EEI –3191 Office Chair

STEP 7:

Attach Back Cover (10) to the Back Support (9) by using 2 pieces of Screw (D) as shown.
Tighten Screw (D) by using screwdriver (not included) as shown.

STEP 8:

Insert the Back Frame (5) to the hole of Control Mechanism (3) by using 1 piece of Bolt (E) and 1 piece of Nut
(F) as shown.
Tighten Bolt (E) by using Allen Wrench (J) as shown.
5
7
3
8
Customer Service 908-368-1025︱www.modwayfurniture.com
6
9
4
2
11
1
8
Hardware & Tools required
J
E
F
Hardware & Tools required
F
x 1
J
E
x 1 x 1
