Technical Specification

The following technical specifications apply to the OTS AF and PB models, unless otherwise stated:
Test voltage
Voltage resolution
Voltage accuracy
Vessels
Temperature sensor resolution
Power supply
Fuses
Batteries (PB model option only)
DC power supply (PB model only)
Internal printer (optional)
Protection
Display
Dimensions (W x H x D)
Weight
Operating temperature
Storage temperature
Humidity
22
PB models:
0 to 60 kV rms maximum (30 kV - 0 - 30 kV)
0 to 80 kV rms maximum (40 kV - 0 – 40 kV)
AF models:
0 to 60 kV rms maximum (30 kV - 0 - 30 kV)
0 to 80 kV rms maximum (40 kV - 0 - 40 kV)
0 to 100 kV rms maximum (50 kV - 0 - 50 kV)
0.1 kV
±1% ±2 digits
400 ml (standard)
150 ml (option)
Thermoplastic polyamide chamber provides precision electrode
alignment, adjustment wheels lock electrodes in position
1 ºC
Line voltage/power
Line frequency
2 x 4 A CFST ceramic, 20 mm x 5 mm, for 250 V
Lead Acid 2 x 12 V 4 Ah, or NiMH 24 V 2 Ah
12 VDC, 60 VA – fitted with battery option,
used to charge battery only
Dot matrix impact printer with graphical output
Paper 57.5 mm wide, weight 52 gm per roll
Epson black ribbon cassette ERC-09B
Safety interlock on test chamber
Discharge barrier on polycarbonate test chamber cover
320 x 240 QVGA colour display with backlight
OTS80PB 520 mm x 380 mm x 250 mm
OTS60PB 520 mm x 330 mm x 250 mm
OTS100AF 520 mm x 420 mm x 290 mm
OTS80AF 520 mm x 420 mm x 290 mm
OTS60AF 520 mm x 420 mm x 290 mm
OTS80PB
no battery
NiMH battery
Lead acid batteries
OTS60PB
no battery
NiMH battery
OTS100AF
OTS80AF
OTS60AF
0 ºC to +50 ºC
-30 ºC to +65 ºC
80% RH at 40 ºC operation
90 to 264 VAC, 300 VA
48 / 63 Hz
20.5 kg
21 kg
23.5 kg
16.3 kg
16.8 kg
30 kg
30 kg
30 kg
