CAUTION: You must read this Assembly Instructions before
you proceed.
Please look under the Seat Panel for hardware pack.
CHAIR
CAUTION : This Chair is NOT a TOY.
Keep your child / children at bay in the process of assembly.
For turning the Chair and to prevent damage to the Chair, 02 persons may
be needed to execute this action.
Noble House Home Furnishings LLC
Page 1 OF 8
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings CHAIR
Summary of Contents for Noble House Home Furnishings CHAIR
- Page 1 CAUTION : This Chair is NOT a TOY. Keep your child / children at bay in the process of assembly. For turning the Chair and to prevent damage to the Chair, 02 persons may be needed to execute this action.
- Page 2 Backrest Panel Seat Cushion Back Cushion Hardware Label Picture Description ① Short Bolt (M6x40x15mm) ② Long Bolt (M6x55x15mm) ③ Self Tapping Screws (M4x 35mm) ④ Allen Wrench (K4) ⑤ Screwdriver (not provided) Noble House Home Furnishings LLC Page 2 OF 8...
- Page 3 This Chair has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 Left Side Panel (A), then secure them together using Bolts (①) and the Allen Wrench (④) as shown above. Do not fully tighten the Bolts at this time. Noble House Home Furnishings LLC Page 4 OF 8...
- Page 5 With assistance from your adult partner, attach the assembled part from step 3 to the Right Side Panel (B) using Bolts (①), Bolts (②) and the Allen Wrench (④) as shown in the picture above. Do not fully tighten the Bolts at this time. Noble House Home Furnishings LLC Page 5 OF 8...
- Page 6 Turn the Chair right side up. EXERT pressure, floorwards, onto the Chair with both hands. This pressure will help the Chair reach full alignment at all joints. Check for wobbles. Inspect the Chair and make sure all parts are adequately connected.
- Page 7 Step 7 Place the Seat Cushion (E) onto the Chair and affix the magic tape straps around the Chair as shown above. Then place the Back Cushion (F) onto the Chair. Your Chair is ready to be used. This Chair can only be used on a flat, level surface.
- Page 8 Care & Maintenance Noble House Home Furnishings LLC Page 8 OF 8...
