3. Assuming the node will be mounted in a rack, it can be secured to slides,
or set on a fixed or slide-out shelf. The node can also be mounted directly
to the cabinet frame, but this makes access difficult.
Do not support a rack-mounted node only in the front.
It must be supported at both front and rear.
4. Plug all cables into the appropriate connectors at the rear of the FRX6000,
and tighten the retaining screws on each cable connector that has them. (It
does not matter which end of an RLP cable plugs into the RLP.) Figure 1
shows the connectors on the rear of the chassis, and Figure 3 shows some
cable retaining screws.
5. Plug the RLP cables into their associated I/O boxes and tighten the
retaining screws. If the assembly is being rack mounted, attach the I/O
boxes and cables as shown in Figure 3, using the hardware provided.
Leave a 24–36 inch service loop in each cable between the mounting rails
and the rear of the node, to allow the unit to be pulled forward.
Installation & Setup Guide
Token Ring
DB9F
RJ45
4
3
Retaining Screw
RLP Cable
I/O Box
Support Rails
Interface Cables
Figure 3 Rack-Mounted I/O Boxes
In the above example, both Line Interface Cards (LICs) on the RLP
are 4-port LICs (V.35, RS-232, or RS-422). A T1 or E1 LIC includes
an RJ45 adapter instead of an RLP cable and I/O box. (The T1/E1
cable is not supplied.)
Table 1 WAN Port Interface Cables
Cable Type Cabletron Part Number
V.35 DTE
FRX-V35DTE-CAB
V.35 DCE FRX-V35DCE-CAB
RS-232 DTE FRX-232DTE-CAB
RS-232 DCE FRX-232DCE-CAB
RS-449 DTE FRX-449DTE-CAB
RS-449 DCE FRX-449DCE-CAB
X.21 DTE FRX-X21DTE-CAB
X.21 DCE FRX-X21DCE-CAB
* One V.35 DTE cable is shipped as standard equipment with each FRX6000.
Cable
Service
Clamp
Loop
Cable Tie
