STEP 4 – MANAGING THE SD CARD
To install the memory card (not included):
1. To install the camera's SD Card, locate the SD card slot in the side of the camera by unscrewing
the con cap.
2. Insert class 10 SD/SDHC/SDXC card into the SD card slot by pressing the SD card until clicks.
To remove the SD card, press the card inward until it clicks to release from the card slot then pull out
3.
from the slot
1
SD Card Slot
Con Cap
STEP 5 – RESETTING THE CAMERA
To reset the camera, use the tip of a paper clip or a pencil and press the reset button. Pressing the button
for five (5) seconds will initiate a camera-wide reset of all the settings, including network settings.
STEP 6 – DW IP FINDER
Use the DW IP Finder
network settings or access the camera's web client. The camera can also be detected and configured
using the VMAX IP Plus™ NVR or the DW Spectrum
®
2
Camera Name,
Model, IP Address,
and MAC Address
Firmware Upgrade
Network Setup
1. Go to: http://www.digital-watchdog.com
3
2. Search for 'IP Finder' on the quick search bar at the top of the page.
3. The latest IP Finder software will appear in the search results. Click on the link to download the file to
your computer.
4. The software will scan your network for all supported cameras and display the results in the table.
Allow up to 5 seconds for the IP Finder to find the camera on the network.
5. Select a camera from the list by double-clicking on the camera's image or clicking on the 'Click' button
under the IP Conf. column. The camera's network information will appear. If necessary, you can adjust
the camera's network type.
Select DHCP if the internet service is dynamic IP. This will
allow the camera to receive its IP address from the DHCP
server.
Select STATIC to manually enter the camera's IP address,
subnet mask, Gateway and DNS information.
Reset Button
Contact your network administrator for more information.
6. The camera's default network information is:
Default TCP/IP information
• IP: DHCP
™
™ software to scan the network and detect all MEGApix ® cameras, set the camera's
IPVMS.
®
Camera's View Camera's
Search for Cameras Network Settings Thumbnail View
Filter Search Results
Camera Uptime
Camera's Firmware
Open Camera's IP
Configuration Screen
7. To view the camera's web viewer, click on "View Camera Website".
'Port Forwarding' has to be set in your network's router for external access to the camera.
8. To save the changes made to the camera's settings, input an ID and PW of the camera for
authentication and click 'Save'.
9. If the camera needs to be rebooted after the settings were changed, press the 'Reboot' button.
The camera will cycle power and will appear back in the search results once the reboot is complete.
Default ID / PW : admin / admin
STEP 7 – WEB VIEWER
The GUI display may differ by camera models.
Once the camera's network settings have been setup properly, you can access the camera's web viewer
using the DW IP Finder .
™
To open the camera's web viewer:
Find the camera using the DW IP Finder .
1. ™
2. Double-click on the camera's view in the results table.
3. Press the 'View Camera Website'. The camera's web viewer will open up in your default web browser.
4. Enter the camera's username and password (default are admin / admin).
5. If you are accessing the camera for the first time, install the ActiveX files in order to view video from the
camera.
NOTE: Please see the full product manual for web viewer setup, functions and camera settings options.
Rev Date: 05/17 Specifications and pricing are subject to change without notice.
Quick Start Guide
