- Page 1 Caution: You must read this before you proceed. Bar Chair Part NO. Picture Description Chair Back Page 1 OF 6 Noble house Home Furnishings LLC...
- Page 2 ② Screw (M4x40mm) ③ Spring Washer ④ Washer ⑤ Allen Key ⑥ Screwdriver Before Beginning Assembly: Bolt (M8x50mm) For assembling Washer Chair Legs(B) to the Chair Spring Washer Back(A) Allen Key Page 2 OF 6 Noble house Home Furnishings LLC...
- Page 3 Side Rail (C) This Bar Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Bar Chair parts, the above picture is to help you put the various Bar Chair parts into perspective.
- Page 4 Note: You may need to apply a little pressure to the Chair Legs to enable the Side Rails to be slotted into position. Attach Side Rails(C) to Chair Legs(B) using Screws(②) with Screwdriver(⑥). Do not fully tighten the Screws. Page 4 OF 6 Noble house Home Furnishings LLC...
- Page 5 Keep your feet and toes well away from the drop zone. Drop the Bar Chair freely and vertically with the four legs, hitting the ground, at the same time. This Drop Test will help to ensure that all the Bolts, Screws and gaps reach full alignment status.
- Page 6 Page 6 OF 6 Noble house Home Furnishings LLC...
