Quick Links
Download this manual
SA-82-AR
Hardware Installation Guide
FIRMWARE VERSION: 1.20.261
SOFTWARE VERSION: 2.00.03
© 2019 AMETEK Electronic Systems Protection | Technical Support: 1-800-645-9721 | UM-SA-82-AR-Rev-D
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for Ametek SURAGEX AXESS Reasy FLATPAK SA-82-AR
Surge Protector Ametek Surgex SA-20-AR User Manual
Axess-ready standalone surge elimination & power conditioning (27 pages)
Surge Protector Ametek Surgex SX1200 Series Installation Instructions
(5 pages)
Summary of Contents for Ametek SURAGEX AXESS Reasy FLATPAK SA-82-AR
Page 1
SA-82-AR Hardware Installation Guide FIRMWARE VERSION: 1.20.261 SOFTWARE VERSION: 2.00.03 © 2019 AMETEK Electronic Systems Protection | Technical Support: 1-800-645-9721 | UM-SA-82-AR-Rev-D...
Page 2
6. USER COMMANDS 7. EVENT COMMANDS VII. DxP PROTOCOL 1. OVERVIEW 2. HELLO HANDSHAKE 3. DXP PACKET 4. COMMANDS 5. DESCRIPTERS 6. PAYLOADS VIII. FIRMWARE UPGRADES RESET BUTTON SPECIFICATIONS © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 3
Located on the rear panel are the input IEC power plug, network connection (RJ-45), 8A circuit breaker, and output receptacles. The front panel contains the Outlet On LED, Self-Test LED, System On LED, and Reset button. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 4: Led Indicators
145V, and AC power will be removed from the output receptacles in order to protect connected equipment. When the AC voltage returns to below 135V, power will automatically be restored to the output receptacles and the System On LED will turn on. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 5
AR. The standard port for web browser accessibility is factory default Port 80. Add: Manually add an AR by IP address. Clear: Clear the list. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 6
All commands may be entered as required before rebooting. Manually specifying the IP address via CLI automatically sets the address as static. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 7
On (Blinking) The Reset button has been pressed for 5 or more seconds. Releasing the button will restore the AR to a factory default state. The outlets are Off. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 8: Web Server
If an NTP time server is being used, the time of the last refresh will be displayed in the upper right corner, as well as History log below the Power Status © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 9: Setup Pages
Closing the web browser will not log the user out, and may lock out web access. In this situation it will be necessary to access the AR via telnet and reboot the unit. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 10
Gateway: Enter the Gateway in dotted decimal format. This field will be automatically set if using DHCP. DNS: Enter the Domain Name Server address. This will be automatically set if using DHCP. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 11
Zone: Specify the time zone (-12 to +12) relative to GMT. Time DST Enable: Enable or disable the use of Daylight Savings Time. DST Start/Stop: Specify the start and stop times for DST. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 12
With OR logic, the action will be triggered if either AutoPing exceeds its fail count. With Single, only AutoPing 1 is used. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 13
Restart: This setting delays the restart of the AutoPing tests after the Action is completed. This setting allows time for the boot sequence of the failed device to complete. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 14
Action: Set the action to be scheduled. On, Off, or Cycle. • Enable: Enables the event when checked. Uncheck to disable the event. • Clear: Deletes a schedule. © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 15
New Password: Enter the new password to be used. • Confirm Password: Enter the new password to be used again. Default credentials: Role Username (fixed) Password (user set) Administrator admin admin User user user © 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com...
Page 16
Enables or disables the ability to upload new firmware. Login Prompts for admin credentials when logged in as user. Logout Terminates the telnet session. Reboot Reboots the AR. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 17
Web and Telnet are both disabled. Set linkback <url> This command sets the linkback URL displayed on the logout page. set timeout < 0-999 > Sets the automatic network timeout in minutes. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 18
Sets whether or not a user account is used. set login required <yes | no> Sets whether or not a login is required for user level operation. A login is always required for admin functions. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 19
< 1-8 > action < on | off | cycle > Sets the action to be performed at the scheduled time. del event < 1-8 > Deletes the scheduled event. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 20: Hello Handshake
Example: Client Server hello-000 → ← 1234 (seq 1234) Command → (seq 1235) ← Response Command → (seq 1237) ← Response © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 21
Payload The payload is determined by a combination of the command class and the descriptor. The payloads are described with the descriptor; see the Descriptors subsection for details. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 22
All of the descriptors and their payloads are outlined by command class below. eCmnd_set The descriptors for this command class will be product specific. eCmnd_get The descriptors for this command class will be product specific. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 23
This is the only valid descriptor that the keep alive command 0 → Successful 1 → Error supports. It is defined as null, as it carries no payload. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 24
Important: Upgrading the firmware with a minor upgrade (For example, 1.01.xx to 1.01.yy) will not alter the user defined settings. Major upgrades may or may not reset the AR to factory defaults. Check the release notes for the upgrade before making any changes. © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 25: Reset Button
Reset to Factory Defaults. Hold until the “System On” LED is blinking, then release. Hold while Recovery Mode. Allows upload of new firmware to the current IP address. powering up © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
Page 26: Specifications
IP Addressed: DHCP Assigned or Static Internal HTTP Web Server Forms Processing Browser Required Internal Telnet Server *1.2 x 50 µs pulse, industry standard combination wave surge,as per IEEE C62.41 © AMETEK Electronic Systems Protection, Inc. | Technical Support: 800-645-9721 | surgex.com...
