This procedure describes how to upload new software from your USB drive and adjust the video
dubbing settings on the eSpinner.
To be able to use a dual language SD card on the eSpinner, the unit has to be uploaded with
software release, v1.04 or higher.

STEP 1 - Verify Software Version

To check the software version please follow the instructions below
1- On the start screen, press the start button.
2- A 3-touch sequence is needed to access the password entry dialog
box. Touch the locations on the workout options screen in the
sequence shown (
The password dialog box should now appear at the screen.
Note: Each location must be pressed within 1 second of the
previous location. If you are unable to access the password screen
after several attempts, you may need to re-calibrate the touch
screen.
, then
and then center of the
,
STAR TRAC BY UNISEN CONFIDENTIAL AND PROPRIETARY
1
)
logo
620-7907 REV A
Page 2 of 9
2
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eSpinner and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Star Trac eSpinner

Summary of Contents for Star Trac eSpinner

  • Page 1 This procedure describes how to upload new software from your USB drive and adjust the video dubbing settings on the eSpinner. To be able to use a dual language SD card on the eSpinner, the unit has to be uploaded with software release, v1.04 or higher.
  • Page 2 1.04 and higher is required to use the dual language SD card. If you have software 1.04 or higher you can proceed to step 3 if you do not want to upgrade software. Star Trac recommends always updating your eSpinner to the latest software available. 620-7907 REV A...
  • Page 3 STEP 2 – UPDATE SOFTWARE To update the software on the eSpinner you need to download the latest software from the Star Trac support website and load the software into a USB thumb drive. The file “spinner” and other language text files should be downloaded to the root directory of the USB drive, as shown below.
  • Page 4 3- After the password screen appears, type ‘218’ then ‘enter’ to gain entry into the Service Menu Screen. 4- Once in the Service Menu screen, press the Maintenance Mode button to enter Maintenance Menu screen. 620-7907 REV A Page 5 of 9 STAR TRAC BY UNISEN CONFIDENTIAL AND PROPRIETARY...
  • Page 5 If you do not automatically reset to the main menu the software did not update and you should go back to step 1 and repeat the process, verifying each step along the way. 620-7907 REV A Page 6 of 9 STAR TRAC BY UNISEN CONFIDENTIAL AND PROPRIETARY...
  • Page 6 3- After the password screen appears, type ‘218’ then ‘enter’ to gain entry into the Service Menu Screen. 620-7907 REV A Page 7 of 9 STAR TRAC BY UNISEN CONFIDENTIAL AND PROPRIETARY...
  • Page 7 When the enable languages option is selected, an audio menu option will populate in the list: Languages enabled Languages disabled Audio Menu 620-7907 REV A Page 8 of 9 STAR TRAC BY UNISEN CONFIDENTIAL AND PROPRIETARY...
  • Page 8 Use the more languages button to toggle between languages. 9- Exit audio language screen by pressing service menu button then main menu button. Changing audio language is now complete. 620-7907 REV A Page 9 of 9 STAR TRAC BY UNISEN CONFIDENTIAL AND PROPRIETARY...
