Before commencing assembly please read these instructions thoroughly
Wing Span: 98.5 in / 2500 mm
Wing Area: 667 sq in / 43 sq dm
Flying Weight:
Fuselage Length: 45 in / 1145 mm
Requires:
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
www thewingsmaker com
GM048XMPO28181206
,
Specifications
Specifications
48 oz / 1360 g
4-channel radio w/ 4 micro servos. Outrunner
Motor KM0283010 w/ Propeller Adaptor HW2340100
20A Brushless ESC, 3 cells 11.1V 15C 1800 mAh Li-Po
battery & charger.
.
.
I NSTRUCTI ON M ANUAL
( GM048XM )
.
Advertisement
Table of Contents
Related Manuals for The Wings Maker SZD-45 OGAR
Summary of Contents for The Wings Maker SZD-45 OGAR
- Page 1 Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. * Specifications are subject to change without notice.* THE WINGS MAKER FACTORY PRE-FABRICATED ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA...
-
Page 2: Before You Begin
SZD-45 OGAR INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.9 SAFETY PRECAUTIONS BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. -
Page 3: Parts List
Parts List 1.MAIN WING -- 1 pair 5.MAIN LANDING GEAR -- 1 pc. MICRO AILERON SERVO MOUNT PL5310020 -- 1 pair MAIN WHEEL Ø50mm PL3111500-- 1 pc. STRAPER PL4112106 -- 2 pcs PLASTIC COLLAR d4xD8x3mm -- 1 pc. CLEVIS PL4112105 -- 2 pcs COLLAR Ø3.1mm w/ Set Screw -- 1 set FUEL TUBE d2xD4x4mm -- 4 pcs SCREW PA3x10mm -- 2 pcs... -
Page 4: Aileron Servo
Aileron Servo Screw PA1.7x8mm Plywood Aileron Servo Lead 36.5x36.5x2 mm Fibre Tape 17x435 mm Bottom View Bottom Fibre Tape Bottom View Clevis PA1.7x8mm Pushrod Ø1.4x60mm Fuel Tube Straper d2xD4x4mm Fuel Tube d2xD4x4mm Horn TWM PL8210010 CLEVIS WRENCH Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo. GM048XMPO28181206... -
Page 5: Stabilizer & Elevator
Stabilizer & Elevator Screw PA1.7x8mm Screw M3x25 d3.1xD11mm Washer Plywood 36.5x36.5x2 mm Fibre Tape Fibre Tape Bottom View Bottom 17x525 mm Bottom View Clevis PA1.7x8mm Ø1.4x33mm Pushrod Fuel Tube Straper d2xD4x4mm Fuel Tube d2xD4x4mm Horn TWM PL8210010 CLEVIS WRENCH Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo. M3x25mm Temporary install the main wing, (Stabi l i zer) -
Page 6: Rudder Servo
Rudder Servo Screw PA1.7x8mm Plywood 36.5x36.5x2 mm Rudder Servo Lead Fibre Tape 17x185 mm Fibre Tape Clevis PA1.7x8mm Pushrod Ø1.4x42mm Fuel Tube Straper d2xD4x4mm Fuel Tube d2xD4x4mm Horn TWM PL8210010 CLEVIS WRENCH Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo. Tail Landing Gear Screw PA2x8... -
Page 7: Main Landing Gear
Main Landing Gear Wheel Ø50mm M3x3mm Set Screw d4xD8x3mm Plastic Collar 3.1mm Collar Screw d3.2xD12mm PA3x10mm Washer d3.2xD12mm Washer M3 Nylon Insert Socket Head Screw M3x30mm M3x30mm Lock Nut PA3x10mm Nylon Insert Lock Nut Plastic Collar d4xD8x3mm Washer Collar w/ Set Screw d3.2xD12mm 3.1mm Bottom View... -
Page 8: Radio Equipment
Main Wing Aileron Servo Lead Wing Tube Ø8x900mm Hook Rubber Band Completed Radio Equipment Install and arrange the equipment as shown in the picture. Receiver Tie Battery Mat Iron ESC Connector Cable Tie Brushless ESC Battery Battery Tie Receiver Motor KP0011310 Solder Solder... - Page 9 Decals A’ A=A’ B’ C’ B=B’ C=C’ Field Stand / Launching Pad The field stand can be used as a launching-pad if you are flying on paved runways. Place the on the stand, point it into the wind, check your controls and advance the throttle. When the gets enough air speed, pull the elevator gently and the will fly off the field...
-
Page 10: Control Throws
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. szd-45 ogar is specially designed to be powered by KM0283010 Outrunner Motor. # Make sure the air field is spacious, never fly the plane too close to people and never get too close to a running propeller. - Page 11 Pl8210010 Large Clevis • Small Clevis • Outrunner 28/ 32 Deluxe (25% higher power) KM02832R1 -Kv(rpm/V): 1010 -Operating Power: 225W -Operating Voltage: 6-15V -Operating Current: 15A -Peak Current: 20A(max.15 sec.) -Internal Resistance: 102 m ohms -Diameter: 28mm -Length: 32mm -Weight: 60g -Shaft Diameter: 3mm -Shaft Length: 15mm -Mounting Screw:...
- Page 12 THE WINGS MAKER GM048XMPO28181206...
