wheel: 1. Slide the large washer onto the rear axle, then slide the inner wheel spacer onto the axle. 2.

  • Page 12: Assemble The Right Rear Wheel

    Assemble the Right Rear Wheel Large washer Wheel cover Gear box Snap pin Rear wheel Right Rear Wheel: 1. Slide the right rear wheel onto right rear wheel axle. The side with gear teeth faces inward. (Note: the gear teeth must engage with the gear box.) 2.

  • Page 13: Attach The Seat

    Assemble the Seat Seat Seat release button 1. Insert the two hooks on the back of the seat into the slots on the car body. Push down on the seat until it clicks into place. 2. When the seat needs to be removed, press the seat release button to unlock the seat.

  • Page 14: Attach The Steering Wheel

    Attach the Steering Wheel 1. Locate the steering wheel screw and nut from the blister box. 2. Plug the steering wheel connector (A) into the dashboard connector (B). 3. Gently tuck the wires into the dashboard. Insert the steering wheel onto the steering rod, and align the holes on the wheel with the holes on the rod.

  • Page 15: Attach The Mirrors

    Attach the Mirrors Insert the left mirror into the slot on the left door near the windshield. Push down on the mirror until it clicks into place. 3. Repeat steps 1-2 for the right mirror.

  • Page 16: Product Features

    Product Features Steering Wheel Buttons Shifter Battery Life MP3 Jack lndicator Tuning Reset Volume Dial Battery Life lndicator Button Pedal Power Button Power Button: Press the Power Button to turn on the car. The Power Button will light up when the car is on. Press the Power Button again to turn off the car. Shifter: Pull the Shifter up to move forward.

  • Page 17: Remote Operating Instructions

    Remote Operating Instructions AAA 1.5V Remote Control Battery Installation: Open the battery cover with a screwdriver. Place two "AAA" (AM-4/LR03) batteries into the battery compartment and replace the battery cover. Secure with the screw. Please note, the use of new alkaline batteries is recommended for optimal performance.
  • Page 18 Remote Operating Instructions Forward Left LED light Stop Speed adjustment Backward Right Operation of Remote Control: Forward/Reverse Buttons: Press the Forward Button, to move forward. Press the Backward Button, to move backwards. Speed Adjustment: The Speed Adjustment Button allows you to choose between 3 speeds.

  • Page 19: Maintenance

    Maintenance Important Battery and Charger Information • Only an adult who has read and understands the safety warnings may handle and operate the battery and battery charger. Keep away from children. • time. • Recharge the battery immediately after each use. Charge for at least 8-12 hours, but no more than 20 hours.

  • Page 20: General Care

    General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Regularly inspect the charger, cord, plug, and other related parts for damage. • Remove any damaged parts and immediately contact Customer Service for replacement parts. See Service and Repairs on Page 21 for more information.

  • Page 21: Troubleshooting Guide

    Troubleshooting Guide Completely read through the manual and troubleshooting guide before contacting Customer Service. Problem Potential Cause Solution Vehicle does not run Battery is low Recharge the battery Thermal fuse tripped Reset fuse Snap pins are loose Tighten snap pins Loose wires or loose Ensure the battery connectors connectors...
  • Page 22 Problem Potential Cause Solution Vehicle needs a push to Loose wires or loose Ensure the battery connectors start connectors are securely attached. If wires are loose, contact Customer Service “Dead spot” on motor A “dead spot” means electricity is not being delivered to the terminal.

  • Page 23: Fcc Information

    FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 24: Service And Repairs

    Service and Repairs Before returning your product to the store, contact Rollplay with questions. If your product requires service, repairs or replacement parts, please contact Rollplay Customer Service. Hours: 9 AM - 5 PM (CST), Monday - Friday 888-982-9309 Phone: 1- Email: customerservice@rollplay.com...
